We supply original Makita spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Drill 6501X.
In the following table, look for the model of the Drill and the respective parts of the code.
| Drill Makita 6501X | ||
| # | Part Num. | Description |
| 1 | 193203-4 | CHUCK, KEYLESS X 6501X |
| 2 | 153178-9 | GEAR ASSY 6501 |
| 3 | 214017-9 | BEARING t5 |
| 4 | 211016-2 | BALL BEARING 626DD |
| 5 | 241508-7 | FAN |
| 6 | 517033-3 | ARMATURE X 6501 |
| 7 | 211016-2 | BALL BEARING 626DD |
| 8 | 633033-6 | STATOR X 6501 |
| 9 | 191914-5 | CARBON BRUSHE SET CB-70 (69) |
| 10 | 632073-1 | HOLDER BACK ARMATURE |
| 11 | 183209-0 | HOUSING FOR CPL 6501 |
| 12 | 651268-7 | SWITCH SGEL206C-2 |
| 13 | 645006-7 | CAPACITOR X LS1013 |
| 16 | 265874-8 | HEAD SCREW CILIND. M4x20 |
| 18 | 682502-4 | CABLE SLEEVE 8/85 6408 |
| 19 | 232100-0 | SPRING PLATE |
| 20 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 21 | 687063-9 | RETAINER X 4304T |
