Makita Spare Parts for Metal Shear JS3201J
€42.06
Tax included
Makita Spare Parts for Metal Shear JS3201J
Makita genuine spare parts or replacements parts for to fix Makita JS3201J Metal Shear.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Metal Shear JS3201J
Makita genuine spare parts or replacements parts for to fix Makita JS3201J Metal Shear.
In the following table, look for the model of the Blenchschere and the respective parts of the code.
| Makita JS3201J Metal Shear Spare Parts | ||
| # | Part Num. | Description |
| 1 | 266056-5 | SCREW M5 X 45 X JR3060T |
| 2 | 141795-7 | GEAR BOX |
| 3 | 253759-0 | ROND.P.12 JN / JS3200 |
| 4 | 331166-8 | ROD X JS3200 |
| 5 | 212252-3 | BEARING ROLLER 1816 |
| 6 | 253198-4 | FLAT WASHER 18 XJS3200 |
| 7 | 153141-2 | SHAFT ECCENTRIC XJS3200 |
| 8 | 253311-4 | ROND.10 8419B / 6710D |
| 9 | 442186-8 | SEAL |
| 10 | 141796-5 | COVER GEAR BOX |
| 11 | 211031-6 | BEARING 608LLB X 4304T |
| 12 | 240094-5 | FAN 70 GA5010 |
| 13 | 513859-1 | ARMATURE |
| 14 | 681644-1 | INSULATING WASHER X 9227CB |
| 15 | 210029-0 | BEARING 608Z X MT601 |
| 16 | 226058-3 | GEAR 18-46 XJS3200 |
| 17 | 253215-0 | ROND. FLAT 8 6510PBL / LVR |
| 18 | 256118-7 | PIN 8 |
| 19 | 913322-8 | SCREW M6x14 |
| 20 | 321405-4 | TUBE X JS3200 |
| 21 | 321404-6 | HOLDER KNIFE XJS3200 |
| 22 | 922216-6 | SCREW ESAG. M5x14 |
| 23 | 346641-1 | PROTECTION |
| 24 | 331165-0 | SHOE X JS3200 |
| 25 | 931203-4 | NUT ESAG. M5-8 XJS3200 |
| 26 | 922227-1 | BOLT M5X18 |
| 27 | 922216-6 | SCREW ESAG. M5x14 |
| 28 | 922451-6 | BOLT M8x30 |
| 29 | 266340-8 | SCREW 4X65 GA5010 |
| 30 | 454140-0 | BAFFLE |
| 31 | 525869-6 | STATOR |
| 32 | 643750-0 | PLUG BRUSH HOLDER |
| 33 | 191963-2 | CARBON BRUSHES CB-303 |
| 35 | 158278-0 | CASING MOTOR GA5010 |
| 36 | 187531-7 | HANDLE |
| 37 | 650230-9 | SWITCH TGL115CDT EQ-2 |
| 38 | 654532-5 | TERMINAL BLOCK 6E / 1DS |
| 39 | 266326-2 | SCREW 4x18 X MT601 |
| 40 | 687052-4 | CLAMP Cable tie X 6408 |
| 41 | 688172-7 | FILTER LINE |
| 42 | 645200-1 | CAPACITOR |
| 43 | 682540-6 | SLEEVE JN1601 |
| 45 | 266326-2 | SCREW 4x18 X MT601 |
| 47 | 256255-7 | PIN 3 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
