Makita Spare Parts for Angle Grinder GA5040C

€6.68
Tax included

Makita Spare Parts for Angle Grinder GA5040C

Distribution and Sale at attractive prices of MAKITA Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Angle Grinder GA5040C.
ITEM CODE: 210027-4
Quantity
on 7/10 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Angle Grinder GA5040C

Distribution and Sale at attractive prices of MAKITA Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Angle Grinder GA5040C.

In the following table, look for the model of the Angle Grinder and the respective parts of the code.
Angle Grinder GA5040C

Angle Grinder GA5040C
# Part Num. Description
1 168705-9 GEAR BOX FOR GA
2 252186-8 NUT M6 X 9554NB
3 253077-6 WASHER P. 6 4300 / 01BV
4 227591-8 GEAR FOR 10 GA
5 211142-7 BEARING 6001LLB X GD0800C
6 318835-8 COVER GEAR BOX
10 253084-9 WASHER P.12 8419B / 5016NB
11 240134-9 FAN FOR 60 GA
12 515373-3 ARMATURE
13 681656-4 INSULATOR X GD0810C
14 253823-7 ROND. FLAT 7 X JS1600
15 210027-4 BEARING 627DDW X 9561CV
16 421738-8 RING LABYRINTH 22 X 9561CV
17 267756-0 WAVY WASHER X BO6040
18 688117-5 MAGNETIC SOCKET X GD0800C
19 259039-2 LOCKING 6 X 9566CV
22 453367-9 BAFFLE
23 266258-3 SCREW 4 X 70 X 9564
24 344871-8 RETAINING X GD0800C
25 626653-3 STATOR 220-240V
27 191978-9 CARBON BRUSHES CB 318 (EX 310)
28 266007-8 SCREW M3 X10 HP2030
29 643769-9 BRUSHES HOLDER
30 453366-1 HOUSING MOTOR
31 266326-2 SCREW 4x18 X MT601
32 687169-3 CLAMP ties HP1620
33 638947-4 SWITCH HOLDER
35 682559-5 SAVE CABLE X 6822
36 266326-2 SCREW 4x18 X MT601
38 453365-3 BACK COVER C
39 620127-6 REGULATOR
40 651418-4 SWITCH ST115A-40 X 9541
42 233071-4 SPRING COMPRESSION 4 X 9541
43 453847-5 LEVER SWITCH
44 453368-7 KEY SWITCH
46 453369-5 BUTTON
47 234057-1 COMPRESSION SPRING 6 GA5021C
48 266361-0 SCREW 4 X 30 X 9554NB
49 213032-0 RING 4 X GA4530
50 256535-1 PLUG FOR 6 GA
51 263002-9 RUBBER PLUG 4
52 210026-6 BALL BEARING 696ZZ
53 961005-4 RETAINING RING S9
54 253180-3 FLAT WASHER 10 X 6221DW
55 310508-9 SOCKET FOR GA
56 346556-2 C PLATE FOR GA
57 227592-6 GEAR FOR 38 GA
58 313228-4 JUNCTION FOR GA
59 210302-8 BEARING 6903ZZ FOR GA
60 253744-3 WASHER PIANA 12 24B / 12N / 14
61 263002-9 RUBBER PLUG 4
62 213641-5 RING FOR 51 GA
63 318837-4 BEARING BOX
64 265490-6 SCREW M4 X 16 X 9561CV
65 211129-9 BALL BEARING NSK 6201DD
66 267279-8 FLAT WASHER 21 X HR2450FT
67 443124-3 FELT RING 17 GD0600
68 285854-8 RETAINING BEARING 20-33
70 326130-2 POST FOR GA
72 123145-8 DISC COVER GA SERIES
73 224415-9 FLANGE INTERNAL 42 GA95010
74 224554-5 EXTERNAL FLANGE 14-45 X 9541
