Makita Spare Parts for Rotary Hammer HR2800
€71.79
Tax included
Makita Spare Parts for Rotary Hammer HR2800
We are MAKITA original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Rotary Hammer HR2800.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Rotary Hammer HR2800
We are MAKITA original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Rotary Hammer HR2800.
In the following table, look for the model of the Rotary Hammer and the respective parts of the code.
| Rotary Hammer HR2800 | ||
| # | Part Num. | Description |
| 1 | 286263-4 | Cap 35 X HR2020 |
| 2 | 233940-9 | ELASTIC RING 19 FOR HR2432 |
| 3 | 417629-9 | FRONT COVER X HR2020 |
| 4 | 257241-1 | RING 21 X HR2020 |
| 5 | 345187-4 | WASHER X HR2020 |
| 6 | 233916-6 | SPRING 21-29 X HR2020 |
| 7 | 922241-7 | SCREW M5X25 |
| 8 | 158057-6 | HANDLE 36 CPL HR2230 |
| 9 | 921919-9 | BOLTM8X110 |
| 10 | 419975-6 | HANDLE SUPPORT X HR2800 |
| 11 | 158288-7 | CANNON FOR HR2800 |
| 12 | 267354-0 | WASHER 31 HR2800 |
| 13 | 262133-1 | URETE RING 31 HR2800 |
| 14 | 267354-0 | WASHER 31 HR2800 |
| 18 | 213620-3 | RING 46 X BSR730 |
| 19 | 922128-3 | BOLT M4X16 4300BA |
| 20 | 419984-5 | CONROD HOUSING COVER HR2800 |
| 21 | 216022-2 | BALL 7 |
| 22 | 158285-3 | TIP HOLDER HR2800 |
| 23 | 213344-1 | OIL SEAL 9X HR2800 |
| 24 | 961140-8 | RETAINING RING HR2800 |
| 25 | 331769-8 | BUSH 9 FOR HR2230 |
| 26 | 324669-9 | HAMMER BHR240 |
| 27 | 324402-9 | RING 10 X HR2450FT |
| 28 | 421955-0 | DAMPER RING 13 |
| 29 | 324216-6 | RING X HR2020 |
| 30 | 213073-6 | RING 9 X HR2020 |
| 31 | 233917-4 | ELASTIC RING 28 X HR2020 |
| 32 | 267105-1 | FLAT WASHER X HR2400 |
| 33 | 234021-2 | COMPRESSION SPRING 30 HR2800 |
| 34 | 331770-3 | GEAR X GE2800 |
| 35 | 213435-8 | RING 26 X HR3000C |
| 36 | 256099-5 | PIN 6 HK / HR2210 / 20 |
| 37 | 324733-6 | HAMMER X HR2460 |
| 38 | 213227-5 | RING 16 X HK0500 |
| 39 | 331776-1 | PISTON CYLINDER HR2800 |
| 40 | 233954-8 | ELASTIC RING 21 HR2800 |
| 41 | 158282-9 | CONROD HR2800 |
| 42 | 227532-4 | GEOGRAPHY 31 X HR2800 |
| 43 | 266420-0 | SCREW 5X20 HR2800 |
| 48 | 213262-3 | GASKET 18 4100R |
| 49 | 162256-4 | CHANGE LEVER SUPPORT HR2800 |
| 50 | 419988-7 | FILTER COVER HR2800 |
| 51 | 213218-6 | RING 16 X HR2800 |
| 52 | 443129-3 | FILTER HR2800 |
| 53 | 419987-9 | CONROD HOUSING COVER HR2800 |
| 54 | 213406-5 | GASKET 30 58NB / SB / HM1200 |
| 55 | 158289-5 | CRANK HOUSING COMPLETE HR2800 |
| 56 | 324793-8 | ECCENTRICO HR2800 |
| 57 | 211232-6 | BALL BEARING X HK0500 |
| 58 | 961055-9 | RETAINING RING S15 |
| 59 | 233951-4 | ELASTIC SPRING 16-26 HR2800 |
| 60 | 223167-9 | CLUTCH GEAR HR2800 |
| 61 | 226653-9 | GEAR 29 HR2800 |
| 62 | 267353-2 | WASHER 8 HR2800 |
| 63 | 961034-7 | RETAINING RING X HR2800 |
| 64 | 345818-5 | ELASTIC WASHER 16 HR2800 |
| 65 | 254239-9 | KEY 4 X HR3000C |
| 66 | 227524-3 | GEAR 9 X HR2800 |
| 67 | 254239-9 | KEY 4 X HR3000C |
| 68 | 210105-0 | BEARING 6001LLU X PW5000CH |
| 69 | 125386-2 | CLUTCH HR2800 |
| 70 | 961006-2 | RETAINING RING S10 |
| 71 | 210024-0 | BEARING X HR5001C |
| 72 | 424028-8 | SEAL HR2800 |
| 73 | 158287-9 | GEARS HOUSING HR2800 |
| 74 | 213445-5 | RING 26 X 9554NB |
| 75 | 213133-4 | OIL SEAL 12 X HR2800 |
| 76 | 331775-3 | BUSH 10 HR2800 |
| 77 | 210054-1 | BEARING X HM1100C |
| 78 | 253171-4 | WASHER X T221DW |
| 79 | 240095-3 | FAN 64 HR2800 |
| 80 | 515294-9 | ARMATURE HR2800 |
| 81 | 266325-4 | SCREW M 4 X 70 X MT952 |
| 82 | 210023-2 | BEARING9910/11 |
| 83 | 681656-4 | ISOLANT WASHER X GD0810C |
| 84 | 419989-5 | DEFLECTOR HR2800 |
| 85 | 526584-5 | FIELD HR2800 |
| 86 | 419981-1 | MOTOR HOUSING HR2800 |
| 87 | 643766-5 | BRUSH HOLDER HR2800 |
| 88 | 266421-8 | SCREW 3X10 HR2800 |
| 89 | 194074-2 | CARBON BRUSHE SET CB-325 X 9554NB |
| 91 | 419983-7 | REAR COVER HR2800 |
| 92 | 266326-2 | SCREW 4X18 X MT601 |
| 93 | 638568-2 | COIL HR2800 |
| 94 | 638567-4 | CABLE B / N HR2800 |
| 95 | 638566-6 | CABLE A / V HR2800 CABLE |
| 96 | 266326-2 | SCREW 4X18 X MT601 |
| 97 | 158284-5 | CHANGE LEVER HR2800 |
| 101 | 419977-2 | REAR HANDLE HR2800 |
| 102 | 911258-5 | SCREW M5X35 4101R |
| 103 | 266420-0 | SCREW 5X20 HR2800 |
| 104 | 863909-5 | LABEL MOD. HR2800 |
| 105 | 419992-6 | REVERSIBILITY LEVER' HR2800 |
| 109 | 645200-1 | CAPACITOR |
| 110 | 419990-0 | SWITCH LEVER HR2800 |
| 111 | 158281-1 | SWITCH SUPPORT HR2800 |
| 112 | 650591-7 | SWITCH HR2800 |
| 113 | 419980-3 | HANDLE COVER HR2800 |
| 114 | 266326-2 | SCREW 4X18 X MT601 |
| 116 | 682573-1 | CORD ARMOR 10 X GA9010C |
| 117 | 266326-2 | SCREW 4X18 X MT601 |
| 118 | 687169-3 | GROMMET HP1620 |
| 119 | 685722-9 | SPONGE X 4302C |
| 999 | 195206-4 | Service Pack HR2800 |
