Makita Spare Parts for Wet Diamond Core Drill DBM230KIT
€25.13
Tax included
Makita Spare Parts for Wet Diamond Core Drill DBM230KIT
We supply MAKITA original spare parts on offer at Lower prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Wet Diamond Core Drill DBM230KIT.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Wet Diamond Core Drill DBM230KIT
We supply MAKITA original spare parts on offer at Lower prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Wet Diamond Core Drill DBM230KIT.
In the following table, look for the model of Core Drill and the respective parts of the code.
| Wet Diamond Core Drill DBM230Kit Pag.1 |
||
| # | Part Num. | Description |
| 1 | EE73537100 | ARMATURE FOR DBM230 |
| 2 | EE80410021 | BEARING 6000ZZ FOR DBM230 |
| 3 | EE83000031 | HOLDER FOR BEARING DBM230 |
| 4 | EE80410101 | BEARING FOR 6201RSZ DBM230 |
| 5 | EE80420160 | HOLDER FOR BEARING DBM230 |
| 6 | EE80201321 | WASHER 12 FOR DBM230 |
| 7 | EE80900159 | HOUSING MOTOR X DBM130 |
| 8 | EE73R53150 | STATOR FOR DBM230 |
| 10 | EE80201199 | HOLDERS X DBM130 |
| 11 | 7332022S | CARBON BRUSHES X DBM130 (2PCS) |
| 12 | EE80900073 | COVER DOOR SPAZ. X DBM230 |
| 13 | EE80201270 | SCREW 4.2 X 13 X DBM080 |
| 14 | EE80201234 | SCREW 3X78 FOR DBM230 |
| 15 | EE80201252 | SCREW 2.9 X 13 X DBM080 |
| 16 | EE85000097 | DEFLECTOR FOR DBM230 |
| 17 | EE80201425 | SCREW 4.5 X 60 FOR DBM230 |
| 18 | EE73537240 | HOUSING FOR A DBM230 |
| 19 | EE80201286 | SCREW 4.8 X 70 FOR DBM230 |
| 20 | EE80901000 | HOUSING B |
| 22 | EE80600119 | SWITCH DBM230 |
| 23 | EE80500010 | CAPACITOR X UT120 |
| 24 | EE80600174 | HOLDER CABLE ALIM. FOR DBM230 |
| 25 | EE73533262 | CABLE + Switch SAFETY AREA. FOR DBM230 |
| 26 | EE73537610 | COVER SC. INPUT. FOR DBM230 |
| 27 | EE80200757 | SCREW M6 X 6 FOR DBM230 |
| 28 | EE83000042 | SEAL 15 X 21 X 3 FOR DBM230 |
| 29 | EE80201351 | RETAINING RING FOR DBM230 |
| 30 | EE80420150 | CUSC. ROLLER HK2012 X DBM230 |
| 31 | EE80420130 | CUSC. ROLLER HK1212 X DBM230 |
| 32 | EE73531420 | POST FOR DBM230 |
| 34 | EE83000073 | SEAL 40X52X7 FOR DBM230 |
| 35 | EE83000074 | SEAL 40X55X7 FOR DBM230 |
| 36 | EE80200607 | KEY FOR 6X6X32 DBM230 |
| 37 | EE80201337 | WASHER FOR 52/2 DBM230 |
| 38 | EE80420155 | CUSC. ROLLER FOR NKS37 DBM230 |
| 39 | EE73531450 | RING DBM230 |
| 40 | EE80420165 | DISTANCE FOR LS 3047 DBM230 |
| 41 | EE80420038 | CUSC. ASS. AXK3047A FOR DBM230 |
| 42 | EE80420168 | DISTANCE FOR ZS3151 DBM230 |
| 43 | EE80200717 | SPRING PIAST.50X25,4X3 X DBM230 |
| 44 | EE73531425 | DISC HOLDER FOR DBM230 |
| 45 | EE73533430 | GEAR X DBM230 |
| 47 | EE73531423 | CYLINDER DBM230 |
| 48 | EE85000076 | DISC DBM230 |
| 49 | EE80201010 | NUT M24 X 1.5 FOR DBM230 |
| 50 | EE73537400 | GEAR BOX FOR DBM230 |
| 51 | EE73531410 | RING DBM230 |
| 52 | EE80201125 | SCREW M6 X 25 FOR DBM230 |
| 53 | EE80201362 | RING STOP S6 X DBM130 |
| 54 | EE80201211 | SCREW M5 X 55 FOR DBM230 |
| 55 | EE83000080 | RING FOR 50,52X1,78 DBM230 |
| 56 | EE80201050 | BUSHING FOR DBM230 |
| 57 | EE80201406 | LOCK SCREW 1/8 "FOR DBM230 |
| 58 | EE83000106 | SEAL 1/8 "FOR DBM230 |
| 59 | EE82000066 | SEAL X DBM230 |
| 60 | EE73531545 | LEVER SPEED. FOR DBM230 |
| 61 | EE73531540 | KNOB TO CHANGE DBM230 |
| 62 | EE80200578 | PLUG FOR 4,6X12 DBM230 |
| 63 | EE83000081 | RING FOR 18,77X1,75 DBM230 |
| 64 | EE73531542 | LEVER FOR DBM230 |
| 65 | EE80200579 | PLUG FOR 5,6X14 DBM230 |
| 66 | EE80201364 | WASHER FOR 5 DBM230 |
| 67 | EE80201230 | SCREW M5 X 12 FOR DBM230 |
| 69 | EE73533490 | CHANGE FOR POST DBM230 |
| 70 | EE80410081 | BALL FOR 5 DBM230 |
| 71 | EE80200694 | SPRING COMPRESSION DBM230 |
| 72 | EE80200610 | KEY FOR 6X6X50 DBM230 |
| 73 | EE73531460 | GEAR FOR A DBM230 |
| 75 | EE73531494 | RING FOR 20X24,5X1 DBM230 |
| 76 | EE80200749 | SNAP RING FOR 20 DBM230 |
| 77 | EE73531550 | GEAR FOR DBM230 |
| 78 | EE73531470 | GEAR FOR B DBM230 |
| 79 | EE80200514 | RING 16X22X1 FOR DBM230 |
| 80 | EE80201316 | WASHER 16X1 FOR DBM230 |
| 81 | EE73325185 | CABLE FOR MASS DBM230 |
| 82 | EE80201200 | SCREW M 4 X 6 FOR DBM230 |
| 83 | EE80200752 | WASHER 4.3 X DBM130 |
| 84 | EE73531500 | SHAFT FOR DBM230 |
| 85 | EE80200600 | KEY FOR 5X5X10 DBM230 |
| 86 | EE73531440 | GEAR FOR C DBM230 |
| 87 | EE73533510 | GEAR FOR D DBM230 |
| 88 | EE80410031 | BEARING FOR DBM230 |
| 89 | EE80410160 | BEARING 6302 FOR DBM230 |
| 91 | EE83000109 | PIPE DBM230 |
| 92 | EE83000107 | SEAL 1/4 "FOR DBM230 |
| 93 | EE83000117 | BALL VALVE FOR DBM230 |
| 95 | EE83000124 | HOLDER FOR DBM230 |
| 97 | EE80601153 | BUSHING FOR LED TO DBM230 |
| 98 | EE80601154 | LED TO DBM230 |
| 99 | EE80201295 | NUT PLASTIC X DBM130 |
| 100 | EE80601155 | PRINTED CIRCUIT FOR DBM230 |
| 101 | EE80201273 | SCREW 4.2 X 25 X DBM130 |
| WATER KIT Pag.2 |
||
| 1 | EE796UN813 | GRIP VALVE FOR DBM230 |
| 2 | EE83000066 | SEAL FOR DBM230 |
| 3 | EE796UN650 | PIN VALVE DBM230 |
| 4 | EE796UN814 | PLUG PIN VALVE DBM230 |
| 5 | EE83000083 | RING NBR 6X2 70 FOR DBM230 |
| 6 | EE80201147 | SCREW M8 X 20 FOR DBM230 |
| 7 | EE85000175 | SPRING COMPRESSION DBM230 |
| 8 | EE80201372 | WASHER FOR 9 DBM230 |
| 9 | EE83000096 | SEAL SPONGE DBM230 |
| 10 | EE83000104 | FITTING 1/4 "G FOR DBM230 |
| 1 | EE15200100 | KNOB FOR P-54190 |
| 2 | EE796UN740 | HOLDER KNOB P-54190 |
| 3 | EE796UN746 | LEVER X P-54190 |
| 4 | EE85000193 | KNOB X P-54190 |
| 5 | EE85000157 | ELASTIC PIN X P-54190 |
| 6 | EE802000627 | PIN 5X30 X P-54190 |
| 9 | EE79600780 | SLED X P-54190 |
| 10 | EE796UN780 | SLED X P-54190 |
| 11 | EE796UN765 | CAP X P-54190 |
| 12 | EE796UN763 | PLATE X P-54190 |
| 13 | EE796UN915 | PLATE X P-54190 |
| 14 | EE80201158 | SCREW M6 X 30 P-54190 |
| 15 | EE80200758 | SCREW X P-54190 |
| 16 | EE85000153 | INDICATOR X P-54190 |
| 17 | EE85000152 | INDICATOR HORIZONTAL P-54190 |
| 18 | EE796UN778 | PLATE X P-54190 |
| 19 | EE796UN770 | BEARING X P-54190 |
| 20 | EE7300W730 | POST X P-54190 |
| 21 | EE80201186 | SCREW M6X40 P-54190 |
| 22 | EE85000189 | SCREW M8X32 X P-54190 |
| 23 | EE85000191 | SCREW M16 X P-54190 |
| 24 | EE796UN735 | SCREW SAFETY X P-54190 |
| 25 | EE85000177 | BUSHING X P-54190 |
| 28 | EE79600911 | GROUP ADAPTER P-54190 |
| 29 | EE796UN911 | ADAPTER X P-54190 |
| 30 | EE80200613 | KEY P 100 X-54190 |
| 31 | EE80201147 | SCREW M8 X 20 FOR DBM230 |
| 32 | EE80201051 | BUSHING 12X10 P-5190 |
| 35 | EE79600895 | BASE COMPLETE X P-54190 |
| 36 | EE796UN895 | BASE X P-54190 |
| 37 | EE85000163 | BUSH THREADED X P-54190 |
| 38 | EE80201381 | WASHER X P-54190 |
| 39 | EE80201041 | NUT FOR M12 P-54190 |
| 40 | EE80201144 | EYEBOLT X P-54190 |
| 41 | EE80201146 | SCREW M10 X 20 P-54190 |
| 42 | EE80201380 | WASHER X P-54190 |
| 45 | EE79600950 | RACK COMPLETE X P-54190 |
| 46 | EE796UN950 | RACK P-54190 |
| 47 | EE80201139 | SCREW X P-54190 |
| 48 | EE80201188 | SCREW M12X110 P-54190 |
| 49 | EE80201388 | WASHER 13 X P-54190 |
| 50 | EE80201036 | NUT FOR M12 P-54190 |
| 51 | EE796UN919 | PLATE X P-54190 |
| 52 | EE80201168 | SCREW M5X20 X P-54190 |
| 53 | EE796DE817 | HANDLE UPPER P-54190 |
| 54 | EE80201160 | SCREW M8x16 X DBM230 |
| 57 | EE79600852 | GROUP GUYS X P-54190 |
| 58 | EE796UN852 | HOLDER X P-54190 |
| 59 | EE796UN918 | HOLDER X P-54190 |
| 60 | EE80201255 | SCREW M8 X 90 X P-54190 |
| 61 | EE80201221 | NUT M8 X P-54190 |
| 62 | EE80201383 | WASHER 8.4 X P-54190 |
| 63 | EE85000188 | LEVER X P-54190 |
| 64 | EE796UN930 | PLATE X P-54190 |
| 67 | EE79600809 | GROUP WHEELS X P-54190 |
| 68 | EE796UN809 | AXIS WHEELS X P-54190 |
| 69 | EE80201318 | WASHER X P-54190 |
| 70 | EE80201352 | WASHER 15 X P-54190 |
| 71 | EE85000178 | WHEEL X P-54190 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
