Makita Spare Parts for Circular Saw 5103R
We have the original Spares MAKITA for Circular Saw 5103R, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Circular Saw 5103R. All Spares are original and can be supplied at Cheap and discounted prices. Our Spares are Genuine Parts Guaranteed.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Circular Saw 5103R
We have the original Spares MAKITA for Circular Saw 5103R, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.
In the following table, look for the model of Circular Saw and the respective parts of the code.
| Circular Saw 5103R | ||
| # | Part Num. | Description |
| 1 | 266083-2 | SCREW M10x25 X 5143R |
| 2 | 224325-0 | EXTERNAL FLANGE 45 X 5103R |
| 3 | 224326-8 | FLANGE INTERNAL 45 X 5103R |
| 4 | 912222-9 | M5X16 SCREW |
| 5 | 285681-3 | STILL BEARING X 5103R |
| 6 | 318062-7 | PROTECTION BLADE X 5103R |
| 7 | 231841-5 | SPRING TENSION 6 X5103R |
| 8 | 211490-4 | BEARING 6203LLU X SG150-2 |
| 9 | 415437-2 | PIN 6 X 5903R |
| 10 | 415438-0 | WASHER 20 |
| 11 | 415438-0 | WASHER 20 |
| 12 | 415437-2 | PIN 6 X 5903R |
| 13 | 922422-3 | HEXAGON BOLT M8x16 |
| 14 | 267284-5 | WASHER 8 X DCS230T |
| 15 | 345750-3 | DIVIDING KNIFE X 5103R |
| 16 | 344260-7 | HOLDER KNIFE DIVIS.X5103R |
| 17 | 344303-5 | RING THICKNESS X 5103R |
| 18 | 911223-4 | HEAD SCREW CILIND. M5X16 |
| 19 | 316709-7 | HOLDER BEARING X5103R |
| 20 | 322830-2 | SLEEVE CLOSING X5143R-5103R |
| 21 | 322827-1 | SHAFT X 5103R |
| 22 | 231968-1 | SPRING 27 X 5143R |
| 23 | 231969-9 | SPRING 20 X 5143R |
| 24 | 226452-9 | GEAR 39 X 5103R |
| 25 | 211104-5 | BEARING 6001 X5143R |
| 26 | 961052-5 | RETAINING RING S12 |
| 27 | 272230-5 | LEVER 54 |
| 28 | 231955-0 | SPRING RETAINER 12 X 5903R |
| 29 | 252134-7 | NUT M8 |
| 30 | 911263-2 | HEAD SCREW CILIND. M5x40 |
| 31 | 266041-8 | PT SCREW 5x25 |
| 32 | 182773-8 | HANDLE COMPL.X5143R |
| 33 | 415440-3 | LOCK BUTTON |
| 34 | 231230-4 | SPRING COMPRESSION 4 |
| 35 | 415439-8 | LEVER SWITCH |
| 36 | 651923-1 | SWITCH TG70B X 5903R |
| 37 | 645006-7 | CAPACITOR X LS1013 |
| 38 | 631209-9 | SPEED CONTROL 'X5143R |
| 40 | 331469-0 | SOCKETS 9 X 5143R |
| 41 | 267216-2 | FLAT WASHER 8 X BO3700 |
| 42 | 232151-3 | SPRING PLATE X 5103R |
| 43 | 266019-1 | BOLT M8X98 |
| 44 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 45 | 687063-9 | BOOT X 4304T |
| 46 | 682503-2 | SLEEVE PROTECTING_COVER X HM1500 |
| 48 | 158090-8 | CAP BLADE COMPL.X 5103R |
| 49 | 443098-8 | FELT X 5143R |
| 50 | 344263-1 | X PLATE 5143R |
| 51 | 316705-5 | COVER CAP BLADE CPL. X5103R |
| 52 | 266036-1 | M5X20 SCREW |
| 54 | 344261-5 | SHAFT CLOSE X 5103R |
| 55 | 233084-5 | COPRESSIONE OF SPRING 6 |
| 56 | 266034-5 | SCREW CT 4X16 |
| 57 | 687053-2 | CLAMP CABLE |
| 58 | 262007-6 | RING 8 X 5143R |
| 59 | 268008-2 | PIN 10 X 5143R |
| 60 | 211236-8 | BEARING 6002DDW X 5705R |
| 61 | 241889-9 | FAN 74 X 5143R |
| 62 | 415768-9 | CONVEYOR AIR X 5143R |
| 63 | 516653-0 | ARMATURE 220 / 240V X5103R |
| 64 | 911944-8 | SCREW M5X80 X 5103R |
| 65 | 596318-0 | STATOR X 5104S |
| 67 | 911288-6 | SCREW M5X65 X 5143R |
| 68 | 643710-2 | PLUG BRUSH XHM1500 |
| 69 | 191953-5 | CARBON BRUSHES CB-203 X 3612C |
| 70 | 158628-9 | CASING MOTOR X 5143R |
| 71 | 210042-8 | BEARING FOR 629LLB GD0600 |
| 72 | 681633-6 | WASHER |
| 73 | 316779-6 | PLATE ANGLE X5103R |
| 74 | 266039-5 | SCREW M6X6 |
| 75 | 265028-7 | M4X11 SCREW |
| 76 | 152511-2 | FULL PLATE X 5103R |
| 77 | 921477-5 | BOLT M8x55 |
| 78 | 415722-3 | GRIP GUIDE ANG. X5103R |
| 79 | 816128-2 | STOP X 5103R |
| 80 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 81 | 252626-6 | NUT M8 X SR2600 |
| 82 | 941201-0 | FLAT WASHER 8 |
| 83 | 265726-3 | SCREW M6x15 |
| 84 | 911108-4 | SCREW M4X8 X 5103R |
| 85 | 415433-0 | CATCH GUIDE |
| 86 | 256231-1 | PIN 6 |
| 87 | 266021-4 | 5X20 SCREW |
| 88 | 266039-5 | SCREW M6X6 |
| 89 | 265993-0 | SCREW M4x5 |
| 90 | 316706-3 | BASE X 5103R |
| 91 | 316708-9 | DRIVING DEPTH 'X 5103R |
| 92 | 951210-1 | PIN 6-20 |
| 93 | 921342-8 | HEXAGON BOLT 6X25 |
| 94 | 941151-9 | WASHER 6 X HM1303 |
| 95 | 252624-0 | NUT M6 |
| 96 | 651941-9 | SWITCH X LS1013 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
