Ama Petrol Lawnmower TRX-510Z Spare Parts
Ama genuine spare parts or replacements parts for to repair Petrol Self-Propelled Lawnmower TRX-510Z - 98920
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Ama Petrol Lawnmower TRX-510Z Spare Parts
Ama genuine spare parts or replacements parts for to repair Petrol Self-Propelled Lawnmower TRX-510Z - 98920.
Open PDF Diagram, check your spare part number position and then select it in the following table.
|
Petrol Self-Propelled Lawnmower TRX-510Z - 98920
|
||
|
Handle Pag.1
|
||
|
1
|
TRX-0094
|
Plastic Decoration
|
|
2
|
TRX-0081
|
Clutch Lever
|
|
3
|
TRX-0400
|
Brake Lever
|
|
4
|
TRX-0125
|
Limiting Stopper
|
|
5
|
TRX-0095
|
Plastic Decoration
|
|
6
|
TRX-0073
|
Foam Pipe
|
|
7
|
TRX-0176
|
Upper Handle
|
|
8
|
TRX-0083
|
Fixed Plate
|
|
9
|
TRX-0085 | Brake cable |
|
10
|
TRX-0086 | Clutch cable |
|
11
|
TRX-0088
|
Lower Handle
|
|
12
|
TRX-0076 | Control Handle |
|
13
|
TRX-0032
|
Pin
|
|
14
|
TRX-0078
|
Handle Pin
|
|
15
|
TRX-0077
|
Lever seat
|
|
16
|
TRX-0027
|
Flat Washer
|
|
17
|
TRX-0089
|
Knob
|
|
18
|
TRX-0093
|
Rope Guide
|
|
19
|
TRX-0091
|
Cable Support
|
|
20
|
TRX-0014
|
Bolt
|
|
21
|
TRX-0018
|
Nut
|
|
22
|
TRX-0015
|
Bolt
|
|
23
|
TRX-0092
|
Handle Plug
|
|
24
|
TRX-0019
|
Nut
|
|
Driver Pag.2
|
||
|
1
|
TRX-0402
|
Upper Cover of Left Panel
|
|
2
|
TRX-0177
|
Screw
|
|
3
|
TRX-0178
|
Spring
|
|
4
|
TRX-0405
|
Handle
|
|
5
|
TRX-0179
|
Cable
|
|
6
|
TRX-0017
|
Nut
|
|
7
|
TRX-0180
|
Bolt
|
|
8
|
TRX-0011
|
Screw
|
|
9
|
Standard
|
Screw
|
|
10
|
TRX-0408
|
Lower Cover of Left Panel
|
|
11
|
TRX-0025
|
Screw
|
|
12
|
Standard
|
Screw
|
|
13
|
TRX-0410
|
Upper Cover of Right Panel
|
|
14
|
TRX-0181
|
Bush
|
|
15
|
TRX-0182
|
Throttle control cable
|
|
16
|
TRX-0421
|
Lower Cover of Right Panel
|
|
17
|
TRX-0409
|
Handle panel
|
|
Chassis Pag.3
|
||
|
1
|
TRX-0005
|
Bolt
|
|
2
|
TRX-0160
|
Height Adjustment Plate
|
|
3
|
TRX-0134
|
Right bracket
|
|
4
|
Standard
|
Nut
|
|
5
|
TRX-0487
|
TW51S-L Chassis
|
|
6
|
TRX-0145 | Mulch plug |
|
7
|
TRX-0152
|
Cable Sleeve
|
|
8
|
Standard
|
Rubber O ring
|
|
9
|
TRX-0169
|
Washing Linker
|
|
10
|
TRX-0026
|
Screw
|
|
11
|
TRX-0135
|
Left bracket
|
|
12
|
TRX-0071
|
Rear Cover Support
|
|
13
|
TRX-0010
|
Screw
|
|
14
|
TRX-0133
|
Rear cover pedestal
|
|
15
|
TRX-0017
|
Nut
|
|
16
|
TRX-0072
|
Plug
|
|
17
|
TRX-0144
|
Rear Cover
|
|
18
|
TRX-0122
|
Rear Cover Spring
|
|
19
|
TRX-0121
|
Rear Cover Shaft
|
|
20
|
TRX-0025
|
Screw
|
|
21
|
TRX-0183
|
TW51 Front plate
|
|
22
|
TRX-0018
|
Nut
|
|
23
|
TRX-0184
|
Fixed Plate
|
|
24
|
Standard
|
Screw
|
|
25
|
TRX-0016
|
Nut
|
|
26
|
TRX-0168
|
Bracket
|
|
27
|
TRX-0006
|
Screw
|
|
28
|
TRX-0057
|
Side Discharge Cover Shaft
|
|
29
|
TRX-0058 | Side Discharge Cover Spring |
|
30
|
Standard
|
Screw
|
|
31
|
TRX-0061
|
Cover Plate
|
|
32
|
TRX-0062 | Spring |
|
33
|
TRX-0131 | Side Discharge Cover |
|
34
|
TRX-0060
|
Lock
|
|
35
|
TRX-0132 | Side-Discharge Guiding Board |
|
Traction Pag.4
|
||
|
1
|
TRX-0097
|
Height Adjustment Handle
|
|
2
|
TRX-0185
|
Rear Wheel Shaft Assy
|
|
3
|
TRX-0157
|
Inner Wheel Cover
|
|
4
|
TRX-0031
|
Spring Washer
|
|
5
|
TRX-0008
|
Screw
|
|
6
|
TRX-0001
|
Ball Bearing
|
|
7
|
TRX-0161
|
11" wheel
|
|
8
|
TRX-0028
|
Flat Washer
|
|
9
|
TRX-0021
|
Nut
|
|
10
|
TRX-0162
|
11" outer wheel cover
|
|
11
|
TRX-0038
|
Split Pin
|
|
12
|
TRX-0034 | Belt |
|
13
|
TRX-0104
|
Gear box
|
|
14
|
TRX-0102 | Fixed spring |
|
15
|
TRX-0103
|
Pin
|
|
16
|
TRX-0016
|
Nut
|
|
17
|
TRX-0433
|
Shaft Sleeve
|
|
17-1
|
TRX-0003
|
Ball Bearing
|
|
18
|
TRX-0007
|
Screw
|
|
19
|
TRX-0033
|
Lock Ring
|
|
20
|
TRX-0030
|
Flat Washer
|
|
21
|
TRX-0158 | Left Gear |
|
22
|
TRX-0159 | Right Gear |
|
23
|
TRX-0186
|
Connecting rod for front wheel
|
|
24
|
TRX-0018
|
Nut
|
|
25
|
TRX-0187
|
Symmetric bush
|
|
26
|
TRX-0188
|
Spring Washer
|
|
27
|
TRX-0189
|
Height adjustment connecting plate
|
|
28
|
TRX-0190
|
Height adjustment connecting pin plate
|
|
29
|
TRX-0191
|
T type bush
|
|
30
|
Standard
|
Bolt
|
|
31
|
TRX-0020
|
Nut
|
|
32
|
TRX-0192
|
Lock knob Assy
|
|
32-1
|
TRX-0193
|
Lock knob spring
|
|
32-2
|
TRX-0194
|
Lock knob pin
|
|
33
|
Standard
|
Bolt
|
|
34
|
TRX-0195
|
Lock upper cover
|
|
35
|
TRX-0196
|
Compression spring
|
|
36
|
TRX-0197
|
Lock limit pin
|
|
37
|
TRX-0198
|
Lock lower cover
|
|
38
|
TRX-0199
|
Left front wheel fixed assy
|
|
39
|
TRX-0480
|
Round pin
|
|
40
|
TRX-0481
|
Rotation axle
|
|
41
|
TRX-0002
|
Bearing
|
|
42
|
TRX-0111
|
8" Wheel
|
|
43
|
TRX-0482
|
Wheel axle
|
|
44
|
TRX-0114
|
8" Outer Wheel Cover
|
|
45
|
TRX-0483
|
Right front wheel fixed assy
|
|
46
|
TRX-0484
|
Front upper cover
|
|
47
|
TRX-0025
|
Screw
|
|
48
|
TRX-0485
|
Front lower cover
|
|
49
|
Standard
|
Bolt
|
|
50
|
TRX-0486
|
TW51 connecting rod
|
|
51
|
TRX-0108
|
Height Adjustment Spring
|
|
Grass Bag Pag.5
|
||
|
1
|
TRX-0142
|
Metal Bracket
|
|
2
|
Standard
|
Flat Washer
|
|
3
|
Standard
|
Screw
|
|
4
|
TRX-0143
|
Fixed plate
|
|
5
|
TRX-0139
|
Plastic Cover
|
|
6
|
TRX-0120
|
Cover Plate
|
|
7
|
TRX-0141
|
Hand Decoration Cover
|
|
8
|
TRX-0140
|
Indicated Board
|
|
9
|
TRX-0044
|
Fabric bag
|
|
Blade Pag.6
|
||
|
1
|
92625 (*)
|
Y196V ENGINE(Muffler side row)
|
|
2
|
TRX-0013
|
Screw
|
|
3
|
TRX-0040 | Flat Key |
|
4
|
TRX-0107 | Blade adapter |
|
5
|
TRX-0045 | Screw Cap |
|
6
|
TRX-0167 | Belt cover |
|
7
|
TRX-0024
|
Screw
|
|
8
|
TRX-0051 | Belt Cover Plate |
|
9
|
TRX-0052
|
Belt Cover Plate
|
|
10
|
TRX-0164
|
20" Blade
|
|
11
|
TRX-0119 | Blade Washer |
|
12
|
TRX-0004 | Blade Bolt |
|
13
|
Standard
|
Screw
|
|
Engine Pag.7
|
||
|
1
|
Standard
|
Bolt
|
|
2
|
TRX-0200
|
Engine cover
|
|
3
|
Standard
|
Nut M6
|
|
4
|
TRX-0201 | Recoil Start Assy |
|
5
|
TRX-0202
|
Blower Housing
|
|
6
|
TRX-0203
|
Bush
|
|
7
|
TRX-0205
|
Bolt I
|
|
8
|
TRX-0207
|
Bolt II
|
|
9
|
TRX-0209
|
Bolt III
|
|
10
|
TRX-0210
|
Nut M14x1.5
|
|
11
|
TRX-0212
|
Start-up Hub
|
|
12
|
TRX-0214
|
Fan
|
|
13
|
TRX-0216
|
Flywheel
|
|
14
|
Standard
|
Bolt M6x12
|
|
15
|
TRX-0218
|
Respirator Cover Plate
|
|
16
|
TRX-0220
|
Gasket of Respirator Cover
|
|
17
|
TRX-0222
|
Valve Element
|
|
18
|
TRX-0223
|
Lubricate Filtering Net
|
|
19
|
Standard
|
Bolt M6x10
|
|
20
|
TRX-0225
|
Back plate
|
|
21
|
Standard
|
Bolt M6x35
|
|
22
|
TRX-0227
|
Brake Assy
|
|
23
|
TRX-0228
|
Bush
|
|
24
|
Standard
|
Bolt M6x25
|
|
25
|
TRX-0229
|
Ignition
|
|
26
|
TRX-0232
|
Left plate
|
|
27
|
TRX-0234
|
Gasket of Cylinder Head
|
|
28
|
TRX-0233
|
Locating Pin
|
|
29
|
TRX-0237
|
Inlet valve
|
|
30
|
TRX-0238
|
Outlet valve
|
|
31
|
Standard
|
Spark Plug
|
|
32
|
TRX-0239
|
Gasket of Muffler
|
|
33
|
TRX-0383
|
Muffler Assy
|
|
34
|
TRX-0384
|
Muffler Cover Assy
|
|
35
|
Standard
|
Locknut M6
|
|
36
|
TRX-0246
|
Guide Board of Handspike
|
|
37
|
TRX-0248
|
Handspike Assy
|
|
38
|
TRX-0247
|
Rocker Support Bolt of Valve
|
|
39
|
TRX-0249
|
Oil Seal of valve
|
|
40
|
TRX-0252
|
Spring of Valve
|
|
41
|
TRX-0253
|
Spring Coil of outlet Valve
|
|
42
|
TRX-0256
|
Upper cap of outlet Valve
|
|
43
|
TRX-0251
|
Spring Coil of outlet Valve
|
|
44
|
TRX-0254
|
Rocker of Valve
|
|
45
|
TRX-0255
|
Adjust Nut of Valve
|
|
46
|
TRX-0257
|
Combined Nut
|
|
47
|
Standard
|
Bolt M8x50
|
|
48
|
TRX-0258 | Gasket of Cylinder Head Cover |
|
49
|
TRX-0262
|
Cylinder Head Inner Cover
|
|
50
|
TRX-0263
|
Cylinder Head Outer Cover
|
|
51
|
Standard
|
Bolt M6x14
|
|
52
|
TRX-0266
|
Cylinder Head Assy
|
|
53
|
Standard
|
Two Stud Bolt M6x92
|
|
54
|
TRX-0269
|
Paper Gasket of Inlet Pipe
|
|
55
|
TRX-0271
|
Air Inlet Pipe
|
|
56
|
TRX-0273
|
Paper Gasket of Carburetor
|
|
57
|
TRX-0389
|
Carburetor
|
|
58
|
TRX-0270
|
Paper Gasket of Air Filter
|
|
59
|
TRX-0369
|
Pedestal of air filter
|
|
60
|
TRX-0281
|
Exhuast Pipe φ8*φ12*140
|
|
61
|
Standard
|
O Ring φ6.5*φ15*0.5
|
|
62
|
TRX-0284 | Paper Filter Element |
|
63
|
TRX-0280
|
Filter Element
|
|
64
|
TRX-0282
|
Air Filter Upper Cover
|
|
65
|
TRX-0287
|
Fuel Tank Cap
|
|
66
|
TRX-0285
|
Seal Gasket of Fuel Tank Cap
|
|
67
|
TRX-0286
|
Connecting Rope
|
|
68
|
Standard
|
Bolt M6x22
|
|
69
|
TRX-0288
|
Gasket
|
|
70
|
TRX-0293
|
Fuel Tank
|
|
71
|
TRX-0294
|
Right Bracket of Fuel Tank
|
|
72
|
Standard
|
Locknut M6
|
|
73
|
TRX-0296
|
Left Bracket of Fuel Tank
|
|
74
|
TRX-0292
|
Filtering Net Duct of Fuel
|
|
75
|
Standard
|
Oil Pipe Circlip I
|
|
76
|
TRX-0299
|
Oil Pipe
|
|
77
|
Standard
|
Oil Pipe Fixing Clip
|
|
78
|
Standard
|
Oil Pipe Circlip II
|
|
79
|
TRX-0303
|
Crankcase Assy
|
|
80
|
TRX-0305
|
Speed Regulator Rocker Spindle
|
|
81
|
Standard
|
Flat Washer
|
|
82
|
TRX-0300
|
Oil Seal 6X11X4
|
|
83
|
TRX-0301
|
Springness Split Pin
|
|
84
|
TRX-0386
|
Spring
|
|
85
|
TRX-0381
|
Speed Regulator Assy
|
|
86
|
Standard
|
Bolt M6x12
|
|
87
|
TRX-0382
|
Plate
|
|
88
|
Standard
|
Screw
|
|
89
|
TRX-0388
|
Handspike of choke
|
|
90
|
TRX-0313
|
Handspike of Valve
|
|
91
|
TRX-0315
|
Spring of Valve
|
|
92
|
TRX-0307
|
Ttype Bolt M6*23
|
|
93
|
TRX-0385
|
Speed Regulator Rocker
|
|
94
|
TRX-0387
|
Speed Regulator Vice Spring
|
|
95
|
TRX-0345
|
Oil Seal 25x38x7
|
|
96
|
TRX-0311
|
Ball bearing
|
|
97
|
TRX-0324
|
Crankshaft Assy
|
|
98
|
TRX-0326
|
Connecting Rod Assy
|
|
99
|
TRX-0328
|
Circlip of Piston Pin
|
|
100
|
TRX-0330
|
Piston Assy
|
|
101
|
TRX-0332
|
Piston Pin
|
|
102
|
TRX-0334
|
Scraper Ring
|
|
103
|
TRX-0336
|
Bushing Ring
|
|
104
|
TRX-0337
|
Piston Ring II
|
|
105
|
TRX-0339
|
Piston Ring I
|
|
106
|
TRX-0341
|
Gasket of Gear
|
|
107
|
TRX-0343
|
Gasket of Crankcase
|
|
108
|
TRX-0344
|
Lubricating Gauge
|
|
109
|
TRX-0331
|
O-Ring
|
|
110
|
TRX-0347
|
Lubricating Pipe
|
|
111
|
TRX-0335
|
Locating Pin of Crankcase
|
|
112
|
TRX-0350
|
Locating Pin of Crankcase
|
|
113
|
Standard
|
O Ring φ21xφ2.3
|
|
114
|
TRX-0338
|
Draining Oil Bolt
|
|
115
|
TRX-0340
|
Draining Oil Bolt Gasket
|
|
116
|
TRX-0354
|
Crankcase Cover
|
|
117
|
TRX-0355
|
Oil seal 25x40x7
|
|
118
|
TRX-0356
|
Tappet
|
|
119
|
TRX-0357
|
Camshaft Assy
|
|
120
|
TRX-0349
|
Gear Shaft Hold-down Plate
|
|
121
|
TRX-0351
|
Sliding Sleeve
|
|
122
|
TRX-0352
|
Gear Shaft Assy
|
|
123
|
TRX-0358
|
Circlip of Gear shaft
|
