Annovi Reverberi Genuine spare parts or replacement parts for to fix Pressure Washer Blue Clean AR757 - 12363.
In the following tables, look for the spare part and its respective code.![]()
| Pressure Washer Blue Clean AR757 - 12363 | ||
| Casing 757 Pag.1 | ||
| # | Part Num. | Description |
| 1 | 2500045 | Blue Casing |
| 2 | 2500340 | Stopper |
| 3 | 2500310 | Knob |
| 4 | 2500050 | Hook |
| 5 | 2500260 | Bowl |
| 6 | 1680880 | Washer |
| 7 | 2500320 | Wheel |
| 8 | 1260780 | Screw |
| 9 | 2500100 | Plate |
| 10 | 320350 | Screw |
| 11 | 2100300 | Screw |
| 12 | 2600100 | Gland |
| 13 | 2100300 | Screw |
| 14 | 2500020 | Handle |
| 15 | 2500130 | Rubber |
| 16 | 880280 | Screw |
| 17 | 2180300 | Washer |
| 18 | 2500120 | Axle |
| 19 | 2500110 | Tank |
| 20 | 2500010 | Basis |
| 21 | 1342040 | Fan Cover |
| 22 | 42113 | Pre-Assembly Cap |
| 23 | 2500330 | Pipe Cleaner |
| 24 | 2500330 | Pipe Cleaner |
| 25 | 2000230 | Filter |
| 26 | 2509000 | Pre-Assembly Base |
| Pump 757 Pag.2 | ||
| 1 | 1260780 | Screw |
| 2 | 1344060 | Cover |
| 3 | 1040710 | O-Ring |
| 4 | 1260050 | Bushing |
| 5 | 1344050 | Pump Housing |
| 7 | 1340170 | Tree |
| 8 | 880111 | Tongue |
| 9 | 1341070 | Bearing |
| 10 | 480890 | Ring |
| 11 | 111120 | Ring |
| 12 | 1341080 | Ring |
| 13 | 1340060 | Piston Rod |
| 14 | 1340080 | Plug |
| 15 | 1340070 | Piston |
| 16 | 1260460 | Oil Seal |
| 17 | 600180 | O-Ring |
| 18 | 1341010 | Disk |
| 19 | 1342740 | Piston |
| 20 | 1341020 | Washer |
| 21 | 850670 | Screw |
| 22 | 600180 | O-Ring |
| 25 | 1349265 | Pre-Assembly Pump |
| 26 | 1260440 | Tenuta Water |
| 27 | 770260 | O-Ring |
| 28 | 1342730 | Piston Guide |
| 29 | 1342760 | Tenuta Water |
| 30 | 1342720 | Ring |
| 31 | 1342750 | Disk |
| 32 | 1349053 | Valve |
| 33 | 800560 | O-Ring |
| 34 | 390341 | O-Ring |
| 35 | 1343110 | O-Ring |
| 36 | 1342710 | Nozzle |
| 37 | 1460430 | O-Ring |
| 38 | 1460260 | Piston |
| 39 | 1540140 | Spring |
| 40 | 880270 | O-Ring |
| 41 | 1560090 | Junction |
| 42 | 770570 | O-Ring |
| 43 | 2500190 | Stopper |
| 44 | 1461470 | Junction |
| 45 | 1340260 | Filter |
| 47 | 881470 | Screw |
| 48 | 680700 | Screw |
| 49 | 480480 | O-Ring |
| 50 | 1340190 | Cover |
| 51 | 780050 | O-Ring |
| 52 | 620301 | Cap |
| 53 | 1342670 | Head |
| 54 | 851100 | Screw |
| 55 | 1250270 | Spring |
| 56 | 1250280 | Sphere |
| 58 | 3226 | Manometer |
| 59 | 1342700 | Office |
| 60 | 1460430 | O-Ring |
| 61 | 1460150 | Piston |
| 62 | 1343810 | Tablet |
| 63 | 740290 | O-Ring |
| 64 | 1260670 | Junction |
| 66 | 1342680 | Cover |
| 67 | 1381550 | Washer |
| 68 | 1343510 | Screw |
| 69 | 1080190 | O-Ring |
| 70 | 2021900 | Piston |
| 71 | 2500330 | Pipe Cleaner |
| 72 | 1080401 | Ring |
| 73 | 1343450 | Disk |
| 74 | 1460190 | Spring |
| 75 | 1343000 | Disk |
| 76 | 2500400 | Insert |
| 77 | 1060120 | Nut |
| 78 | 2500480 | Screw |
| 79 | 2500210 | Knob |
| 80 | 1343900 | Stopper |
| 81 | 880840 | O-Ring |
| 82 | 2180740 | Ferrule |
| 83 | 2500280 | Curve |
| 84 | 480560 | O-Ring |
| 85 | 2500200 | Junction |
| 86 | 42391 | Pre-Assembly Head |
| 87 | 42520 | Kit Valve Adjustment |
| A | 1880 | Kit Valves |
| B | 2623 | Piston Kit |
| C | 1876 | Kit Oil Seals |
| E | 2624 | Kit Kept Water |
| F | 2767 | Gasket Kit |
| Engine 757 Pag.3 | ||
| 1 | 1260300 | Fan |
| 2 | 1340350 | Estate |
| 3 | 1260760 | Screw |
| 4 | 1340320 | Shield |
| 5 | 1340340 | Bearing |
| 6 | 1269100 | Clamp |
| 7 | 1340780 | Gasket |
| 8 | 1340480 | Box |
| 9 | 1261560 | Screw |
| 10 | 1263520 | Condenser |
| 11 | 1340280 | Band |
| 12 | 1260810 | Screw |
| 13 | 2320280 | Switch |
| 16 | 1760450 | Cable |
| 17 | 4919 | Engine |
| 18 | 1340660 | Fairlead |
| 19 | 1340640 | Ferrule |
| 20 | 1340650 | Fairlead |
| Accessories 757 Pag.4 | ||
| 1 | 40925 | Gun |
| 2 | 40030 | Lancia + Head |
| 3 | 1271350 | High Pressure Hose |
| 4 | 2000770 | O-Ring |
