Makita Spare parts for Cordless Chain Saw DUC254
€6.06
Tax included
Makita Spare parts for Cordless Chain Saw DUC254
Makita original spare parts, at discounted prices, we are a licensed service center with after-sales service able to quickly solve the maintenance and repair any issues for Cordless Chain Saw DUC254 - 254C.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare parts for Cordless Chain Saw DUC254
Makita original spare parts, at discounted prices, we are a licensed service center with after-sales service able to quickly solve the maintenance and repair any issues for Cordless Chain Saw DUC254 - 254C.
In the following table, look for the model of the Cordless Chain Saw and the respective parts of the code.
| DUC254 - 254C 250MM CORDLESS CHAIN SAW Pag.1 |
||
| # | Part Num. | Description |
| 001 | 458490-5 | SIDE HANDLE |
| 002 | 183J27-6 | HOUSING SET |
| C10 | 263005-3 | RUBBER PIN 6 |
| 003 | 266326-2 | TAPPING SCREW 4X18 |
| 004 | 266041-8 | TAPPING SCREW 5X25 |
| 005 | 168508-1 | TANK CAP COMPLETE |
| 006 | 213355-6 | O-RING 25 |
| 007 | 421959-2 | SPONGE SEAL |
| 008 | 140A75-4 | OIL TANK COMPLETE |
| 009 | 422271-3 | CONNECTOR A |
| 010 | 422272-1 | CONNECTOR B |
| 011 | 450437-5 | FILTER |
| 012 | 424612-9 | GROMMET |
| 013 | 266041-8 | TAPPING SCREW 5X25 |
| 014 | 458489-0 | MOTOR HOUSING |
| 015 | 142857-4 | OIL PUMP COMPLETE |
| 016 | 266326-2 | TAPPING SCREW 4X18 |
| 017 | 210026-6 | BALL BEARING 696ZZ |
| 018 | 961006-2 | RETAINING RING S-10 |
| 019 | 221428-1 | WORM GEAR |
| 020 | 619518-6 | ROTOR |
| 022 | 266326-2 | TAPPING SCREW 4X18 |
| 023 | 629378-8 | STATOR COMPLETE |
| 024 | 210059-1 | BALL BEARING 6000DDW |
| 025 | 962105-3 | RETAINING RING R-26 |
| 026 | 458497-1 | CATCH LEVER |
| 027 | 651365-9 | SWITCH C3JW-6BM-P |
| 028 | 233476-8 | COMPRESSION SPRING 4 |
| 029 | 458495-5 | SWITCH LEVER |
| 030 | 632L49-0 | SWITCH UNIT |
| 031 | 632L48-2 | SWITCH UNIT |
| 032 | 141J61-2 | CONTROLLER COMPLETE |
| C10 | 810D46-0 | SWITCH LABEL |
| 033 | 140A71-2 | FRONT HAND GUARD COMPLETE |
| C10 | 816U30-5 | CAUTION LABEL |
| 034 | 232453-7 | COMPRESSION SPRING 3 |
| 035 | 310879-4 | HAND GUARD GUIDE |
| 036 | 643874-2 | TERMINAL |
| 037 | 347377-5 | HOOK SUPPORT |
| 038 | 281222-3 | HOOK |
| 039 | 183J27-6 | HOUSING SET |
| C10 | 263005-3 | RUBBER PIN 6 |
| 040 | 422270-5 | GROMET |
| 041 | 227620-7 | DRIVE GEAR |
| 042 | 227634-6 | STRAIGHT BEVEL GEAR 14 |
| 043 | 455241-7 | CLAMP SCREW |
| 044 | 347376-7 | TENSION SLIDE |
| 045 | 327120-8 | ADJUST SCREW |
| 046 | 227496-2 | STRAIGHT BEVEL GEAR 14 |
| 047 | 455242-5 | CLAMP SCREW |
| 048 | 458491-3 | HOUSING R COVER |
| 049 | 266326-2 | TAPPING SCREW 4X18 |
| 050 | 140A74-6 | LINK PLATE COMPLETE |
| 051 | 232452-9 | COMPRESSION SPRING 7 |
| 052 | 347372-5 | BRAKE BAND |
| 053 | 161871-1 | BRAKE DRUM COMPLETE |
| 054 | 213060-5 | O RING 10 |
| 055 | 221464-7 | SPROCKET 6 |
| 055 | 198259-2 | SPROCKET 9 1/4" - CARVING |
| 056 | 961013-5 | STOP RING E-7 |
| 057 | 347567-0 | GUIDE PLATE L |
| 058 | 347373-3 | CHAIN CATCHER |
| 059 | 266905-6 | H.L. SOCKET HEAD BOLT M5X12 |
| 060 | 266388-0 | TAPPING SCREW 5X16 |
| 061 | 266007-8 | TAPPING SCREW BIND PT 3X10 |
| 062 | 347375-9 | GUIDE PLATE R |
| 063 | 136010-2 | SPROCKET COVER ASS'Y |
| 063-1 | 136010-2 | SPROCKET COVER ASS'Y |
| 063-2 | 136036-4 | SPROCKET COVER ASS'Y |
| 064 | 162494-8 | FRANGE NUT COMPLETE |
| 064-1 | 162494-8 | FLANGE NUT COMPLETE |
| 065 | 458499-7 | NUT COVER |
| 066 | 854G31-1 | DUC254 NAME PLATE |
| 067 | 816U21-6 | DUC254 MODEL NO. LABEL |
| 068 | 854G38-7 | DUC254 SERIAL NO. LABE |
| 070 | 422310-9 | CHIP GUIDE |
| 071 | 458493-9 | SPROCKET COVER |
| Accessories Pag.2 | ||
| A01 | 161846-0 | GUIDE BAR 10 |
| A02 | 458501-6 | GUIDE BAR CASE |
| A03 | 199075-5 | SAW CHAIN SET |
| A04 | 782023-7 | WRENCH 13-16 |
| A09 | 831304-7 | ACCESSORY BAG |
| A10 | 191G22-4 | SPROCKET NOSE BAR 3/8" X 1,3MM X 25CM |
| A11 | 191H00-0 | CHAIN LOOP 90PX-1,1MM 3/8"40 LINKS |
| A12 | 168407-7 | CARVING BAR 25CM SP.1,3MM |
| A13 | 512466060 | MICRO CHISEL CAHIN LINKS 60 15,60 |
