Makita Spare Parts for Electric Chainsaw UC3010A
search
  • Makita Spare Parts for Electric Chainsaw UC3010A
  • Makita Spare Parts for Electric Chainsaw UC3010A
  • Makita Spare Parts for Electric Chainsaw UC3010A
  • Makita Spare Parts for Electric Chainsaw UC3010A

Makita Spare Parts for Electric Chainsaw UC3010A

€1.43
Tax included

Makita Spare Parts for Electric Chainsaw UC3010A

We supply original Makita spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Electric Chainsaw for Wood UC3010A.
ITEM CODE: 913540185
Quantity
on 7/10 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Electric Chainsaw UC3010A

We supply original Makita spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Electric Chainsaw for Wood UC3010A.

In the following table, look for the model of the Electric Saws and the respective parts of the code.


UC3010A - ELECTRIC CHAINSAW 30CM MAKITA 1500W pag.1
1 416711-1 CASE LEFT CPL UC3010A/ES31A
2 416713-7 COVER WITH TUBULAR HANDLE ES-31A
3 913540185 SCREW 4X18 UC3000-3500-4000A
5 416707-2 HAND GUARD UC3010A ES-31A
6 266181-2 SCREW 5 X 16
7 924605510 WASHER ES-31A
8 210213030 SPRING FOR HAND GUARD UC3010A ES-31A
9 416708-0 SWITCH BUTTON UC3101A X UC3020A
10 416178-3 LOCKING BUTTON X UC3020A
11 233173-6 COMPRESSION SPRING 4 FOR UC3020A
12 975001200 PUSH BUTTON ES-31A
15 416714-5 GUIDE PLATE ES-31A
16 970803390 ARMATURE ASS'Y 220-240V ES-31A
17 634313-3 STATOR AAS'Y ES-31A
18 632891-7 CONNECTING BOARD COMP UC3010A   ES-31A
20 266029-8 SCREW M5X65
21 970109820 CAPACITOR 160MM UC3010A ES-31A
22 970001200 SWITCH X UC3000-3500-4000A
23 632890-9 CABLE WITH PLUG ES-31A
26 682574-9 BREAK PROTECTION 10-90 PC5000C
UC3010A - ELECTRIC CHAINSAW 30CM MAKITA 1500W pag.2
1 210211100 GEAR PLATE CPL. X ES
2 210221100 GEAR CPL UC3010A ES-31A
3 210114021 OIL TANK ES-31A
6 021245007 OIL PUMP
7 203245002 OIL PUMP HOLDER X DES
8 915735100 SCREW X DCS3400TH
9 965451210 CONNECTION FOR OIL PUMP ES-31A
10 231975-4 PRESSURE SPRING X DCS230T
11 416274-7 OIL PIPE CAP X DCS230T
12 965452388 TUBE ES-31A
13 963203010 O-RING 3,5X1 ES-31A
14 925305000 WASHER ES-31A
18 210213300 BRAKE SPRING HOLDER CPL. ES-31A
19 210213500 BRAKE SPRING ES-31A
20 210213020 BRAKE RING X ES-31A
21 210213050 SPRING ES-31A
22 028213521 SPRING X UC3000-3500-4000A
23 267195-4 WASHER 4 X DCS230T
25 210271080 SWITCH ROD UC3010A ES-31A
27 210110620 CASE RIGHT CPL UC3010A ES-31A
28 980114181 LABEL DES300/350/400 ES-31A
30 913540185 SCREW 4X18 UC3000-3500-4000A
31 001213042 NUT WITH PIVOT DCS34/PS34 X PS 34
32 901505354 SCREW M5X35 X UC
35 930108100 WASHER ES-31A SAFETY
37 264055-1 NUT M8
UC3010A - ELECTRIC CHAINSAW 30CM MAKITA 1500W pag.3
1 442030611 SPROCKET NOSE BAR 12" 30 cm 3/8" 1.1 mm ES-31A
2 511291746 EXTRAGUARD SAW CHAIN 3/8 46 LINKS
3 510090010 TIE STRAP WITH RIVETS ES-31A
4 510090030 SAFETY TIE STRAP ES-31A
5 952010640 CHAIN PROTECTION 40CM
6 941713001 UNIVERSAL KEY X DES380
8 442030661 SPROCKET NOSE BAR 0.50" 30CM 3/8" 12" TH.1.3MM
10 511492746 EXTRAGUARD SAW CHAIN 0.50" 30CM 3/8" 12" TH.1.3MM LINKS 46
11 558092010 TIE STRAP WITH RIVETS 3/8" 0.50"
12 558092000 SAFETY TIE STRAP ES-31A

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
