Makita Spare Parts for Brusch Cutter RBC311
We are MAKITA original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Brusch Cutter RBC311.
In the following table, look for the model of Brusch Cutter and the respective parts of the code.
| Brusch Cutter RBC311 | ||
| # | Part Num. | Description |
| 7 | 6407003000 | BAND X RBC 310 |
| 8 | 0011706300 | BOLT M6X30 X RBK250-RBC225- |
| 9 | 6418500302 | GUARD X RBK250-RBC225 |
| 12 | 6254004000 | HOLDER CPL RBC260 / 230/310 |
| 13 | 6251005001 | DAMPER X RBC 310 |
| 14 | 6251505501 | CLUTCH HOUSING X RBC 310 |
| 16 | 6251501300 | WASHER X RBC 310 |
| 17 | 0031512000 | RING X RBC260 / 520RBK410 |
| 18 | 0600129950 | BALL BEARING X RBC260 |
| 19 | 0031432000 | INNER SNAP RING RBC260 / 310/410 |
| 20 | 6251025000 | COMPLETE SHAFT X RBC 310 |
| 22 | 267429-5 | WASHER 6 |
| 23 | 6402500100 | CLUTCH SHOE X RBC310 |
| 24 | 267817-6 | WASHER 8 EBH252L |
| 26 | 6252500500 | CLUTCH BOLT X RBC415 |
| 27 | 0119059950 | M5X18 BOLT XRBC230 / 310/225 / |
| 28 | 0119059880 | BOLT X RBC 310 |
| 30 | 6251002000 | PIPE SHAFT COMP X RBC 310 |
| 33 | 0031424000 | INNER SNAP RING XRBC260-230-225- |
| 34 | 6253502600 | OUTER SNAP RING X RBC310 / RBK410 |
| 35 | 210049-4 | EBH252L 609ZZ BEARING |
| 36 | 6253005000 | SHAFT SET X RBC310 / RBK410 |
| 38 | 0011306120 | M6X12 X RBC310 / 520 BOLT |
| 39 | 6253004001 | GEARBOX X RBC310 / RBK410 |
| 40 | 266671-5 | OIL CAP |
| 41 | 412099-7 | GUARD X DECESP. |
| 42 | 922213-2 | SCREW M5X12 EBH341U |
| 43 | 6253500200 | BALL BEARING 627 |
| 44 | 0600109990 | BALL BEARING 6200 |
| 45 | 6253501300 | SPACER |
| 46 | 0031430000 | INNER SNAP RING X RBC310 / RBK410 |
| 47 | 6253501100 | OIL GASKET X RBC310 / K410 |
| 48 | 6258503600 | UPPER FLANGE RBC310 / K410 |
| 49 | 6258500001 | CLAMP WASHER X RBC 310 / RBK410 |
| 50 | 0203089990 | SPRING WASHER X RBC260 / 230RBK410 |
| 51 | 264018-7 | NUT M8 RBC2510 |
| 102 | 266573-5 | SCREW M5X33 EBH341U |
| 103 | 6215500100 | CONTROL CABLE X RBC 260 |
| 105 | 6214500400 | HANDLE X RBC230 / RBK 410 |
| 106 | 6255018000 | CONTROL LEVERS X RBK410 |
| 107 | 0022705000 | NUT M5 X RBC230 / 310 / RBK410 |
| 54 | 0140059920 | SCREW 5X8 X RBC 310 |
| 55 | 0140059920 | SCREW 5X8 X RBC 310 |
| 57 | 0031005000 | WASHER X RBC230 / 410 / RBK410 |
| 59 | 5313500600 | GASKET MUFFLER X RBC 310 |
| 60 | 5313500300 | MUFFLER COVER |
| 62 | 0119059730 | X RBC BOLT 260/230/225/255 |
| 64 | 0053203101 | WOODRUFF RBC / RBK 410 |
| 65 | 5312500400 | PIN / RBC 310 |
| 66 | 233976-8-4 | PIN WITH EBH252L RING (4pcs) |
| 67 | 054002-10 | SPARK PLUG NGK - BM7A |
| 68 | 324891-8 | SPRING X RBC260 / 230RBK410 |
| 69 | 5317500200 | SPARK PLUG CAP X RBC260 310 |
| 70 | 5315501800 | CARTER X RBC 310 |
| 71 | 0140059920 | SCREW 5X8 X RBC 310 |
| 72 | 319255-9 | CYLINDER |
| 73 | 0119059730 | X RBC BOLT 260/230/225/255 |
| 74 | 5313500500 | ISOLATOR X RBC 310 |
| 76 | 0119059950 | M5X18 BOLT XRBC230 / 310/225 / |
| 77 | 5982500200 | PISTON RING X RBC 230/310 |
| 78 | 319248-6 | PISTON |
| 79 | 233976-8-4 | PIN WITH EBH252L RING (4pcs) |
| 80 | 5311500301 | CYLINDER GASKET X MS2810 |
| 81 | 0610089990 | NEDDLE BEARIG X RBC260 / 230/310 / |
| 83 | 0600129920 | BEARING MS5250 |
| 84 | 0440129991 | OIL SEAL X RBC415 |
| 85 | 5315500400 | STARTING WHEEL X RBC 310 |
| 86 | 6202006000 | X RBC310 BOLT |
| 89 | 5505001030 | FRICTION PLATE |
| 90 | 5105015020 | RATCHET RBC 310 / RBC520 |
| 91 | 5105015060 | RETURN SPRING X RBC310 / RBC520 |
| 92 | 5105015050 | CLUTCH SPRING X RBC 310/520 |
| 93 | 5025001010 | REEL X RBC 310 |
| 94 | 5105015040 | STARTER SPRING X RBC 310 |
| 96 | 5315001020 | STARTING KNOB X RBC 310 |
| 98 | 0119059950 | M5X18 BOLT XRBC230 / 310/225 / |
| 99 | 452920-8 | TANK CAP |
| 100 | 5316500400 | TANK BAND SPACER X RBC 310 |
| 101 | 5316500200 | DAMPER X RBC 310 |
| 103 | 0600129920 | BEARING MS5250 |
| 104 | 5311500400 | GASKET X RBC 310 |
| 105 | 5316500200 | RUBBER X RBC 310 |
| 106 | 0440129991 | OIL SEAL X RBC415 |
| 107 | 5317004010 | FLYWHEEL X RBC 310 |
| 108 | 0200069920 | WASHER M6 X RBC310 / 410 / RBK410 |
| 109 | 0032006000 | ELASTIC WASHER X RBC / RBK410-G2400R |
| 110 | 0011606160 | SCREW X RBC 310 |
| 113 | 0119059730 | X RBC BOLT 260/230/225/255 |
| 115 | 346286-5 | SUPPORT X RBC 310 |
| 116 | 922213-2 | SCREW M5X12 EBH341U |
| 117 | 0851169971 | TUBE X RBC260 / 310 |
| 118 | 0561080010 | STOP TUBE X RBC 260 / RBC520 |
| 119 | 163447-0 | FUEL FILTER X DCS230T |
| 120 | 5316502100 | TANK RBC 310 |
| 122 | 5236018040 | SWIVEL XRBC230-260-310-225- |
| 123 | 5206008110 | PIN / RBC 260/230/310/225 |
| 125 | 5316005450 | CABLE ADJUST NUT RBC260 / 310 |
| 126 | 5216008010 | SCREW REG CABLE ACC.XRBC260 310 |
| 128 | 5236018010 | THROTTLE VALVE ASS'Y RBC230 -310 |
| 129 | 5316005120 | RING X RBC 260/230/310/225/2 |
| 130 | 5216010000 | CARBURETOR X RBC230 / 310 |
| 131 | 5246001010 | GASKET X RBC 260/230/310 / |
| 132 | 5036002010 | JET X RBC230 / 310/225/255 |
| 133 | 5246001030 | PUMP GASKET RBC260-230-310- |
| 134 | WJ00009599 | PUMP DIAPHRAGM X DCS230T |
| 135 | 5236046130 | BODY PUMP CPL X RBC350-RBC42 |
| 136 | 442154-1 | DIAPHRAGM EBH341U GASKET |
| 137 | 168574-8 | CPL DIAPHRAGM EBH341U |
| 138 | 5236046060 | CPL AIR FILTER BODY RBC350 |
| 139 | 424314-7 | PRIMING PUMP EBH341 |
| 140 | 5236046050 | PUMP COVER X RBC350-RBC42 |
| 141 | 266582-4 | SCREW 3X24 EBH341U |
| 142 | 5016004010 | INLET SCREEN X RBC 260/230/310/225 |
| 143 | 0022705000 | NUT M5 X RBC230 / 310 / RBK410 |
| 144 | 5236018020 | GASKET X RBC 260/230 / 310 |
| 145 | 5213500400 | FILTER COVER X RBC 260/230/230 |
| 146 | 454831-3 | LEVER |
| 147 | 423376-2 | GASKET EBH341U |
| 148 | 0230059970 | SPACER X RBC 260/230/310 |
| 149 | 5013501400 | AIR CLEANER PLATE X RBC 260/230/310 |
| 150 | 0140059730 | SCREW M5X50 X RBC260 / 310 |
| 151 | 5213500700 | AIR CLEANER ELEMENT RBC230 / 260/310 |
| 152 | 5213500501 | AIR CLEANER CASE COVER 260/230/310 |
| 153 | 0043605120 | SCREW M5X12 X RBC 260/230/310 |
| 204 | 0717049990 | HEX. WRENCH RBC350-RBC420 |
