Makita Electric Lawn Mower ELM4121 Spare Parts
€37.93
Tax included
Makita Electric Lawn Mower ELM4121 Spare Parts
MAKITA Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and fix issues for Electric Lawn Mower ELM4121.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Electric Lawn Mower ELM4121 Spare Parts
MAKITA Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and fix issues for Electric Lawn Mower ELM4121.
In the following table, look for the model of Lawn Mower and the respective parts of the code.
| ELM4121 410MM ELECTRIC LAWN MOWER pag.1 | ||
| # | Part Num. | Description |
| 1 | YA00000958 | UPPER HANDLE BAR ASSY |
| 2 | YA00001187 | SPONGE GRIP |
| 3 | YA00000959 | SWITCH LEVER |
| 4 | YA00000765 | SWITCH BOX RIGHT |
| 5 | YA00000766 | SWITCH LINK BUTTON |
| 6 | YA00000767 | COMPRESSION SPRING 16.8 |
| 7 | YA00000768 | SWITCH LEVER END CAP RIGHT |
| 8 | 652024721 | SELF DRILLING SCREW 3.5X10 |
| 9 | YA00000769 | SWITCH TORSION SPRING 21 |
| 10 | YA00000778 | SELF TAPPING SCREW ST4X16 |
| 11 | YA00000780 | CORD CLAMP |
| 12 | YA00000914 | POWER SUPPLY CORD ASSY |
| 13 | YA00000781 | INDICATOR LENZ |
| 14 | YA00000778 | SELF TAPPING SCREW ST4X16 |
| 15 | YA00000780 | CORD CLAMP |
| 16 | YA00000773 | POWER SUPPLY CORD ASSY (EURO) 220V |
| 17 | 652023811 | CABLE HANGER |
| 18 | YA00000772 | SWITCH |
| 19 | YA00000782 | SWITCH BOX LEFT |
| 20 | YA00000778 | SELF TAPPING SCREW ST4X16 |
| 21 | 652023795 | SPRING BOX RIGHT |
| 22 | 652024721 | SELF DRILLING SCREW 3.5X10 |
| 23 | 652023794 | SWITCH LEVER END LEFT |
| 24 | YA00000737 | TORSION SPRING |
| 25 | 652023793 | SPRING BOX LEFT |
| 26 | YA00000778 | SELF TAPPING SCREW ST4X16 |
| 27 | YA00000785 | SELF TAPPING SCREW ST4X25 |
| 28 | YA00000921 | CABLE CLIP |
| 29 | YA00000960 | SELF TAPPING SCREW ST3X12 |
| 30 | YA00000961 | ANGLE ADJUSTMENT JOINT UPPER |
| 31 | YA00000975 | TENSION LEVER ASSY |
| 32 | YA00000976 | CONICAL SPRING |
| 33 | YA00000977 | ANGLE ADJUSTMENT JOINT LOWER |
| 34 | YA00000960 | SELF TAPPING SCREW ST3X12 |
| 35 | YA00000802 | HEX.FRANGE CAP NUT M6 |
| 36 | YA00000974 | LOWER HANDLE ASSEMBLY |
| 37 | YA00000970 | CABLE GUIDE RING |
| 38 | YA00000971 | RUBBER SHEET |
| 39 | YA00000971 | RUBBER SHEET |
| 40 | YA00000972 | CABLE GUIDE CLAMP |
| 41 | YA00000873 | SELF TAPPING SCREW ST4X12 |
| 42 | YA00000973 | SELF TAPPING SCREW ST3X16 |
| 44 | YA00000983 | SQUARE NECKED BOLT M8X40 |
| 45 | YA00000996 | RIGHT HANDLE BRACKET |
| 46 | YA00000803 | M8 KNOB |
| 47 | YA00001001 | LEFT HANDLE BRACKET |
| 48 | YA00000997 | CABLE CLAMP |
| 49 | YA00000998 | PAN HEAD SCREW M6X8 |
| 50 | YA00000995 | H.S.TRUSS HEAD SCREW M8X16 |
| ELM4121 410MM ELECTRIC LAWN MOWER pag.2 | ||
| 51 | YA00001008 | AIR INTAKE PLATE RIGHT BULE |
| 52 | YA00001010 | SPONGE SHEET |
| 53 | YA00001006 | MOTOR HOOD UPPER BLUE |
| 54 | YA00001011 | SPONGE SHEET |
| 55 | YA00001012 | AIR INTAKE PLATE LEFT BLUE |
| 56 | YA00000638 | PAN HEAD SCREW M5X14 |
| 57 | YA00001174 | CABLE TIE |
| 58 | YA00001173 | HEAT SHRINKABLE TUBE |
| 59 | YA00001181 | LEAD WIRE SET |
| 60 | YA00000928 | MOTOR ASSY 230V |
| 61 | YA00000813 | SELF TAPPING SCREW ST4X10 |
| 62 | YA00000814 | CARBON BRUSH 2PICS SET |
| 63 | YA00001183 | MOTOR FRAME & PULLEY ASSY |
| 64 | YA00000806 | SELF TAPPING SCREW ST5X20 |
| 65 | YA00001180 | LIBED BELT |
| 66 | 652023843 | NYLON INSERT HEX. LOCK NUT M8 |
| 67 | YA00001184 | BELT COVER |
| 68 | YA00000806 | SELF TAPPING SCREW ST5X20 |
| 69 | YA00000778 | SELF TAPPING SCREW ST4X16 |
| 70 | YA00001034 | CORD CLAMP |
| 71 | YA00000992 | REAR FLAP BLUE |
| 72 | YA00000990 | STOP RING E-5 |
| 73 | YA00000991 | REAR FLAP HINGE ROD |
| 74 | YA00000994 | REAR FLAP TORSION SPRING 7.7 |
| 75 | YA00000999 | REAR FLAP MOUNT BLUE |
| 76 | YA00000794 | SELF TAPPING SCREW ST4X14 |
| 77 | YA00001002 | HEIGHT ADJUSTER STOP PLATE |
| 78 | YA00000638 | PAN HEAD SCREW M5X14 |
| 79 | YA00000393 | NYLON INSERT HEX. LOCK NUT M5 |
| 80 | YA00001032 | HEX. FLANGE BOLT M5X12 |
| 81 | YA00001003 | DECK |
| 82 | YA00001019 | FRONT HOOD BLUE |
| 83 | YA00001021 | FRONT AXLE COVER |
| 84 | YA00000778 | SELF TAPPING SCREW ST4X16 |
| 85 | YA00000794 | SELF TAPPING SCREW 4X14 |
| 86 | YA00001030 | SELF TAPPING SCREW 5X20 |
| 87 | YA00001030 | SELF TAPPING SCREW 5X20 |
| 88 | YA00001015 | BELT COVER RETAINER |
| 89 | YA00001016 | HEX. SOCKET HEAD BOLT M8X35 |
| 90 | YA00001029 | SPACER RING 16 |
| 91 | YA00000890 | BLADE SUPPORT |
| 92 | YA00000734 | BLADE 41 |
| 93 | YA00000891 | CLAMP WASHER 8 |
| 94 | YA00000827 | HEX. BOLT M8X25 |
| ELM4121 410MM ELECTRIC LAWN MOWER pag.3 | ||
| 95 | YA00000925 | WHEEL CAP 7INCH 178 |
| 96 | 652023843 | NYLON INSERT HEX. LOCK NUT M8 |
| 97 | YA00000420 | WASHER |
| 98 | YA00000926 | WHEEL 8INCH 200 |
| 99 | YA00000989 | HEIGHT ADJUST GRIP |
| 100 | YA00000988 | PAN HEAD SCREW M4X12 |
| 101 | YA00000987 | HEIGHT ADJUST LEVER |
| 102 | YA00000407 | HEX. FLANGE BOLT M5X16 |
| 103 | YA00000407 | HEX. FLANGE BOLT 5X12 |
| 104 | YA00000986 | HEIGHT ADJUST SPRING |
| 105 | YA00000393 | NYLON INSERT HEX. LOCK NUT M5 |
| 106 | YA00000985 | REAR AXLE |
| 107 | YA00000393 | NYLON INSERT HEX. LOCK NUT M5 |
| 108 | YA00000851 | PIN 7 |
| 109 | YA00001017 | CONNECTING ROD |
| 110 | YA00001018 | PIN 7 |
| 111 | YA00001022 | WHEEL CAP 5.2INCH 64MM |
| 112 | 652023843 | NYLON INSERT HEX. LOCK NUT M8 |
| 113 | YA00000420 | WASHER |
| 114 | YA00001023 | WHEEL 6INCH 150MM |
| 115 | YA00000954 | FRONT AXLE |
| 116 | YA00001026 | FRONT AXLE MOUNT UPPER |
| 117 | YA00001025 | FRONT AXLE MOUNT LOWER |
| 118 | YA00001027 | HEIGHT ADJUST ASSIST SPRING |
| 119 | YA00000851 | R PIN 7 |
| 120 | YA00001018 | PIN 7 |
| 121 | YA00000962 | GRASS BOX ASSY(MAKITA) |
| 122 | YA00000964 | GRASS CATCH SIDE CLOSS SET MAKITA |
| 123 | YA00000791 | GRASS CATCHER INDICATOR BLUE |
| 124 | YA00000966 | GRASS CATCHER UPPER BORAD |
| 125 | YA00000795 | GRIP |
| 126 | YA00000794 | SELF TAPPING SCREW ST4X14 |
| 127 | YA00000968 | GRASS CATCHER FRAME |
| 128 | YA00000967 | WASHER 4 |
| 129 | YA00000794 | SELF TAPPING SCREW ST4X14 |
| 130 | YA00000978 | MULCHING PLUG ASSY |
| 131 | YA00000979 | MULCHING PLUG BOX |
| 132 | YA00000980 | LATCH HANDLE |
| 133 | YA00000981 | COMPRESSION SPRING |
| 134 | YA00000982 | SPRING RETAINER |
| 135 | YA00000778 | SELF TAPPING SCREW ST4X16 |
| 136 | YA00000798 | SPANNER 10-13 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
