Makita Spare Parts for Chainsaw DCS500/45
€3.72
Tax included
Makita Spare Parts for Chainsaw DCS500/45
We are MAKITA original spare parts Dealers at low at unbeatable prices and a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Chainsaw DCS500/45.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Chainsaw DCS500/45
We are MAKITA original spare parts Dealers at low at unbeatable prices and a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Chainsaw DCS500/45.
In the following table, look for the model of Chainsaw and the respective parts of the code.
| Chainsaw DCS500/45 | ||
| # | Part Num. | Description |
| 1 | 181114605 | BLUE TANK |
| 2 | 181117050 | REAR HANDLE DCS4600S / 5000 HANDLE |
| 3 | 181117131 | UNLOCK LEVER FOR PS-460/500 |
| 4 | 181117031 | SPRING FOR PS-460/500 |
| 5 | 181117081 | JOINT LEVER FOR PS-460/500 |
| 6 | 181117111 | SPRING X PLATE |
| 7 | 010117050 | THROTTLE CABLE DCS4600S |
| 8 | 935930240 | PIN / DCS6401 |
| 9 | 181117121 | THROTTLE LEVER |
| 10 | 957114061 | VALVE KIT X DCS6401 |
| 11 | 913455204 | SCREW 5,5X20 (TORX) |
| 12 | 181114065 | FUEL LINE DCS4600S / 5000 |
| 13 | 163532-9 | FILTER |
| 14 | 010114020 | REPAIR FILTER KIT X HP-450 |
| 15 | 168823-3 | PS32CTLC TANK CAP |
| 16 | 213080-9 | RING 29.5 PS32CTLC |
| 17 | 181114301 | DAMPER PS4605 / 5105 |
| 18 | 181114301 | DAMPER PS4605 / 5105 |
| 19 | 181310200 | TUBULAR HANDLE DCS4600S |
| 20 | 913455204 | SCREW 5,5X20 (TORX) |
| 21 | 266478-9 | SCREW 5,5X16 (TORX) |
| 22 | 181114650 | HANDLE COVER DCS4600S |
| 23 | 908006205 | SCREW M6X20 |
| 24 | 913455204 | SCREW 5,5X20 (TORX) |
| 26 | 181118261 | RED FILTER COVER PS500C |
| 27 | 181118060 | CLOSING PLATE DCS4600S |
| 28 | 181173190 | DCS4600S / 5000 AIR FILTER |
| 28A | 181173090 | NYLON AIR FILTER PS5000 / 5105 |
| 28B | 181173240 | NYLON AIR FILTER |
| 29 | 181171050 | LEVER FOR AIR FILTER DCS4600S |
| 30 | 010117050 | THROTTLE CABLE DCS4600S |
| 31 | 266480-2 | SCREW |
| 32 | 181155020 | STARTER DCS4600S / 5000 |
| 33 | 970311550 | CABLE DCS4600S-5000 |
| 34 | 266478-9 | SCREW 5,5X16 (TORX) |
| 35 | 181173250 | PRE-FILTER |
| 36 | 181131602 | BACKGROUND (BLUE) FOR DCS460-500 |
| 37 | 266476-3 | SCREW M5X20 (TORX) |
| 38 | 038118110 | RUBBER PLATE X DCS6401 |
| 39 | 938650062 | STOP X DCS6401 |
| 40 | 181171150 | INTERMEDIATE FLANGE DCS4600S |
| 41 | 181131090 | PIPE DCS4600S-5000 |
| 42 | 181131040 | DCS6400S SUCTION DUCT |
| 43 | 346413-4 | BUSH 17 PS32CTLC |
| 44 | 181131070 | DCS4600S-5000 RING |
| 45 | 266478-9 | SCREW 5,5X16 (TORX) |
| 46 | 181155010 | CONTACT PLATE |
| 47 | 181155030 | DCS4600S-5000 GUIDE |
| 48 | 266478-9 | SCREW 5,5X16 (TORX) |
| 49 | 267821-5 | ELASTIC WASHER |
| 50 | 980114928 | LABEL PS-460/500 |
| 53 | 181174102 | MUFFLER FOR PS-460/500 |
| 57 | 181174061 | ISOLAN PLATE. FOR PS-460/500 |
| 58 | 181174050 | GASKET DCS4600S-5000 |
| 59 | 266476-3 | SCREW M5X20 (TORX) |
| 60 | 181174091 | MUFFLER SUPPORT |
| 61 | 266474-7 | SCREW M5X8 (TORX) |
| 62 | 908905165 | SCREW M5X16 FOR PS-460/500 |
| 108 | 181174301 | PS500 CATALYTIC MUFFLER |
| 109 | 181174470 | CAP PS500 / C |
| 110 | 266474-7 | SCREW M5X8 (TORX) |
| 65 | 179130215 | CYLINDER AND PISTON D45 |
| 66 | 181132064 | PISTON DIAM.45MM DCS4600-5000 |
| 67 | 181132080 | PISTON RING DIAM 45 |
| 68 | 181132040 | PISTON PINS DCS4600S / 5000 |
| 69 | 181132050 | CIRCLIP 12X1 |
| 70 | 181118070 | DCS4600S DAMPER BUFFER |
| 72 | 266960-8 | SCREW X DCS6401 |
| 73 | 181114401 | DAMPER PS4605-5105 |
| 74 | 181131134 | GASKET |
| 75 | 181120102 | CRANKSHAFT DCS4600S / 5000 |
| 76 | 962210103 | NEEDLE BEARING 10X13X12.5 |
| 77 | 211154-0 | BALL BEARING 6202 |
| 78 | 960123159 | BALL BEARING 6203 C3 |
| 79 | 213141-5 | OIL SEAL |
| 80 | 179111650 | FLYWHEEL CARTER (BLUE) |
| 81 | 179111640 | CLUTCH SIDE CASING (BLUE) |
| 82 | 181111061 | CRANKCASE GASKET FOR PS-460/500 |
| 83 | 168399-0 | TANK CAP X DCS230T |
| 84 | 963225030 | RING X PS3400 / 3400TH |
| 85 | 181118050 | DCS4600S FIXING PLATE |
| 86 | 908006205 | SCREW M6X20 |
| 87 | 266476-3 | SCREW M5X20 (TORX) |
| 89 | 936430160 | PIN 3X16 PS350C-420C |
| 91 | 266476-3 | SCREW M5X20 (TORX) |
| 92 | 266476-3 | SCREW M5X20 (TORX) |
| 93 | 181111050 | CHAIN CATCH DCS4600S-5000 |
| 94 | 908006205 | SCREW M6X20 |
| 95 | 905808210 | PRISIONER M8X21 PS-460/500 |
| 96 | 181250011 | SPIKE FOR PS-460/500 |
| 97 | 908905165 | SCREW M5X16 FOR PS-460/500 |
| 98 | 168504-9 | BREATHER VALVE PS32CTLC |
| 100 | 181213300 | DCS4600S-5000 CHAIN TENSIONER |
| 101 | 227743-1 | SCREW FOR CHAIN TENSIONER 11 |
| 102 | 181213240 | SLIDE DCS4600S-5000 |
| 103 | 227744-9 | GEAR 18 |
| 104 | 452667-4 | COVER |
| 105 | 452668-2 | CHAIN TENSIONER PLATE EA3200S |
| 106 | 963207020 | GASKET 7 |
| 107 | 908905165 | SCREW M5X16 FOR PS-460/500 |
| 108 | 960123159 | BEARING 6203 C3 |
| 115 | 181160601 | BLUE STARTER GROUP |
| 116 | 181112611 | STARTING CASE DCS4600S |
| 118 | 266476-3 | SCREW M5X20 (TORX) |
| 119 | 001161020 | STARTER GRIP DPC7311 |
| 120 | 108164020 | STARTER ROPE 3,5X980MM |
| 122 | 267821-5 | ELASTIC WASHER |
| 123 | 181162150 | REEL DCS4600S |
| 124 | 181163020 | SPRING DCS4600S |
| 125 | 924605510 | WASHER ES-31A |
| 126 | 913455204 | SCREW 5,5X20 (TORX) |
| 127 | 181118041 | DCS4600S-5000 DEFLECTOR |
| 128 | 181143212 | COIL PS4605-5105 BLACK |
| 129 | 181147050 | COIL CABLE DCS4600S / 5000 |
| 131 | 970502110 | INSULATION TUBE 6 / 0.5 (M) |
| 132 | 957604260 | SPARK PLUG CAP |
| 133 | 965603021 | SPARK PLUG NGK BPMR7A |
| 134 | 266476-3 | SCREW M5X20 (TORX) |
| 135 | 264022-6 | NUT |
| 136 | 926208001 | ELASTIC WASHER 8 |
| 137 | 181141105 | FLYWHEEL DCS4600S-5000 |
| 138 | 181166050 | PAWL COMPLETE |
| 182 | 181160671 | STARTER GROUP |
| 183 | 181112660 | BLUE STARTER CASING |
| 184 | 181118041 | DCS4600S-5000 DEFLECTOR |
| 185 | 452458-3 | STARTER GRIP |
| 186 | 266607-4 | SCREW M5X20 PS32CTLC |
| 187 | 181163050 | SPRING |
| 188 | 181162020 | REEL |
| 189 | 234193-3 | SPRING EASY START |
| 190 | 181163090 | GUIDE FOR EASY START |
| 191 | 266616-3 | SCREW X EASY START |
| 192 | 181164020 | ROPE 3.5MMX1100 |
| 140 | 181245251 | OIL PUMP DCS4600S-5000 |
| 142 | 181245140 | PUMP BODY COVER DCS4600S |
| 143 | 424178-9 | OIL DUCT DCS4600S |
| 145 | 168645-1 | PS32CTLC SUCTION HOSE |
| 146 | 231975-4 | OIL TUBE SPRING X DCS230T |
| 147 | 001245020 | HOSE STEM |
| 149 | 908905165 | SCREW M5X16 FOR PS-460/500 |
| 150 | 450956-1 | ENDLESS DCS4600S-5000 |
| 151 | 001182042 | DISC PS350C / 420C |
| 152 | 168510-4 | CLUTCH DCS4600S-5000 |
| 153 | 181184010 | CLUTCH SPRING DCS4600S-5000 |
| 154 | 021224011 | SPACER |
| 155 | 346029-5 | BRAKE SPRING |
| 157 | 962300009 | NEEDLE BEARING DCS4600S |
| 159 | 267820-7 | WASHER 29 PS350C-420C |
| 160 | 259045-7 | RING X DCS6401 |
| 161 | 927304000 | SAFETY WASHER 4 |
| 162 | 181213100 | DCS4600S-5000 LEVERAGE |
| 163 | 181213023 | TENSION SPRING X PS6100 |
| 164 | 181213170 | GUIDE DCS4600S |
| 165 | 181213371 | SPONGE FOR PS-460/500 |
| 167 | 181213161 | HANDLE PROTECTION DCS4600S-5000 |
| 168 | 810449-4 | LABEL |
| 169 | 181213310 | SPACER DCS4600S-5000 |
| 170 | 325604-0 | BUSCH DCS4600S-5000 |
| 171 | 266476-3 | SCREW M5X20 (TORX) |
| 175 | 957213600 | CRANKCASE (BLUE) |
| 176 | 264055-1 | NUT M8 |
| 177 | 957213220 | GUARD FOR PS-460/500 |
| 178 | 181213191 | PINION COVER DCS4600S-5000 |
| 179 | 908105126 | SCREW M.5X12 X UH4520-5520-7020 |
| 180 | 181223312 | CLUTCH DRUM 325 "Z = 7 |
| 181 | 181213400 | INSERT FOR PS |
| 200 | 181153101 | CARBURETOR DCS4600S-5000 |
| 202 | 181153030 | DCS4600S TOP COVER |
| 203 | 038153360 | SCREW X DCS6401 |
| 204 | 181153040 | DCSS4600S DIAPHRAGM COVER |
| 205 | 001153020 | SCREW |
| 206 | 181153020 | GASKET KIT DCS4600S-5000 |
| 207 | 181153050 | DIAPHRAGM DCS4600S-5000 |
| 208 | 038153210 | BALL X PS6400 |
| 209 | 181153070 | SCREW S X DCS4600S-5000 |
| 210 | 036153040 | FILTER X PS 34 |
| 211 | 957153090 | THROTTLE VALVE |
| 212 | 957153080 | THROTTLE SHAFT DCS4600S |
| 213 | 957153070 | CONTROL PARTS X PS6400 |
| 214 | 028153480 | SPRING FOR PS-460/500 |
| 215 | 181153180 | SCREW L DCS4600S-5000 |
| 216 | 181153190 | SCREW H DCS4600S-5000 |
| 217 | 181153220 | WASHER FOR PS-460/500 |
| 224 | 181153110 | THROTTLE VALVE SPRING |
| 225 | 181153160 | THROTTLE SHAFT VALVE SPRING |
| 226 | 181153210 | CARBURETOR PLATE DCS4600S |
| 230 | 038155012 | FIXING PS4605-5105-5105D |
| 231 | 965402995 | GASKET DCS4600S-5000 |
| 500 | 445045631 | 45CM CHAIN BAR SP.1,5MM |
| 501 | 415325710 | BAR PINION 0.325 " |
| 502 | 528086772 | SUPERGUARD SAW CHAIN 72 |
| 503 | 514686772 | 45CM 0.325 "POWER MATCH SAW CHAIN |
| 504 | 558083000 | TIE PITCH 0.325 " |
| 505 | 558083010 | TIE STRAP 0.325 " |
| 518 | 952010640 | COVER GUARD 40CM |
| 520 | 957004002 | TOOLS SERIES DCS430 |
| 521 | 941719133 | UNIVERSAL KEY 19/13 |
| 522 | 782025-3 | TORX KEY |
| 523 | 783012-5 | SCREWDRIVER FOR CARBURETOR |
| 524 | 950004001 | PLASTIC HOUSING |
