Makita Spare Parts for Electric Saw UC4041A

€11.29
Tax included

Makita Spare Parts for Electric Saw UC4041A

MAKITA Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Electric Chain Saw UC4041A.
ITEM CODE: 210213500
Quantity
Usually Ships in: 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Electric Saw UC4041A

MAKITA Original spare parts  at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Electric Chain Saw UC4041A.

In the following table, look for the model of Electric Saw and the respective parts of the code.
Makita UC4041A
Electric Saw UC4041A
# Part Num. Description
1 266326-2 SCREW 4X18 X MT601
2 454725-2 REAR COVER
3 191972-1 CARBON BRUSHES CB-132
4 682211-5 RUBBER SLEEVE FOR UC3020A
6 424600-6 FRONT SOCKET
7 266388-0 SCREW 5X16 FOR UC3020A
8 253807-5 WASHER 5 6012D / HD / 62/63 / 64DW
9 142279-8 FRONT PROTECTION
10 231640-5 TORSION SPRING 20 FOR UC3020A
11 187869-0 HOUSING
12 650577-1 SWITCH SD-006-BB2AA-AA
13 650716-3 TGC31B SWITCH
14 233173-6 SPRING COMPRESSION 4 FOR UC3020A
15 416178-3 UNLOCKING BUTTON X UC3020A
16 455185-1 SWITCH
17 645149-5 CAPACITOR X 4350CT
18 266326-2 SCREW 4X18 X MT601
19 687124-5 CABLE CLAMP MT953
20 682540-6 SLEEVE JN1601
22 210046-0 BALL BEARING 608ZZ
23 681644-1 INSULATION WASHER X 9227CB
24 594538-0 STATOR FOR UC3020A
25 266389-8 SCREW 5 X 70 FOR UC3020A
26 513893-1 ARMATURE
28 419238-0 DEFLECTOR FOR UC3020A
29 211061-7 BEARING BALLS 6000DD 6221DW
30 227153-2 GEAR 12 FOR UC3020A
31 931403-6 HEXAGONAL NUT M8
32 142282-9 CPL. TANK CAP
34 454729-4 OIL TANK
37 424602-2 OIL TUBE
38 231975-4 SPRING OF OIL TUBE X DCS230T
39 416274-7 OIL TUBE CAP X DCS230T
40 268238-5 PIN 5 EBH341U
41 158047-9 LINK PLATE
42 233175-2 COMPRESSION SPRING 9
44 266326-2 SCREW 4X18 X MT601
45 267195-4 WASHER 4 X DCS230T
46 210213500 SPRING OF ES-31A BRAKE
47 346739-4 BRAKE RING
48 231817-2 TENSION SPRING 5 X UC3020A
49 454720-2 BEARING HOUSING
50 213017-6 RING 6 X AN621
51 266326-2 SCREW 4X18 X MT601
52 424601-4 CONNECTOR
53 135615-5 GEAR 43
55 210106-8 BEARING 6001LLB
56 961006-2 RETAINING RING S10
57 210033-9 BEARING 696ZZ X 2107FK
58 326359-0 ROD
60 266326-2 SCREW 4X18 X MT601
61 345651-5 SPIKE FOR UC3020A
63 266326-2 SCREW 4X18 X MT601
64 221526-1 REEL FOR UC3020A
65 930108100 ES-31A SAFETY WASHER
66 266007-8 SCREW M3 X10 HP2030
67 454727-8 TENSION COVER
68 454726-0 BUTTON 30
69 326360-5 SHAFT
70 227496-2 BEVEL GEAR 14 FOR UC3020A
71 227496-2 BEVEL GEAR 14 FOR UC3020A
72 324620-9 ADJUST SCREW X UC3020A
73 346859-4 CHAIN TENSION SLIDE
74 424603-0 CABLE
75 142156-4 OIL PUMP
76 221427-3 WORM
77 266326-2 SCREW 4X18 X MT601
78 266427-6 SCREW 4X12 MT923
79 142281-1 SPROCKET COVER CPL
80 454728-6 COVER
81 142235-8 NUT
500 511492756 SAW CHAIN 56M 3/8"
501 442040661 SPROCKET NOSE BAR 40 cm (16") 3/8" - 0.50
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
