Makita Spare Parts for Chainsaw EA3201S
€62.03
Tax included
Makita Spare Parts for Chainsaw EA3201S
We have the Makita original Spare Parts for Chainsaw EA3201S, the diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Chainsaw EA3201S. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Chainsaw EA3201S
Fix Your Chainsaw EA3201S. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.In the following table, look for the model of Chainsaw and the respective parts of the code.
| CHAINSAW MAKITA EA3201S pag.1 | ||
| # | Part Num. | Description |
| 1 | 168507-3 | TANK CAP COMPLETE |
| 2 | 213080-9 | O RING 29.5 |
| 3 | 163447-0 | GASOLINE FILTER |
| 4 | 195758-5 | TANK ASSEMBLY A BLUE |
| 5 | 266651-1 | H.L. TAPPING SCREW 5.5X16 |
| 6 | 452021-2 | GRIP SHELL |
| 7 | 452020-4 | CATCH LEVER |
| 8 | 231866-9 | TORSION SPRING 10 |
| 9 | 452019-9 | THROTTLE LEVER |
| 10 | 195762-4 | AIR VALVE SET |
| 11 | 452018-1 | FUEL NIPPLE |
| 12 | 213586-7 | O RING 11.5 |
| 13 | 424456-7 | FUEL LINE |
| 14 | 869091-8 | EA3201S NAME PLATE |
| 17 | 452036-9 | TUBULAR HANDLE |
| 18 | 346517-2 | CUP W ASHER 6 |
| 19 | 234189-4 | COMPRESSION SPRING 12 |
| 20 | 266605-8 | H.L. SOCKET HEAD BOLT M5X16 |
| 21 | 266651-1 | H.L. TAPPING SCREW 5.5X16 |
| 22 | 891898-4 | MAKITA LOGO LABEL |
| 23 | 266651-1 | H.L. TAPPING SCREW 5.5X16 |
| CHAINSAW MAKITA EA3201S pag.2 | ||
| 24 | 452031-9 | AIR FILTER COVER |
| 25 | 423414-0 | AIR FILTER |
| 26 | 452030-1 | INTAKE MANIFOLD |
| 27 | 266604-0 | H.L. SOCKET HEAD BOLT M4X40 |
| 28 | 424173-9 | DAMPING PLUG |
| 29 | 168398-2 | PRIMER PUMP |
| 30 | 422067-2 | TUBE 2.5-55 |
| 31 | 422065-6 | TUBE 2.5-112 |
| 32 | 422068-0 | TUBE 3-70 |
| 33 | 422066-4 | TUBE 2.5-72 |
| 34 | 318634-8 | FLANGE RING |
| 35 | 346413-4 | BUSH 17 |
| 36 | 452024-6 | INTERMEDIATE FLANGE |
| 37 | 424340-6 | INTAKE HOSE |
| 38 | 233971-8 | RING SPRING |
| 39 | 266651-1 | H.L. TAPPING SCREW 5.5X16 |
| 40 | 264044-6 | SNAP NUT M5 |
| 41 | 168602-9 | CARBURETOR |
| 42 | 266421-8 | TAPPING SCREW 3X10 |
| 43 | 346290-4 | CONTACT SPRING |
| 44 | 266651-1 | H.L. TAPPING SCREW 5.5X16 |
| 45 | 452023-8 | HOOD |
| 46 | 266607-4 | H.L. SOCKET HEAD BOLT M5X20 |
| 47 | 325938-1 | ANGULAR NIPPLE |
| 48 | 346306-5 | COOLING PLATE |
| 49 | 325939-9 | CONNECTING LINK |
| 50 | 346304-9 | GASKET |
| 51 | 266605-8 | H.L. SOCKET HEAD BOLT M5X16 |
| 52 | 168604-5 | MUFFLER COMPLETE |
| 53 | 346294-6 | SPARK ARRESTER SCREEN |
| 54 | 266606-6 | H.L. SOCKET HEAD BOLT M5X40 |
| 55 | 266605-8 | H.L. SOCKET HEAD BOLT M5X16 |
| CHAINSAW MAKITA EA3201S pag.3 | ||
| 56 | 195759-3 | CYLINDER PISTON SET |
| 57 | 195760-8 | PISTON SET |
| 58 | 325991-7 | PISTON RING 38 |
| 59 | 325992-5 | PISTON PIN 8 |
| 60 | 233988-1 | RING SPRING 8 |
| 61 | 213582-5 | OIL SEAL 12 |
| 62 | 211341-1 | BALL BEARING 6201 |
| 63 | 212086-4 | NEEDLE CAGE 810 |
| 64 | 195956-1 | CRANK SHAFT SET |
| 65 | 211341-1 | BALL BEARING 6201 |
| 66 | 213582-5 | OIL SEAL 12 |
| 67 | 424339-1 | CRANK CASE SEALING |
| 68 | 318633-0 | CRANKCASE UNDERSIDE |
| 69 | 168507-3 | TANK CAP COMPLETE |
| 70 | 213080-9 | O RING 29.5 |
| 71 | 452727-2 | PLUG |
| 72 | 266651-1 | H.L. TAPPING SCREW 5.5X16 |
| 73 | 234189-4 | COMPRESSION SPRING 12 |
| 74 | 816917-5 | INDICATION LABEL |
| 75 | 452025-4 | CHOKE LEVER |
| 76 | 452022-0 | THROTTLE LINKAGE |
| 77 | 266608-2 | H.L.TAPPING SCREW 5X40 |
| 78 | 325946-2 | BUSH 6 |
| 79 | 234189-4 | COMPRESSION SPRING 12 |
| 80 | 266651-1 | H.L. TAPPING SCREW 5.5X16 |
| 81 | 234189-4 | COMPRESSION SPRING 12 |
| 82 | 266651-1 | H.L. TAPPING SCREW 5.5X16 |
| 83 | 266651-1 | H.L. TAPPING SCREW 5.5X16 |
| 84 | 168504-9 | VENT VALVE |
| 85 | 346301-5 | SPIKE BAR |
| 86 | 346385-3 | HEAT PROTECTION FOIL |
| CHAINSAW MAKITA EA3201S pag.4 | ||
| 87 | 444029-0 | ISOLATING TUBE 6-95 |
| 88 | 346445-1 | SPARK PLUG CONNECTOR |
| 89 | 168401-9 | SPARK PLUG |
| 90 | 452670-5 | ISOLATING WASHER |
| 91 | 126270-4 | IGNITION COIL ASSEMBLY |
| 92 | 266631-7 | H.L. SOCKET HEAD BOLT M5X20 |
| 93 | 168601-1 | CABLE HARNESS |
| 94 | 266651-1 | H.L. TAPPING SCREW 5.5X16 |
| 95 | 891901-1 | EA3201S MODEL NO. LABEL |
| 96 | 168608-7 | STARTER COMPLETE BLUE |
| 97 | 453783-5 | STARTER GRIP |
| 98 | 267847-7 | SQUARE WASHER 4 |
| 99 | 444038-9 | STARTER ROPE |
| 100 | 234252-3 | REW IND SPRING |
| 101 | 453785-1 | REEL |
| 102 | 234253-1 | TORSION SPRING 20 |
| 103 | 453786-9 | CAM PLATE |
| 104 | 266777-9 | TAPPING SCREW 5X12 |
| 105 | 452026-2 | AIR GUIDE PLATE |
| 106 | 264053-5 | HEX. NUT M8X1 |
| 107 | 267822-3 | SPRING W ASHER 8 |
| 108 | 140480-9 | FLYW HEEL COMPLETE |
| 109 | 195761-6 | RATCHET SET |
| CHAINSAW MAKITA EA3201S pag.5 | ||
| 110 | 452032-7 | HAND GUARD |
| 111 | 810075-9 | CAUTION LABEL |
| 112 | 266627-8 | H.L. TAPPING SCREW 4.7X16 |
| 113 | 267066-5 | FLAT W ASHER 5 |
| 114 | 313212-9 | HAND GUARD GUIDE |
| 115 | 234210-9 | COMPRESSION SPRING 6 |
| 116 | 231868-5 | TENSION SPRING 10 |
| 117 | 163500-2 | LINK PLATE COMPLETE |
| 118 | 325947-0 | BUSH 6 |
| 119 | 346299-6 | SPACER SHEET METAL |
| 120 | 961011-9 | STOP RING E-4 |
| 121 | 452033-5 | BRAKE COVER |
| 122 | 266421-8 | TAPPING SCREW 3X10 |
| 123 | 452035-1 | PUMP DRIVE |
| 124 | 168645-1 | OIL SUCTION LINE COMPLETE |
| 125 | 234207-8 | COMPRESSION SPRING 6 |
| 126 | 452666-6 | NIPPLE |
| 127 | 424342-2 | OIL PRESSURE LINE |
| 128 | 168503-1 | OIL PUMP COMPLETE |
| 129 | 195872-7 | OIL PUMP ADJUSTMENT SET |
| 130 | 266627-8 | H.L. TAPPING SCREW 4.7X16 |
| 131 | 267430-0 | FLAT W ASHER 10 |
| 132 | 267431-8 | FLAT W ASHER 10 |
| 133 | 168607-9 | CLUTCH COMPLETE |
| 134 | 231873-2 | TENSION SPRING 5 |
| 135 | 140980-9 | CLUTCH DRUM ASSEMBLY |
| 136 | 267451-2 | FLAT W ASHER 8 |
| 137 | 259033-4 | RETAINING RING E TYPE 6 |
| 138 | 346298-8 | BRAKE BAND |
| 139 | 140482-5 | ENGINE HOUSING COMPLETE TLC B |
| 140 | 453784-3 | SPRING CASSETTE |
| 141 | 195955-3 | REW IND SPRING SET |
| 151 | 140510-6 | SPROCKET GUARD TLC COMPLETE B |
| 152 | 266007-8 | TAPPING SCREW BIND PT 3X10 |
| 153 | 346309-9 | GUIDE PLATE |
| 154 | 266007-8 | TAPPING SCREW BIND PT 3X10 |
| 155 | 417403-5 | COVER |
| 156 | 324068-5 | ADJUST PIN |
| 157 | 226681-4 | HELICAL GEAR 17 |
| 158 | 226534-7 | HELICAL GEAR 8 |
| 159 | 346518-0 | GUIDE PLATE |
| 160 | 892502-8 | INDICATION LABEL |
| 161 | 233033-2 | COMPRESSION SPRING 4 |
| 162 | 216008-6 | STEEL BALL 4 |
| 163 | 419233-0 | DIAL 40 |
| 164 | 253874-0 | FLAT WASHER 4 |
| 165 | 915106-0 | BINDING HEAD SCREW M4X8 |
| 166 | 264042-0 | HEX. NUT M8-13 |
| 167 | 231025-5 | COMPRESSION SPRING 8 |
| 168 | 195764-0 | WING GRIP SET |
| CHAINSAW MAKITA EA3201S pag.6 | ||
| 170 | WJ00096166 | SCREW |
| 171 | WJ00213750 | COVER ASSEMBLY-PUMP |
| 172 | WJ00096369 | SCREW-IDLE ADJ |
| 173 | WJ00098356 | SPRING |
| 174 | WJ00096475 | SCREW |
| 175 | WJ00183519 | LEVER-CHOKE |
| 176 | WJ00983585 | SPRING |
| 177 | WJ00223556 | SHAFT ASSEMBLY-THROTTLE |
| 178 | WJ00098494 | SPRING |
| 179 | WJ01023908 | NEEDLE-IDLE |
| 180 | WJ01024001 | NEEDLE-HIGH SPEED |
| 181 | WJ00098404 | SPRING |
| 182 | WJ00136152 | WASHER |
| 183 | WJ00016105 | RING-O |
| 184 | WJ00062150 | VALVE-CHOKE |
| 185 | WJ00983270 | SPRING |
| 186 | WJ00166114 | LEVER-METERING |
| 187 | WJ00014477 | PIN-METERING LEVER |
| 188 | WJ00008282 | VALVE-INLET NEEDLE |
| 189 | WJ00963226 | SCREW |
| 190 | WJ00088271 | PLUG-W ELCH |
| 191 | WJ00021158 | COVER-METERING DIAPHRAGM |
| 192 | WJ00095613 | DIAPHRAGM ASSEMBLY-METERING |
| 193 | WJ00092192 | GASKET-METERING DIAPHRAGM |
| 194 | WJ00223784 | SHAFT ASSEMBLY-CHOKE |
| 195 | WJ00013690 | WASHER |
| 196 | WJ00016682 | LEVER-FAST IDLE |
| 197 | WJ00983584 | SPRING |
| 198 | WJ00001673 | RING-RETAINING |
| 199 | WJ00183366 | LEVER-THROTTLE |
| 200 | WJ00983164 | SPRING |
| 201 | WJ00160511 | PISTON ASSMBLY-ACCELERATOR |
| 202 | WJ00088229 | PLUG-CUP |
| 203 | WJ00014070 | INLET SCREEN |
| 204 | WJ00343439 | VALVE-THROTTLE |
| 205 | WJ00009589 | DIAPHRAGM-PUMP |
| 206 | WJ00092225 | GASKET-PUMP |
| 207 | WJ00096589 | SCREW ASSEMBLY |
| 208 | WJ00096475 | SCREW |
| 209 | WJ00096475 | SCREW |
| 210 | WJ00096475 | SCREW |
| 211 | WJ00001673 | RING-RETAINING |
| A01 | 165246-6 | SPROCKET NOSE BAR 14" 35CM 3/8" .043 1,1 MM |
| A02 | 419560-5 | CHAIN COVER |
| A03 | 511291752 | CHAIN 14" / 35cm 3/8"P |
| A04 | 782026-1 | UNIVERSAL WRENCH |
| A05 | 783012-5 | SCREW DRIVER 13/16 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
