Makita original spare parts for the replacement of damaged parts or to repair electrical or mechanical components of the Battery-Powered Pruning Shear 4604DW.
In the following table, look for the model of the Prining Scissor and the respective parts of the code.
| Battery-Powered Pruning Shear 4604DW | ||
| # | Part Num. | Description |
| 1 | 266230-5 | SCREW M8 X 4604D |
| 2 | 153396-9 | BLADE HOLDER X 4604D |
| 3 | A-86670 | UPPER KNIFE X 4604DW |
| 4 | A-86664 | LOWER KNIFE X 4604DW |
| 5 | 941201-0 | FLAT WASHER 8 |
| 6 | 252128-2 | NUT M8-13 X 4603DW |
| 7 | 226394-7 | GEAR 9 4604D |
| 8 | 256014-9 | PIN 3 |
| 9 | 317231-7 | GEAR BOX CPL 4604DW |
| 10 | 211051-0 | BALL BEARING 609 2RS |
| 11 | 226785-2 | GEAR 5 4604D |
| 12 | 216416-1 | NEEDLE BEARING 4604D |
| 13 | 216207-0 | WASHER X 4604D |
| 14 | 416961-8 | BLADE COVER 4604DW |
| 15 | 183142-6 | HOUSING CPL X 4604DW |
| 16 | 266273-7 | SCREW 4 X 12 X 4604D |
| 17 | 911028-2 | SCREW 3 X 16 X 4604D |
| 18 | 638855-9 | UNIT X 4604D |
| 19 | 416967-6 | 4604DW SWITCH LEVER |
| 20 | 256176-3 | PIN X 4604D |
| 21 | 231473-8 | SPRING COMPRESION 4 X 4604D |
| 22 | 416966-8 | UNLOCKING LEVER 4604DW |
| 23 | 233075-6 | SPRING COMPRESION 6 X 4604D |
| 24 | 631365-5 | CPL CIRCUIT 4604DW |
| 25 | 911002-0 | SCREW M3 X 6 X 4604D |
| 26 | 226784-4 | CONICAL GEAR 15 4604D |
| 27 | 211012-0 | BEARING X 9524NB |
| 28 | 211012-0 | BEARING X 9524NB |
| 29 | 267198-8 | FLAT WASHER X 4604D |
| 30 | 226392-1 | INNER GEAR 44 4604D |
| 31 | 911002-0 | SCREW M3 X 6 X 4604D |
| 32 | 266492-5 | SCREW M4X25 9527PB-9528PB |
| 33 | 151718-7 | COMPLETE SUPPORT X 4604DW |
| 34 | 226386-6 | SPUR GEAR 4604D |
| 35 | 153269-6 | GEAR 16 4604DW |
| 36 | 226386-6 | SPUR GEAR 4604D |
| 37 | 267198-8 | FLAT WASHER X 4604D |
| 38 | 265078-2 | SCREW M5 X 12 X 4604D |
| 39 | 416968-4 | 4604DW MOTOR BLOCK |
| 40 | 629742-3 | DC 4604DW MOTOR |
| 43 | 911018-5 | SCREW M 3 X 12 4604D |
| 44 | 266273-7 | SCREW 4 X 12 X 4604D |
