Makita Spare Parts for Bruschcutter RBC421
€1.44
Tax included
Makita Spare Parts for Bruschcutter RBC421
We are MAKITA original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Bruschcutter RBC421.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for BruschCutter RBC421
We are MAKITA original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Bruschcutter RBC421.
In the following table, look for the model of Brusch Cutter and the respective parts of the code.
| RBC421 - BRUSHCUTTER 40,2CC MAKITA -PAG. 1 | ||
| Pos. | Part Num. | Description |
| 1 | 6411028000 | COMPLETE SHAFT ASSEMBLY X RBC351 |
| 2 | 6411502600 | CLUTCH HOUSING X RBC 410 |
| 3 | 6301501600 | WASHER X RBC520 |
| 4 | 6414005001 | HANDLEGRIP SUPPORT RBC351 |
| 5 | 6353001000 | GEAR BOX X RBC 410 BOX |
| 6 | 0031512000 | EXT. RING X RBC260 / 520RBK410 |
| 7 | 0031428000 | INTERNAL RING X RBC410 / 520 |
| 8 | 0600129980 | BALL BEARING 6001ZZ |
| 9 | 6413003000 | SPINDLE X RBC410 |
| 10 | 0011306140 | BOLT WITH WASHER X RBC410 |
| 11 | 0011306320 | BOLT WITH WASHER X RBC410 |
| 12 | 266671-5 | OIL CAP |
| 13 | 412099-7 | PROTECTION X BRUSHCUTTER |
| 14 | 0031005000 | WASHER X RBC230 / 410 / RBK410 |
| 15 | 0119059900 | BOLT M5X12 X RBC225-255 |
| 16 | 0600079990 | BEARING 627 X RBC415 |
| 17 | 0600129970 | BEARING 6201 X RBC415 |
| 18 | 6413500500 | SPACER X RBC410 |
| 19 | 0031432000 | INTERNAL LOCK X RBC260 / 310/410 |
| 20 | 6413500400 | OIL GASKET X RBC410 |
| 21 | 326053-4 | UPPER FLANGE X RBC410 |
| 22 | 346441-9 | EXTERNAL FLANGE |
| 23 | 264058-5 | NUT X RBC 410 / RBC520 |
| 24 | 6308503300 | NUT X RBC 410 / RBC520 |
| 25 | 0031517000 | EXTERNAL LOCK X RBC 410 RBK410 |
| 26 | 0031435000 | INTERNAL LOCK X RBC410 / 520 / RBK410 |
| 27 | 0600179850 | BALL BEARING 6003DD X RBC / K 410 |
| 28 | 0119069910 | COMPLETE BOLT X RBC 410 |
| 29 | 424403-8 | RUBBER X RBC 410 |
| 32 | 6202500400 | BOLT X RBC 410 / RBK410 |
| 33 | 267429-5 | WASHER 6 |
| 34 | 6218008003 | PROTECTION FOR BRUSHCUTTER |
| 35 | 140897-6 | CLUTCH (MS4211) |
| 36 | 6202500400 | BOLT X RBC 410 / RBK410 |
| 37 | 0032006000 | ELASTIC WASHER X RBC / RBK410-G2400R |
| 38 | 267429-5 | WASHER 6 |
| 39 | 6407006000 | COMPLETE BELT X RBC350-420 |
| 40 | 6411502101 | CLAMP X RBC350-420 |
| 41 | 318732-8 | CLAMP X RBC525 |
| 42 | 0016706500 | BOLT X RBC350-420 |
| 43 | 0230069970 | SPACER X RBC350-420 |
| 44 | 6411501300 | KNOB X RBC350-RBC420 |
| 45 | 0037108000 | GASKET X RBC520 |
| 46 | 6414505000 | RBC351 SIDE HANDLE |
| 47 | 6415034000 | THROTTLE LEVER RBC351 |
| 48 | 6414504000 | KNOB X RBC351 |
| 49 | 6414507000 | SPRING X RBC351 |
| 101 | 0150059940 | SCREW X RBK250-RBC225-RBC255 |
| RBC421 - BRUSHCUTTER 40,2CC MAKITA - PAG.2 | ||
| 50 | 5411005000 | ENGINE HOUSING ASSY RBC / RBK |
| 51 | 318630-6 | CYLINDER X RBC 410 / RBK 410 |
| 52 | 442156-7 | CYLINDER GASKET X RBC420E |
| 53 | 5411501200 | CRANK CASE GASKET X RBC410 / RBK 410 |
| 54 | 5412001000 | CRANK SHAFT ASSY X RBC / RBK 410 |
| 55 | 318631-4 | PISTON X RBC410 / RBK410 |
| 56 | 257309-3 | PISTON RING RBC410 / RBK4 |
| 57 | 257797-4 | PISTON PIN |
| 58 | 212085-6 | NEEDLE BEARING 1014 |
| 59 | 233983-1 | PISTON EBH341 PINK RING |
| 60 | 0323039990 | KEY X RBC350-RBC420 |
| 61 | 5323006000 | MUFFLER X RBC350-RBC420 |
| 62 | 5413500100 | MUFFLER COVER X RBC350-420 |
| 63 | 5323500200 | MUFFLER GASKET X RBC RBK / 410 |
| 64 | 453971-4 | INSULATOR X RBC350-RBC420 |
| 65 | 5403500600 | INSULATOR GASKET X RBC350 |
| 66 | 5416504000 | CARBURETOR GASKET RBC350P02 |
| 67 | 442160-6 | LEAD VALVE GASKET |
| 68 | 5413006000 | CPL VALVE X RBC350-RBC420 |
| 69 | 6218501500 | SCREW X RBC350-RBC420 |
| 70 | 5415504500 | STARTER HOUSING RBC350-420 |
| 71 | 5415032000 | STARTER ASSY X RBC / RBK 410 |
| 72 | 452766-2 | RBC RBK RBK 410 |
| 73 | 452767-0 | STARTER BRACKET RBC / RBK 410 |
| 74 | 233993-8 | SPIRAL SPRING X RBC 410 / RBK410 |
| 75 | 452768-8 | STARTER GUIDE X RBC 410 / RBK41 |
| 76 | 5415001050 | RETURN SPRING X RBC / RBK 410 |
| 77 | 5415001060 | WASHER X RBC / RBK 410 |
| 78 | 5245001010 | SCREW X RBC RBK 410 |
| 79 | 5415001140 | STARTER CABLE X RBC 260/410 / RBK 410 |
| 80 | 5305002110 | STARTER KNOB X RBC260 / RBK41 |
| 81 | 5415504600 | CYLINDER CASE X RBC 410 / RBK |
| 82 | 454558-5 | TANK |
| 83 | 168765-1 | TUBE X RBC350-RBC420 |
| 84 | 168766-9 | TUBE COMPLETE |
| 85 | 0561059990 | CLAMP FAST FILTER XRBC230-310 / 520 |
| 86 | 452920-8 | TANK CAP |
| 87 | 163447-0 | FUEL FILTER X DCS230T |
| 88 | 5416057000 | SHANK PROTECTION |
| 89 | 0230059990 | COMPASS X RBC260 / 410 / RBK 410 |
| 91 | 5416503500 | RUBBER X RBC350-RBC420 |
| 92 | 5416503600 | RUBBER X RBC350-RBC420 |
| 93 | 168587-9 | COIL |
| 94 | 5417001010 | POLAR WHEEL X RBC / RBK 410 |
| 95 | 0655009940 | SPARK PLUG CAP X RBC410 / RBK410RBC520 |
| 96 | 0654009931 | PIN X RBC415-225-255 |
| 97 | 965603021 | SPARK PLUG NGK BPMR7A |
| 98 | 5417500300 | TUBE X RBC350-RBC420 |
| 99 | 5607005000 | COMPLETE CABLE X RBC350-RBC420-HT225 |
| 100 | 0016706160 | BOLT M6X16 X RBC / RBK 410 |
| 101 | 0031005000 | WASHER X RBC230 / 410 / RBK410 |
| 102 | 0200069920 | WASHER M6 X RBC310 / 410 / RBK410 |
| 103 | 0032006000 | X RBC / RBK410-G2400R ELASTIC WASHER |
| 104 | 0140059630 | SCREW M5X14 X RBC350-RBC420 |
| 105 | 0140059610 | SCREW M5X14 X RBC350-RBC420 |
| 106 | 0140059560 | SCREW M5X14 X RBC350-RBC420 |
| 107 | 0119059790 | BOLT X RBC / RBK 410 M5X22 |
| 108 | 0119059660 | BOLT X RBC350-RBC420 |
| 109 | 0119059940 | BOLT X RBC 410 / RBK 410 |
| 110 | 0119069780 | BOLT M6X60 X RBC350-RBC420 |
| 111 | 0119069990 | BOLT X RBC 410 / RBK 410 |
| 112 | 5415001220 | WASHER ELASTASTICAX RBC RBK 410 |
| 113 | 0140069910 | SCREW M6X16 X RBC350-RBC420 |
| 114 | 0140059550 | SCREW M5X14 X RBC350-RBC420 |
| 115 | 0119059640 | BOLT M5X25 X RBC415 |
| 116 | 346443-5 | SUPPORT X RBC350-RBC420 |
| 117 | 0119069900 | BOLT M6X14 RBC350-RBC420 |
| 118 | 140436-2 | ROD EBH341U |
| 119 | 213546-9 | OIL SEAL X PB500R-RBC525 |
| 120 | 0600159880 | BALL BEARING 6202C3 X PB500R |
| 121 | 0600159880 | BALL BEARING 6202C3 X PB500R |
| 122 | 213546-9 | OIL SEAL X PB500R-RBC525 |
| RBC421 - BRUSHCUTTER 40,2CC MAKITA - PAG.3 | ||
| 118 | 168764-3 | CARBURETOR X RBC350-RBC420 |
| 119 | 5236046130 | CPL PUMP BODY X RBC350-RBC42 |
| 120 | 5236046060 | AIR FILTER BODY CPL. RBC350 |
| 121 | 5236046050 | PUMP COVER X RBC350-RBC42 |
| 122 | 424314-7 | PRIMING PUMP EBH341 |
| 123 | 168574-8 | DIAPHRAGM CPL EBH341U |
| 124 | 442154-1 | DIAPHRAGM GASKET EBH341U |
| 125 | 5246001040 | PUMP DIAPHRAGM RBC260 / 230/310/225 |
| 126 | 5246001030 | PUMP GASKET RBC260-230-310 |
| 127 | 5316005120 | RING X RBC 260/230/310/225/2 |
| 128 | 5236018040 | THROTTLE CABLE XRBC230-260-310-225 |
| 129 | 5416041010 | VALVE CPL RBC350 |
| 131 | 5236052020 | CABLE SUPPORT RBC350-RBC420 |
| 132 | 5316005450 | NUT ADJUSTER RBC260 / 310 |
| 133 | 5216008010 | SCREW REG CAVO ACC.XRBC260 310 |
| 134 | 5236018020 | GASKET X RBC 260/230/310 |
| 135 | 266582-4 | SCREW 3X24 EBH341U |
| 136 | 5416041020 | REGULATION SCREW RBC350-RBC |
| 137 | 5806080110 | SPRING X RBC350-RBC420 |
| 138 | 5216006040 | WASHER X RBC350-RBC420 |
| 139 | 5216006050 | GASKET X RBC350-RBC420 |
| 140 | 5426005030 | WASHER X RBC350-RBC420 |
| 141 | 453981-1 | FILTER HOUSING |
| 142 | 453982-9 | FILTER COVER |
| 143 | 443180-3 | AIR FILTER |
| 144 | 424523-8 | WASHER X RBC415-RBC350 |
| 145 | 332044-5 | BUSHING |
| 146 | 5233013040 | PLATE X RBC350-RBC420 |
| 147 | 346627-5 | AIR LEVER |
| 148 | 5313003110 | BRACKET COVER X RBC350-420 |
| 149 | 0119059810 | BOLT M5X50 XRBC / RBK410 |
| 201 | 6407003003 | BELT X RBC350-RBC420 |
| 202 | A-81658 | HEAD TAP AND GO M10x1,25F |
| 203 | 6419038000 | HEX WRENCH X RBC350 |
| 204 | 0717049990 | HEX WRENCH X RBC350-RBC420 |
| 205 | 0717059990 | HEX WRENCH RBC350-RBC420 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
