Annovi & Reverberi Parts for Pressure Washer AR 585
Annovi & Reverberi original spare parts to replace worn components or repair damaged parts of the Pressure Washer Annovi & Reverberi AR 585 - 12404.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Annovi & Reverberi Parts for Pressure Washer AR 585
Annovi & Reverberi original spare parts to replace worn components or repair damaged parts of the Pressure Washer Annovi & Reverberi AR 585 - 12404.
In the following tables, look for the spare part and its respective code.
| Pressure Washer Annovi Reverberi AR 585 - 12404 | ||
| Casing Pag.1 | ||
| # | Part Num. | Description |
| 1 | 2100300 | Screw |
| 2 | 2900650 | Guard |
| 3 | 2900620 | Knob |
| 4 | 2900610 | Blue casing |
| 5 | 2900870 | Tube clip |
| 6 | 2909009 | Handle |
| 7 | 2909007 | Base assembly |
| 8 | 2900900 | Ball |
| 9 | 2500320 | Wheel |
| 10 | 1680880 | Washer |
| 11 | 2900600 | Base |
| 12 | 2180330 | Rubber foot |
| 13 | 2900720 | Plate |
| 14 | 2440280 | Screw |
| 15 | 2900840 | Axle |
| 16 | 1682310 | Plug |
| 17 | 2901000 | Detergent hose |
| 18 | 2900710 | Tank |
| 19 | 2900690 | Plug |
| 20 | 42113 | Plug assembly |
| 21 | 2900640 | Accessories carrier |
| 22 | 2600100 | Cable gland |
| 23 | 2900680 | Knob |
| 24 | 2100300 | Screw |
| 25 | 2900670 | Plate |
| 26 | 380420 | Ring |
| 27 | 2900660 | Hose reel rotor |
| 28 | 2900940 | Detergent hose |
| 29 | 2000230 | Filter |
| Pump Pag.2 | ||
| 1 | 1980740 | Plug |
| 2 | 2900200 | Head |
| 3 | 800220 | Screw |
| 4 | 820510 | O-ring |
| 5 | 2900850 | Fitting |
| 6 | 740290 | O-ring |
| 7 | 1340260 | Filter |
| 8 | 480560 | O-ring |
| 9 | 2849051 | Complete valve |
| 10 | 2200141 | Water seal |
| 11 | 770590 | O-ring |
| 12 | 2840550 | Bushing |
| 13 | 2840540 | Bushing |
| 14 | 1683500 | Oil seal |
| 15 | 2900500 | Screw |
| 16 | 2900020 | Piston guide |
| 17 | 2901170 | Spring |
| 18 | 2840530 | Piston |
| 19 | 2840050 | Lock |
| 20 | 2840130 | Plug |
| 21 | 2840470 | Screw |
| 22 | 2909005 | Spring assembly |
| 23 | 1120680 | O-ring |
| 24 | 3040270 | O-ring |
| 25 | 2900130 | Fitting |
| 26 | 1560520 | Spring |
| 27 | 1250280 | Ball |
| 28 | 480480 | O-ring |
| 29 | 1982520 | Hose tail |
| 30 | 1460430 | O-ring |
| 31 | 2901070 | Shutter |
| 32 | 1080091 | Spring |
| 33 | 800560 | O-ring |
| 34 | 2901060 | Injector |
| 35 | 1461470 | Fitting |
| 36 | 2900810 | Fitting |
| 37 | 1260740 | O-ring |
| 38 | 2900800 | Hub pin |
| 39 | 2900820 | Ring nut |
| 40 | 2900830 | Fitting |
| A | 2233 | Valve kit |
| B | 2313 | Piston kit |
| C | 42124 | Oil seal kit |
| F | 42438 | Gasket kit |
| Motor Pag.3 | ||
| 1 | 44111 | Motor |
| 2 | 2900170 | Thrust Bearing |
| 3 | 2900260 | Wobble plate |
| 4 | 1780490 | Ball Bearing |
| 5 | 1460530 | Oil seal |
| 6 | 2320090 | Screw |
| 7 | 2900010 | Pump body |
| 8 | 1460590 | Bearing |
| 9 | 1460040 | Shield |
| 10 | 1461200 | Oil seal |
| 11 | 394280 | O-ring |
| 12 | 1460370 | Fan |
| 13 | 1460340 | Conveyor |
| 14 | 2900780 | Cover |
| 15 | 2000210 | Screw |
| 16 | 2900420 | Switch |
| 17 | 2900770 | Box |
| 18 | 2900930 | Cable |
| 19 | 2021480 | Gland |
| 20 | 2900750 | Box |
| 21 | 2020570 | Screw |
| 22 | 2900760 | Cover |
| 23 | 2100300 | Screw |
| 24 | 1340280 | Clamp |
| 25 | 2900980 | Capacitor |
| 26 | 1760450 | Cable |
| 27 | 660170 | O-ring |
| 28 | 2022201 | Fork |
| 29 | 2029753 | TSS box assembly |
| 30 | 1262400 | Washer |
| Accessories Pag.4 | ||
| 1 | 40715 | Lance+lance head |
| 2 | 40714 | Gun |
| 3 | 1460702 | High pressure hose |
| 4 | 2000770 | O-ring |
| 5 | 40246 | Lance+lance head |
| 6 | 40925 | Gun |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi & Reverberi websites, which we consider as reliable.Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi & Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Annovi Reverberi 585 - 12404
10 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N AR:
- AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS
