We supply original Hitachi-HIKOKI spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Belt Sander SB10V2.
In the following table, look for the model of the BELT SANDER and theirs spare part.
| BELT SANDER SB10V2 | ||
| # | Part Num. | Description |
| 1 | 327742 | PULLEY (A) |
| 2 | 6000VV | BALL BEARING 6000VVCMPS2L |
| 3 | 327739 | DUST GUIDE |
| 4 | 360797E | ARMATURE 220V-230V |
| 5 | 608VVM | BALL BEARING 608VVC2PS2L |
| 6 | 935196 | MACHINE SCREW (W/WASHERS) M4X12 (BLACK) |
| 7 | 931701 | BEARING LOCK |
| 8 | 328209 | DUST PLATE |
| 9 | 327738 | FAN GUIDE |
| 10 | 953174 | HEX. HD. TAPPING SCREW D5X55 |
| 11 | 340700G | STATOR ASS'Y 220V-230V |
| 12 | 930703 | BRUSH TERMINAL |
| 13 | 980063 | TERMINAL |
| 14 | 328433 | BELT COVER |
| 15 | 316321 | TAPPING SCREW (W/FLANGE) D5X45 |
| 16 | 327740 | DUST COVER |
| 17 | 327760 | HANDLE COVER |
| 18 | 984750 | TAPPING SCREW (W/FLANGE) D4X16 |
| 19 | 937631 | CORD CLIP |
| 20 | 958049 | CORD ARMOR D8.2 |
| 21 | 327759 | HOUSING ASS'Y |
| 22 | 938477 | HEX. SOCKET SET SCREW M5X8 |
| 25 | 958900 | BRUSH HOLDER |
| 26 | 999043 | CARBON BRUSH (1 PAIR) |
| 27 | 945161 | BRUSH CAP |
| 28 | 327779 | PULLEY COVER |
| 29 | 305812 | TAPPING SCREW (W/FLANGE) D4X16 (BLACK) |
| 30 | 325085 | SWITCH (E) (1P SCREW TYPE) W/LOCK |
| 32 | 328432 | VARISTOR |
| 33 | 305499 | MACHINE SCREW (W/WASHER) M3.5X6 |
| 34 | 980063 | TERMINAL |
| 36 | 938108 | TERMINAL |
| 37 | 325566 | NOISE SUPPRESSOR |
| 38 | 953043 | WASHER |
| 39 | 953042 | METAL |
| 40 | 995586 | IDLE PULLEY ASS'Y |
| 41 | 305490 | TAPPING SCREW (W/FLANGE) D4X30 (BLACK) |
| 42 | 327744 | CLEAR COVER |
| 43 | 995578 | KNOB NUT |
| 44 | 327780 | BODY ASS'Y |
| 45 | 953161 | WASHER |
| 46 | 995577 | SPRING |
| 47 | 939542 | RETAINING RING FOR D12 SHAFT |
| 48 | 995587 | SHAFT |
| 49 | 327746 | STRIKING GUIDE |
| 50 | 949216 | MACHINE SCREW M4X10 |
| 51 | 953063 | SPRING |
| 52 | 949218 | MACHINE SCREW M4X14 |
| 53 | 995585 | FORK ASS'Y |
| 54A | 330690 | BELT |
| 55 | 327749 | PULLEY (B) |
| 56 | 327748 | GEAR COVER |
| 57 | 6200VV | BALL BEARING 6200VVCMPS2L |
| 58 | 327750 | PINION |
| 59 | 935522 | METAL |
| 60 | 939540 | RETAINING RING FOR D10 SHAFT |
| 61 | 995576 | GEAR |
| 62 | 948213 | WASHER (B) D19 |
| 63 | 953175 | METAL D10X14X12 |
| 64A | 329900 | SHOE CUSHION |
| 65 | 327781 | SHOE PLATE |
| 66 | 944109 | FEATHER KEY 3X3X8 |
| 67 | 995575 | DRIVE PULLEY |
| 68 | 995552 | SANDING BELTS 100X610 WA80 |
| 69 | 328513 | DUST SEAL |
| 70 | 302086 | TAPPING SCREW (W/FLANGE) D4X20 (BLACK) |
| 500 | ABRASIVES PAPER | |
