Metabo Spare Parts for Router OFE 738
€1.84
Tax included
Metabo Spare Parts for Router OFE 738
Metabo original spare parts for to replace broken parts for to fix Router OFE 738 - 00738000.Fix Your Router OFE 738 - 00738000. All Spares can be supplied at discounted price. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Metabo Spare Parts for Router OFE 738
Fix Your Metabo Router OFE 738 - 00738000. All Spares can be supplied at discounted price. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Milling Machine and the respective parts of the code.
| Router OFE 738/00738000 | ||
| # | Part Num. | Description |
| 1 | 34448103 | Cable with plug |
| 2 | 34111156 | Handle upper part |
| 3 | 34105256 | Bolt |
| 4 | 34154009 | Adjusting toggle |
| 5 | 34336366 | Pointer |
| 6 | 33811024 | Scale |
| 7 | 33912451 | Cover |
| 8 | 14113010 | Hexagonal nut |
| 9 | 34202112 | Circlip |
| 10 | 14118066 | Retaining ring |
| 11 | 31603304 | Handle bottom part |
| 12 | 34111132 | Handle upper part |
| 14 | 34337441 | Housing with cover |
| 15 | 34410114 | Cable sleeve |
| 16 | 34340673 | Switch |
| 17 | 34307970 | electronic unit 230 V |
| 18 | 34449396 | Cable strand |
| 19 | 31603550 | Brush holder cpl. |
| 20 | 33804091 | Rating plate |
| 21 | 31501268 | Motor housing |
| 22 | 31100996 | Field coil 230V |
| 23 | 33915093 | Baffle |
| 24 | 34416130 | Open-end spanner |
| 25 | 34337443 | Housing with cover |
| 26 | 14111699 | Self-tap. fill. h. screw |
| 27 | 34336249 | Cable clip |
| 28 | 14111602 | Self-tap fill h screw |
| 29 | 34337364 | Switch rod |
| 30 | 34337588 | Switch slide |
| 31 | 33812216 | M-Label,08 52x22 |
| 32 | 34409636 | Rubber bushing |
| 33 | 14311479 | RI.KU.LA. 6X 19X 6 |
| 34 | 31000815 | Armature cpl.230V |
| 35 | 33903153 | Clamping washer |
| 36 | 14118009 | snap ring |
| 37 | 14311465 | Ball bearing, 15x35x11 |
| 38 | 33900348 | Sealing washer |
| 39 | 14319119 | Felt ring |
| 40 | 31541004 | Spindle head |
| 41 | 34170149 | Tight-fit screw |
| 42 | 14112019 | Fillister head screw |
| 43 | 63194600 | Collet 8 mm |
| 44 | 34111082 | Thumbscrew |
| 45 | 34336411 | Trigger |
| 46 | 34200177 | Pressure spring |
| 47 | 33912449 | Slide |
| 48 | 14116341 | Tubular rivet |
| 49 | 34200198 | Pressure spring |
| 50 | 31602514 | Exhaust nozzle |
| 51 | 14111912 | Knurled-screw |
| 52 | 34200004 | Pressure spring |
| 53 | 31602073 | Base plate cpl. |
| 54 | 33912448 | Support |
| 55 | 31602072 | Holder cpl. |
| 56 | 33912452 | Locking plate |
| 57 | 14111390 | Cap screw |
| 58 | 33900495 | Plate |
| 59 | 14112007 | Fill. head screw |
| 60 | 34200182 | Pressure spring |
| 61 | 14111322 | Fillister head screw |
| 62 | 34336468 | Angle bracket |
| 63 | 31602075 | Parallel guide |
| 64 | 34111103 | Thumbscrew |
| 65 | 34435015 | Scale |
| 66 | 31603551 | Carbon brush |
| 67 | 31603305 | Handle bottom part |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Metabo OFE738 - 00738000
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N METABO:
- METABO S/N START WITH ( 0 ) and have 8 DIGITS
