Hikoki DH18DBL Cordless Rotary Hammer Spare Parts
€4.18
Tax included
Hikoki DH18DBL Cordless Rotary Hammer Spare Parts
Hitachi-HIKOKI Original spare parts sourced directly from the manufacturer, with after-sales assistance at the best price on the web for to repair Brushless Cordless Rotary Hammer DH18DBL.Fix Your Brushless Rotary Hammer DH18DBL Spares are original and can be supplied at Low and discounted prices.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hikoki DH18DBL Cordless Rotary Hammer Spare Parts
Fix Your Brushless Rotary Hammer DH18DBL Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.In the following table, look for the model of the Hammer and their spare part.
| Hitachi / Hikoki DH18DBL Cordless Rotary Hammer Spare Parts Pag.1 | ||
| Pos. | Codice | Description |
| 1 | 306345 | FRONT CAP |
| 2 | 306340 | STOPPER RING |
| 3 | 324527 | GRIP DH24PB3-PC3 |
| 4A | 371326 | BALL HOLDER (FW) |
| 5 | 324526 | HOLDER PLATE |
| 6 | 322812 | HOLDER SPRING |
| 8 | 370306 | GEAR COVER ASS'Y INCLUD.10.11.18 |
| 10 | 335259 | OIL SEAL |
| 11 | 335260 | BALL BEARING 6805DD |
| 12 | 878885 | O-RING (S-18) |
| 13 | 322789 | PUSHING BUTTON |
| 14 | 317223 | PUSHING SPRING |
| 15 | 334011 | CHANGE LEVER |
| 17 | 335800 | SPRING (E) |
| 18 | 608VVM | BALL BEARING 608VVM |
| 19 | 959156 | STEEL BALLS D7.0 (10PCS) |
| 20 | 335261 | CYLINDER |
| 21 | 335264 | PIN D2.5 |
| 22 | 335263 | CYLINDER CLUTCH |
| 23 | 335265 | SECOND GEAR |
| 24 | 335266 | SPRING (A) |
| 25 | 301679 | WASHER |
| 26 | 948310 | RETAINING RING FOR D30 SHAFT |
| 27 | 335262 | OIL SEAL (A) |
| 28 | 335268 | HAMMER HOLDER © |
| 29 | 335795 | SLEEVE (FW) |
| 30 | 335269 | SECOND HAMMER |
| 31 | 335267 | HAMMER HOLDER (A) |
| 32 | 322805 | DAMPER (A) |
| 33 | 322808 | O-RING (C) |
| 34 | 324524 | DAMPER HOLDER DH24PB3-PC3 |
| 35 | 322807 | STOPPER RING |
| 36 | 335246 | STRIKER |
| 37 | 335247 | O-RING D17 |
| 38 | 301679 | WASHER (A) |
| 39 | 335255 | PISTON |
| 40 | 335794 | PISTON WASHER |
| 42 | 370309 | INNER COVER (B) |
| 43 | 370310 | O-RING |
| 44 | 370311 | INNER COVER (A) INCLUD.53.54.62-64 |
| 46 | 335793 | PISTON PIN |
| 47 | 335249 | RECIPROCATING BEARING |
| 48 | 335250 | BEARING WASHER |
| 49 | 370312 | BEARING HOLDER (B) |
| 50 | 608VVM | BALL BEARING 608VVM |
| 51 | 370313 | BEARING COVER (A) |
| 52 | 370314 | BEVEL GEAR (A) |
| 53 | 334008 | AIR CAP |
| 54 | 324543 | FELT PACKING (A) |
| 55 | 335275 | PINION SLEEVE |
| 56 | 335276 | LOCK PLATE |
| 57 | 335278 | SECOND PINION |
| 58 | 323182 | CLUTCH SPRING |
| 59 | 335254 | CLUTCH |
| 60 | 331315 | WASHER DH22PH |
| 61 | 335277 | SECOND SHAFT |
| 62 | 370315 | FELT PACKING |
| 63 | 370316 | PACKING WASHER |
| 64 | 872470 | O-RING S26 |
| 65 | 361035 | ROTOR (B) |
| 66 | 340944 | STATOR |
| 67 | 370321 | DAMPER (A) |
| 68A | 370676 | HOUSING (A).(B) SET INCLUD.67 |
| 69A | 370548 | SWITCH CONTROLLER ASS'Y (A) INCLUD.73 |
| 70 | 370327 | RUBBER CUSHION |
| 71 | 370545 | TERMINAL RUBBER BASE |
| 72 | 324225 | PUSHING BUTTON (B) WR18DL |
| 73 | 370322 | DC-SPEED CONTROL SWITCH |
| 74 | 370329 | BATTERY RUBBER (A) |
| 78 | 370954 | WIRING ASS'Y INCLUD. 66,69,79,73 |
| 94 | 376195 | BATTERY TERMINAL |
| STANDARD ACCESSORIES Pag.2 | ||
| 502 | 303709 | DEPTH GAUGE |
| 503 | 335273 | SIDE HANDLE |
| 504 | 370332 | CARRYING CASE |
| 505 | 402541 | CASE ASS'Y (STACKABLE 4) INCLUD.506-508 |
| 506 | 336472 | LATCH |
| 507 | 336473 | HANDLE |
| 508 | 336474 | HINGE |
| 509A | 370331 | INNER TRAY DH18DBL *376002 |
| 510 | 329897 | BATTERY COVER |
| 601 | 752098 | HAMMER DRILL CHUCK SET 13MM INCLUD.602 |
| 602 | 752053 | CHUCK HANDLE |
| 603 | 303335 | RUBBER CAP |
| 604 | 752097 | DRILL CHUCK AND ADAPTER SET INCLUD.605 |
| 605 | 744085 | CHUCK ADAPTER (G) (SDS PLUS) |
| 606 | 752058 | DRILL CHUCK 13VLRB-D INCLUD.607 |
| 607 | 331966 | FLAT HD. SCREW (LEFT HAND) M6X20 |
| 608 | 987576 | CHUCK WRENCH FOR 13VLB-D 1 |
| 609 | 752056 | DRILL CHUCK 13VLD-D INCLUD.602 |
| 610 | 971787 | DUST CUP |
| 611 | 931844 | STOPPER |
| 612 | 971511Z | + DRIVER BIT (A) NO.2 25L |
| 613 | 752254 | + DRIVER BIT (A) NO.3 25L |
| 617 | 306885 | DUST COLLECTOR (B) ASS'Y INCLUD.618 |
| 618 | 306910 | SOCKET ADAPTER (B) |
| 621 | 335782 | GREASE FOR ROTARY HAMMER (60G) |
| 622 | 335781 | GREASE FOR ROTARY HAMMER (500G) |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
