Hitachi Spare Parts for Demolition Hammer DH38MS
€2.21
Tax included
Hitachi Spare Parts for Demolition Hammer DH38MS
Hitachi-HIKOKI Original spare parts sourced directly from the manufacturer, with after-sales service at the lowest price on the web for to make maintenance or repair damaged parts for Rotary Demolition Hammer DH38MS.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Demolition Hammer DH38MS
Hitachi-HIKOKI Original spare parts sourced directly from the manufacturer, with after-sales service at the lowest price on the web for to make maintenance or repair damaged parts for Rotary Demolition Hammer DH38MS.
In the following table, look for the model of the Hammer and the respective parts of the code.
| Demolition Hammer 9 Joule - 6.4Kg DH38MS | ||
| # | Part Num. | Description |
| 1 | 331542 | FRONT CAP |
| 2 | 331541 | GRIP |
| 3 | 331540 | STOPPER RING |
| 4 | 331539 | NEEDLE HOLDER |
| 5 | 331538 | RETAINER SPRING |
| 6 | 331537 | SPRING HOLDER (A) |
| 7 | 331530 | CYLINDER CASE |
| 8 | 991712 | HEX. SOCKET HD. BOLT (W/FLANGE) M6X25 |
| 9 | 956996 | O-RING (1AS-60) |
| 10 | 331531 | RETAINER DAMPER |
| 11 | 331532 | RETAINER DAMPER WASHER |
| 12 | 331524 | RETAINER SLEEVE |
| 13 | 331536 | NEEDLE ROLLER D8X20 |
| 14 | 313396 | O-RING (C) |
| 15 | 331525 | SECOND HAMMER |
| 16 | 331224 | DAMPER WASHER |
| 17 | 321835 | DAMPER |
| 18 | 331225 | DAMPER HOLDER |
| 19 | 331526 | CYLINDER |
| 20 | 331533 | SPRING HOLDER (B) |
| 21 | 331534 | LOCK SPRING |
| 22 | 331535 | LOCK SLEEVE |
| 23 | 331527 | CLUTCH SPRING |
| 24 | 331528 | CLUTCH |
| 25 | 331529 | BEVEL GEAR |
| 26 | 331234 | THRUST WASHER |
| 27 | 331235 | STRIKER |
| 28 | 986104 | O-RING |
| 29 | 331221 | PISTON PIN |
| 30 | 326369 | PISTON |
| 31 | 321285 | CONNECTING ROD |
| 32 | 983162 | SEAL LOCK HEX. SOCKET HD. BOLT M4X12 |
| 33 | 331545 | CHANGE LEVER |
| 34 | 331544 | LEVER HOLDER |
| 35 | 311229 | RETAINING RING FOR D20 HOLE |
| 36 | 331543 | LEVER SHAFT |
| 37 | 873095 | O-RING (P-16) |
| 38 | 331548 | PIN D2X10 |
| 39 | 331546 | LEVER SPRING |
| 40 | 321311 | PUSHING BUTTON |
| 41 | 6201DD | BALL BEARING 6201DDCMPS2L |
| 42 | 325003 | DUST WASHER (B) |
| 43 | 360875E | ARMATURE 220V-230V |
| 44 | 331252 | FAN GUIDE |
| 45 | 953174 | HEX. HD. TAPPING SCREW D5X55 |
| 46 | 340753E | STATOR ASS'Y 220V-230V |
| 47 | 930703 | BRUSH TERMINAL |
| 48 | 331251 | HOUSING ASS'Y |
| 49 | 331210 | SLIP CLUTCH ASS'Y |
| 50 | 331211 | BEVEL PINION |
| 51 | 944109 | FEATHER KEY 3X3X8 |
| 52 | 331212 | COLLAR |
| 53 | 313050 | OIL SEAL (A) |
| 54 | 6002DD | BALL BEARING 6002DDCMPS2L |
| 55 | 331213 | WASHER |
| 56 | 331214 | WASHER (A) |
| 57 | 321281 | GEAR HOLDER |
| 58 | 331218 | SPRING (C) |
| 59 | 331217 | NEEDLE |
| 60 | 331215 | SECOND GEAR |
| 61 | 331219 | SPACER |
| 62 | 629VVM | BALL BEARING 629VVC2PS2L |
| 63 | 331220 | BEARING WASHER (C) |
| 64 | 992803 | SEAL LOCK HEX. SOCKET HD. BOLT M6X20 |
| 65 | 986940 | SEAL LOCK HEX. SOCKET HD. BOLT M6X45 |
| 67 | 994192 | HEX. SOCKET HD. BOLT (W/FLANGE) M5X16 |
| 68 | 331245 | CRANK COVER |
| 69 | 878713 | CYLINDER O-RING (B) |
| 70 | 331523 | CRANK CASE |
| 71 | 331549 | SEAL PACKING |
| 72 | 939540 | RETAINING RING FOR D10 SHAFT |
| 73 | 331208 | CRANK SHAFT |
| 74 | 948391 | RETAINING RING FOR D40 HOLE |
| 75 | 6203DD | BALL BEARING 6203DDCMPS2L |
| 76 | 996363 | O-RING (S-40) |
| 77 | 321274 | OIL SEAL (B) |
| 78 | 331209 | FIRST GEAR |
| 79 | 939299 | NEEDLE BEARING (M661) |
| 80 | 331253 | GEAR COVER |
| 81 | 307947 | WING BOLT M6X12 |
| 82 | 331248 | MOUNT |
| 83 | 949556 | NUT M6 |
| 84 | 331247 | HANDLE BOLT |
| 85 | 331246 | BAND |
| 86 | 330209 | SIDE HANDLE |
| 87 | 945161 | BRUSH CAP |
| 88 | 999043 | CARBON BRUSH (1 PAIR) |
| 89 | 958900 | BRUSH HOLDER |
| 90 | 938477 | HEX. SOCKET SET SCREW M5X8 |
| 91 | 982631 | WASHER (A) |
| 92 | 608VVM | BALL BEARING 608VVC2PS2L |
| 93 | 331254 | BEARING HOLDER |
| 94 | 331202 | TAIL COVER |
| 95 | 302089 | TAPPING SCREW (W/FLANGE) D5X20 (BLACK) |
| 96 | 331203 | NOISE SUPPRESSOR |
| 97 | 331204 | HANDLE |
| 98 | 330216 | INTERNAL WIRE 270L |
| 99 | 959141 | CONNECTOR 50092 |
| 102 | 958049 | CORD ARMOR D8.2 |
| 102 | 940778 | CORD ARMOR D10.7 |
| 103 | 981974 | INTERNAL WIRE |
| 104 | 313093 | SWITCH (C) (2P SCREW TYPE W/O LOCK) |
| 105 | 938307 | PILLAR TERMINAL |
| 106 | 959141 | CONNECTOR 50092 |
| 107 | 960266 | CORD CLIP |
| 108 | 984750 | TAPPING SCREW (W/FLANGE) D4X16 |
| 109 | 331205 | HANDLE COVER |
| 110 | 307028 | TAPPING SCREW (W/FLANGE) D4X25 (BLACK) |
| 111 | 331547 | DUST SEAL |
| 112 | 331550 | WASHER (FW) |
| 500 | 981840 | GREASE 30 GR |
| 501 | 308471 | GREASE 70 GR |
| 502 | 980927 | GREASE 500 GR |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
