Hitachi Spare Parts for Belt Sander SB-75
We supply original Hitachi-HIKOKI spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Belt Sander SB-75.
In the following table, look for the model of the BELT SANDER and theirs spare part.
| Belt Sander SB-75 | ||
| # | Part Num. | Description |
| 1C | 322598 | HOUSING SB75 |
| 2 | 958900 | CARBON BRUSH HOLDER |
| 4 | 931701 | LOCKING KEY |
| 5A | 340104M | FIELD 220-230V FOR SB10T-SB75 |
| 6 | 930703 | CARBON BRUSH TERMINAL |
| 9 | 953033 | INTERNAL CABLE |
| 10A | 953185 | FAN GUIDE |
| 11 | 953145F | ARMATURE 220-230V (SB75-SB10T) |
| 12 | 629VVM | BALL BEARING 629VVM |
| 13 | 954234 | WASHER |
| 14 | 6200VV | BALL BEARING 6200VVCM |
| 15 | 322590 | INTERNAL COVER |
| 15A | 322590 | INTERNAL COVER |
| 20A | 322588 | BODY SB75 |
| 21 | 935522 | WASHER |
| 22 | 953150 | Drive Pulley Assembly |
| 23 | 948213 | WASHER |
| 24 | 953151 | GEAR |
| 25 | 944109 | KEY 3X3X8 |
| 26 | 939540 | RING TYPE C X SHAFTS D.10 (10PZ) |
| 27 | 953152 | PINION |
| 28 | 6200VV | BALL BEARING 6200VVCM |
| 29 | 953153 | GEAR COVER |
| 29A | 322591 | GEAR COVER |
| 32A | 987532 | PULLEY (A) |
| 33 | 953154 | ROLLER PULLEY |
| 34 | 958874 | BELT |
| 35 | 953155 | BELT PROTECTION COVER |
| 37 | 953053 | SUCTION FAN |
| 38 | 953156 | DUST GUIDE |
| 39 | 953157 | FAN BOX COVER |
| 39A | 322589 | DUST PROTECTION SB10T |
| 42 | 953158 | GUIDE PLATE |
| 44A | 953159 | BELT TENSIONER |
| 45 | 953160 | FRONT ROLLER |
| 46 | 953161 | CUP WASHER |
| 47 | 953162 | PIN |
| 48 | 939540 | RING TYPE C X SHAFTS D.10 1 (10PZ) |
| 49 | 953163 | SPRING |
| 50 | 714500 | CABLE 5M 2 X 1.0 WITH PLUG |
| 51 | 958049 | SLEEVE D8.2 |
| 52 | 937631 | CORD CLIP |
| 54 | 956632 | Switch (2P Pillar Type) Wilock |
| 54A | 956632 | Switch (2P Pillar Type) Wilock |
| 56 | 956614 | DIODE 200-240 V |
| 57 | 960283Z | NOISE SUPPRESSOR |
| 58 | 953171 | Slide Switch (1 P Solder Type) |
| 59 | 959140 | Connector |
| 60 | 959141 | Connector |
| 63 | 953186 | HANDLE COVER (OLD 953164) |
| 64A | 319258 | REGISTRATION SCREW SB8V2 |
| 65 | 953071 | SPRING |
| 66 | 953165 | Shoe Cushion |
| 67 | 953166 | Shoe PLATE |
| 68 | 999043 | CARBON BRUSHE SET (1 PAIR) |
| 69 | 945161 | CARBON BRUSH CAP |
| 71 | 957561 | HITACHI LABEL |
| 79A | 323011 | DUST BAG (BLACK) |
| 79B | 322592 | DUST BAG (GRAY) |
| 80 | 953169 | PLATE |
| 81 | 938307 | PILLAR TERMINAL (OLD 938307Z / 512-31 |
| 82 | 981373 | TUBE D |
| 84 | 953175 | Metal D.10X14X12 |
| 85 | 949509 | RIVET D2.5X3.2 |
| 87 | 944516 | BEARING WASHER (B), Till 12.1985 |
| 90 | 971792 | Slide Switch Cover, Since 1.1986 |
| 93 | 953181 | @ WASHER (B) |
| 95 | 953184 | WASHER SB8V2 |
| 96 | 960282Z | INTERNAL WIRE (B) |
| 97 | 938108 | TERMINAL |
| 98 | 980063 | TERMINAL |
| 99 | 322596 | RIGHT HANDLE KNOB SB10T |
