Hitachi Spare Parts for Angle Grinder G13BY
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Angle Grinder G13BY.In the following table , look for the model of the grinder and the ripettivo spare part.
| ANGLE GRINDER HITACHI G13BY | ||
| # | Part Num. | Description |
| 1 | 372945 | BUTTON |
| 2 | 372944 | SPRING (A) |
| 4 | 372943 | O-RING (A) |
| 5 | 372946 | ROLLER |
| 7 | 372932 | GEARBOX INCLUD.1.2.4-6 |
| 9 | 372924 | WASHER 10.2X14.8X0.2 |
| 10 | 372925 | WASHER 10.2X14.8X0.1 |
| 11 | 372926 | WASHER 10.2X14.8X0.5 |
| 12 | 372931 | GEAR SET INCLUDE.9-11 |
| 13 | 372918 | SEAL |
| 14 | 372927 | LOWER COVER |
| 15 | 372959 | O-RING (B) |
| 16 | 372941 | COMPLETE LEVER INCLUDING.20 |
| 17 | 372949 | WASHER |
| 18 | 372922 | SPINDLE |
| 19 | 372933 | SPINDLE KIT INCLUDED.8.12-15.17.18.21 |
| 20 | 372916 | SPRING |
| 21 | 372929 | GEAR ASSY |
| 22 | HTA336865 | SIDE HANDLE M10 150 MM |
| 24 | 372901 | INTERNAL CARTER |
| 25 | 372956 | SPRING (C) |
| 26 | 372953 | LEVER |
| 27 | 372955 | SPRING (B) |
| 28 | 372954 | SUPPORT |
| 29 | 372952 | PLATE |
| 30 | 372950 | PLATE (B) |
| 32 | 372908 | WASHER 7.05X19.5X0.2 |
| 33 | 372907 | BEARING 8X22X7 |
| 34 | 372942 | SEEGER |
| 35 | 372957 | SPACER |
| 36 | 372951 | DISC BRAKE |
| 37 | 372938 | FAN |
| 38 | 372887 | ARMATURE INCLUDING.37 |
| 39 | 372904 | BEARING 6X19X6 |
| 40 | 372905 | BEARING SEAT |
| 41 | 372947 | MAGNET |
| 42 | 372958 | FLANGE |
| 43 | 372899 | FAN GUIDE |
| 44 | 372890 | STATOR FIELDS |
| 45 | 372898 | MOTOR HOUSING |
| 46 | 372936 | BRUSH HOLDER (2 PIECES) |
| 47 | 372939 | CARBON BRUSHE (1 PAIR) |
| 48 | 372892 | SWITCH |
| 50 | 371271 | CABLE CLAMP |
| 51 | 372911 | REAR COVER |
| 52 | 372894 | CABLE SLEEVE |
| 53 | 714500 | CABLE 5M 2 X 1.0 WITH PLUG |
| 54 | 372912 | REAR COVER |
| 56 | 372915 | WHEEL GUARD |
| 57 | 372702 | WHEEL NUT |
| 60 | 372902 | ELECTRONIC CARD |
| 61 | 372948 | PIVOTING BAR |
| 62 | 372914 | SLIDE SWITCH KNOB |
| 63 | 372910 | SLIDE BAR |
