authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Angle Grinder G23SW2.
In the following table, look for the model of the Angle Grinder and the respective parts of the code.
<
| Angle Grinder G23SW2 | ||
| # | Part Num. | Description |
| 2 | 337641 | PUSHING BUTTON |
| 3 | 320219 | SPRING |
| 4 | 337650 | GEAR COVER ASS'Y |
| 5 | 937033 | FELT WASHER |
| 6 | 320226 | SPECIAL NUT M10 |
| 7 | 6301VV | BALL BEARING 6301VVCMPS2L |
| 8 | 330031 | RUBBER RING |
| 9 | 337642 | WASHER |
| 10 | 948391 | RETAINING RING FOR D40 HOLE |
| 11 | 337640 | FAN GUIDE (B) |
| 12 | 360982E | ARMATURE 220V-230V |
| 13 | 337639 | FAN GUIDE (A) |
| 15 | 939542 | RETAINING RING FOR D12 SHAFT |
| 17 | 320229 | BEARING COVER (B) |
| 18 | 6302VV | BALL BEARING 6302VVCMPS2L |
| 19 | 990852 | FELT PACKING (B) |
| 20 | 320234 | SPINDLE |
| 21 | 320228 | SEAL PLATE |
| 23 | 994192 | HEX. SOCKET HD. BOLT (W/FLANGE) M5X16 |
| 25 | 338292 | WHEEL GUARD ASS'Y |
| 26 | 937907Z | WHEEL WASHER (C) |
| 27 | 937909Z | WHEEL NUT M14X2 |
| 28 | 306890 | LOCK PIN |
| 29 | 330688 | GEAR AND PINION SET |
| 30 | 340888E | STATOR 220V-230V |
| 31 | 330029 | DUST SEAL |
| 32 | 6000VV | BALL BEARING 6000VVCMPS2L |
| 33 | 337643 | HOUSING |
| 34 | 337646 | BRUSH HOLDER |
| 36 | 999059 | CARBON BRUSH (1 PAIR) |
| 37 | 337649 | BRUSH COVER |
| 38 | 305812 | TAPPING SCREW (W/FLANGE) D4X16 (BLACK) |
| 40 | 320239 | OFF/ON LOCK |
| 40 | 320238 | OFF/LOCK |
| 41 | 981373 | TUBE (D) |
| 43 | 940778 | CORD ARMOR D10.7 |
| 501 | 325491 | KEY |
| 503 | 333932 | CASE |
