Hitachi-HIKOKI Tanaka Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues fo Angle Grinder G13SR2.
In the following table , look for the model of the grinder and the ripettivo spare part.![]()
| Disc Grinder G13SR2 | ||
| # | Part Num. | Description |
| 2 | 302149 | GUARD PLATE |
| 3 | 301944 | PUSHING BUTTON WITH SPRING G13SB3 |
| 4 | 314125 | GEAR COVER ASS'Y |
| 5 | 309191 | SPECIAL NUT M6 |
| 6 | 321742 | PINION |
| 8 | 608VVM | BALL BEARING 608VVM |
| 9 | 301935 | INNER COVER |
| 10 | 360605E | ARMATURE G12SR2-G13SR2 |
| 11 | 306840 | FAN GUIDE |
| 12 | 963712 | STATOR SCREW D4X65 |
| 13 | 340552E | STATOR G12SR2-G13SR2 |
| 14 | 321722 | DUST SEAL |
| 15 | 626VVM | BALL BEARING 626VVM |
| 16 | 309929 | RUBBER BUSHING |
| 17 | 301943 | LOCK PIN |
| 18 | 316487 | RETAINING RING FOR D11 SHAFT |
| 19 | 316486 | WAVE WASHER |
| 20 | 321743 | GEAR |
| 22 | 938058 | BEARING COVER (B) |
| 23 | 6001VV | BALL BEARING 6001VV |
| 24 | 301946 | FELT PACKING |
| 25 | 301947 | PACKING GLAND |
| 27 | 302047 | WOODRUFF KEY |
| 28 | 321729 | SPINDLE M14 |
| 30 | 301949 | SET PLATE |
| 31 | 319116 | WHEEL GUARD ASS'Y |
| 32 | 376067 | WHEEL WASHER |
| 34 | 339579 | WHEEL WASHER M14 |
| 35 | 321741 | GEAR AND PINION ASS'Y G13SR2 |
| 36 | 314429 | SPRING |
| 37 | 314427 | SLIDE BAR |
| 38 | 314428 | SLIDE KNOB |
| 39 | 321721 | HOUSING ASS'Y G12SR2-G13SR2 |
| 41 | 314854 | EARTH TERMINAL |
| 42 | 980063 | TERMINAL |
| 43 | 994273 | NOISE SUPPRESSOR |
| 44 | 314432 | SWITCH HOLDER |
| 45 | 938307 | PILLAR TERMINAL (OLD 938307Z / 512-31 |
| 47 | 936551 | BRUSH CAP |
| 48 | 999021 | CARBON BRUSHE (1 PAIR) |
| 49 | 313777 | BRUSH HOLDER |
| 50 | 314603 | SWITCH (1P SOLDER TYPE) |
| 52 | 980063 | TERMINAL |
| 53 | 937631 | CORD CLIP |
| 55 | 953327 | CORD ARMOR D8.8 |
| 56 | 321726 | TAIL COVER G12SR2-G13SR2 |
| 58 | 714500 | CORD 5M 2 X 1.0 WITH PLUG |
| STANDARD ACCESSORIES | ||
| 501 | 938332Z | WRENCH |
| 502 | 711283 | SIDE HANDLE M10 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
