Hitachi Spare Parts for Angle Grinder G23UDY
€1.78
Tax included
Hitachi Spare Parts for Angle Grinder G23UDY
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Angle Grinder G23UDY.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Angle Grinder G23UDY
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Angle Grinder G23UDY.
In the following table , look for the model of the grinder and their respective spare parts.
| Disc Grinder 230 mm G 23UDY | ||
| # | Part Num. | Description |
| 1 | 984509 | SEAL LOCK HEX. SOCKET HD. BOLT M5X14 |
| 2 | 949454 | SPRING WASHER M5 (10 PCS.) |
| 3 | 323209 | TAPPING SCREW (W/FLANGE) D5X35 (BLACK) |
| 4 | 306888 | PUSHING BUTTON |
| 5 | 320219 | SPRING |
| 6 | 326717 | GEAR COVER ASS'Y |
| 7 | 320226 | SPECIAL NUT M10 |
| 8 | 320221 | SEAL WASHER |
| 9 | 320222 | FELT PACKING |
| 10 | 6301VV | BALL BEARING 6301VVCMPS2L |
| 11 | 994208 | RUBBER RING (B) |
| 12 | 320220 | BEARING COVER (A) |
| 13 | 360777E | ARMATURE 220V-230V |
| 14 | 320215 | FAN GUIDE |
| 15 | 984271 | HEX. HD. TAPPING SCREW D5X75 |
| 16 | 340846E | STATOR 230V-240V |
| 17 | 937033 | FELT WASHER |
| 18A | 336864 | SIDE HANDLE |
| 19 | 939540 | RETAINING RING FOR D10 SHAFT |
| 20 | 326722 | COUPLING COVER |
| 21 | 326721 | COUPLING DAMPER |
| 22 | 333147 | COUPLING |
| 23 | 328700 | INNER |
| 24 | 949236 | MACHINE SCREW M5X10 (10 PCS.) |
| 25 | 326723 | BEARING COVER (B) |
| 26 | 6302VV | BALL BEARING 6302VVCMPS2L |
| 27 | 990852 | FELT PACKING (B) |
| 28 | 326727 | SPINDLE |
| 29 | 320228 | SEAL PLATE |
| 30 | 320227 | PACKING GLAND |
| 31 | 994192 | HEX. SOCKET HD. BOLT (W/FLANGE) M5X16 |
| 32 | 311492 | LABEL |
| 33 | 321546 | SET PIN |
| 34 | 321545 | LEVER |
| 35 | 306887 | BOLT M8X22 |
| 36 | 949457 | SPRING WASHER M8 (10 PCS.) |
| 37 | 321544 | SET PIECE |
| 38 | 673489 | RETAINING RING (E-TYPE) FOR D5 SHAFT |
| 39 | 321547 | WHEEL GUARD ASS'Y |
| 39A | 337225 | WHEEL GUARD ASS'Y |
| 40 | 937908Z | WHEEL WASHER (B) |
| 40A | 937907Z | WHEEL WASHER (C) |
| 41 | 316825 | D. C. WHEELS 230MM A24R (25 PCS.) |
| 42 | 937909Z | WHEEL NUT M14X2 |
| 43 | 320218 | O-RING |
| 44 | 306890 | LOCK PIN |
| 46 | 326718 | GEAR AND PINION SET |
| 47 | 330029 | DUST SEAL |
| 48 | 6000VV | BALL BEARING 6000VVCMPS2L |
| 49 | 321536 | BEARING BUSHING |
| 50 | 326712 | HOUSING ASS'Y |
| 51 | 326715 | BRUSH COVER |
| 52 | 305812 | TAPPING SCREW (W/FLANGE) D4X16 (BLACK) |
| 53 | 999089 | CARBON BRUSH (AUTO STOP TYPE) (1 PAIR) |
| 53 | 999061 | CARBON BRUSH 7X17X22.5 (1 PAIR) |
| 54 | 322323 | BRUSH HOLDER SET |
| 55 | 326714 | HANDLE (B) |
| 56 | 326726 | HANDLE DAMPER |
| 57 | 326724 | O-RING |
| 58 | 326725 | O-RING |
| 60 | 326716 | BRUSH COVER |
| 62 | 330216 | INTERNAL WIRE 270L |
| 63 | 959140 | CONNECTOR 50091 (10 PCS.) |
| 64 | 959141 | CONNECTOR 50092 (10 PCS.) |
| 65 | 335122 | CONTROLLER SWITCH 250V |
| 66 | 984750 | TAPPING SCREW (W/FLANGE) D4X16 |
| 67 | 960266 | CORD CLIP |
| 68 | 326713 | HANDLE (A) |
| 69 | 981373 | TUBE (D) |
| 70 | 940778 | CORD ARMOR D10.7 |
| 70 | 958049 | CORD ARMOR D8.2 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
