Hitachi Spare Parts for Jigsaw CJ110MVA

Hitachi-HIKOKI Tanaka

 authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Jigsaw CJ110MVA.

In the following table, look for the model of the Jigsaw and theirs spare part.
Hitachi CJ110MVA

JIGSAW CJ110MVA
# Part Num. Description
1 325419 HOUSING (A).(B) SET
2 930153 SUPPORT (B)
3 325415 PRINTED CIRCUIT BOARD (LED LIGHT)
4 960356 TERMINAL (A) M3.5
5 325418 CONTROLLER 230V-240V
5A 321597 CONTROLLER CIRCUIT 230V-240V
6 984528 O-RING (P-6)
7 301653 TAPPING SCREW (W/FLANGE) D4X20 (BLACK)
9 960356 TERMINAL (A) M3.5
10 953327 CORD ARMOR D8.8
11 937631 CORD CLIP
12 984750 TAPPING SCREW (W/FLANGE) D4X16
13 321594 SLIDE BAR
15 305499 MACHINE SCREW (W/WASHER) M3.5X6
16 938307 PILLAR TERMINAL
17 955509 SWITCH (1P SCREW TYPE)
21 608VVM BALL BEARING 608VVC2PS2L
22A 360741E ARMATURE 220V-230V
23A 340545E STATOR 220V-240V
24 323420 RUBBER RING
25 608VVM BALL BEARING 608VVC2PS2L
26 999041 CARBON BRUSH (1 PAIR)
27 955203 BRUSH HOLDER
28 311741 TERMINAL
29 325078 FRONT COVER
30 325083 TAPPING SCREW (W/FLANGE) D4X12 (BLACK)
31 325414 SLIDE KNOB
32 325082 LIGHT BAR
33 321592 FENCE
34 325079 MACHINE SCREW (W/SP. WASHER) M4X8 (BLACK
35 321580 LEVER SPRING
36 325080 LEVER
37 325081 LEVER BOLT
38 325071 PLATE SPRING
39 983564 PIN D6
40 325070 PLUNGER HOLDER (A)
41 325072 PLUNGER
42 994251 RETAINING RING FOR D7 SHAFT
43 325069 CONNECTING PIECE
44 325242 NEEDLE BEARING
45 325068 GEAR
46 325067 BALANCE WEIGHT
47 325066 ORBITAL CAM
48 957540 WASHER (A)
49 325061 GEAR HOLDER
50 673489 RETAINING RING (E-TYPE) FOR D5 SHAFT
52A 326270 ROLLER HOLDER SET
53 325062 NEEDLE ROLLER
54 325241 SEAL LOCK HEX. SOCKET HD. BOLT M3X8
55 325077 SEAL LOCK HEX. SOCKET HD. BOLT M3X6
56 325076 BLADE HOLDER
57 325073 PLUNGER HOLDER (B)
58 325075 PACKING COVER
59 325074 PACKING
60 315500 MACHINE SCREW (W/WASHER) M4X8 (BLACK)
61 321576 RUBBER BUSHING
62 321573 BASE
63 321575 BASE LOCKER
64 949665 HEX. SOCKET HD. BOLT M5X14
65A 328331 PIN
66 325065 CHANGE KNOB
67 982454 SPRING (C)
68A 335297 STEEL BALL 5/32
69 872971 RETAINING RING (E-TYPE) FOR D3 SHAFT
