Hitachi Spare Parts for Engine Blower RB 24EAP
€16.40
Tax included
Hitachi Spare Parts for Engine Blower RB 24EAP
Hitachi original spare parts for to replace broken parts for to fix Engine Blower RB 24EAP.Compact and light, powerful and effective, great for cleaning up any surface from foliage.
The Hitachi blower ensures extraordinary results with minimum effort and a great time saving.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Engine Blower RB 24EAP
Hitachi original spare parts for to replace broken parts for to fix Engine Blower RB 24EAP.
In the following table, look for the model of Blower and the respective parts of the code.
| Engine Blower RB 24EAP | ||
| # | Part Num. | Description |
| 3 | 6698375 | MUFFLER |
| 4 | 6698374 | HEAT PROTECTION PLATE |
| 5 | 6698362 | CYLINDER |
| 7 | 6698365 | COVER PACKING |
| 8 | 6698363 | SCAVENGING COVER(A) |
| 11 | 6684865 | INSULATOR GASKET |
| 12 | 6698372 | FLASH PAN |
| 13 | 6698387 | CARBURETOR INSULATOR |
| 14 | 6698405 | CARBURETOR PACKING |
| 15 | 6698373 | CARBURETOR ASS'Y (WYC-27) |
| 18 | 6684696 | STOP RING |
| 19 | 6684692 | PUMP GASKET |
| 20 | 6684693 | PUMP DIAPHRAGM |
| 21 | 6691242 | PUMP PLATE |
| 25 | 6684695 | O-RING |
| 27 | 6691234 | CIRCUIT PLATE |
| 28 | 6696828 | PUMP BODY COMP. |
| 29 | 6685220 | DIAPHRAGM PACKING-METERING |
| 30 | 6684690 | METERING DIAPHRAGM |
| 31A | 6698844 | SEAL LOCK HEX. SOCKET BOLT (W/WASHERS)M5 |
| 34 | 6696832 | AIR CLEANER HOUSING |
| 35 | 6685139 | PRIMING PUMP COMP. |
| 36 | 6690347 | CLEANER ELEMENT |
| 37 | 6696831 | AIR CLEANER COVER |
| 38 | 6696549 | AIR CLEANER ASS'Y |
| 42 | 6698397 | IGNITION COIL ASS'Y |
| 44 | 6698364 | SCAVENGING COVER (B) |
| 45 | 6698366 | CYLINDER PACKING |
| 46 | 6698404 | PISTON RING |
| 47 | 6698368 | PISTON |
| 48 | 6684590 | CIR CLIP |
| 49 | 6684591 | PISTON PIN |
| 52 | 6698396 | MAGNETO ROTOR COMP. |
| 54 | 6698370 | CRANK CASE (B) ASS'Y |
| 55 | 6698371 | CRANK CASE PACKING |
| 57 | 6696533 | CRANK SHAFT COMP. |
| 59 | 6698369 | CRANK CASE (A) ASS'Y |
| 60 | 6696572 | RECOIL STARTER BODY ASS'Y INCLUDES 61-66 UP TO YEAR OF PRODUCTION JULY 2014 |
| 61 | 6693633 | SET SCREW |
| 63 | 6684675 | RECOIL SPRING |
| 72 | 6696471 | STARTER PULLEY ASS'Y |
| 79 | 6600408 | STARTER ASSY INCLUDE 80-81 SINCE 8 2014 |
| 80 | 6600407 | STARTER PULLEY |
| 85 | 6600405 | RECOIL REEL |
| 91 | 6698399 | THROTTLE WIRE COMP. |
| 92 | 6698391 | THROTTLE LEVER |
| 94 | 6685364 | STOP SWITCH |
| 95A | 6699427 | MUFFLER PROTECTOR |
| 97A | 6698716 | FUEL PIPE |
| 98 | 6698401 | FUEL PIPE (PINK) |
| 99A | 6697846 | RETURN GROMMET |
| 101 | 6698402 | FUEL TANK CAP ASS'Y |
| 102A | 6600317 | TANK (B) |
| 106 | 6698512 | BOLT (W/FLANGE) L23.8 |
| 107 | 6698394 | NOZZLE (B) |
| 108 | 6698393 | NOZZLE (A) |
| 113 | 6698378 | FAN |
| 120A | 6698931 | FUEL GROMMET |
| 121 | 6698844 | SEAL LOCK HEX. SOCKET BOLT (W/WASHERS)M5 |
