Hitachi Spare Parts for Engine Brush Cutter CG47EY-T
Hitachi original spare parts for to replace broken parts for to fix Engine Brush Cutter CG47EY-T.
In the following table, look for the model of the chainsaw and ripettivo spare part.
| ENGINE BRUSH CUTTER CG47EY-T | ||
| B3101 CYLINDER/PISTON/CRANK SHAFT Pag.1 | ||
| # | Part Num. | Description |
| 6 | 6687468 | SPARK PLUG CAP ASS'Y |
| 7 | 6688336 | SPARK PLUG RUBBER COVER |
| 8 | 6699319 | SPARK PLUG ASS'Y BPMR6A |
| 11 | 6685470 | CYLINDER SET |
| 12 | 6684586 | HEX.HOLE BOLT M5X18/S |
| 14 | 6685738 | CYLINDER GASKET |
| 15 | 6686126 | PISTON RING |
| 16 | 6685887 | PISTON SET |
| 17 | 6686019 | PISTON PIN 10X35 |
| 18 | 6686026 | PISTON PIN CIRCLIP |
| 20 | 6685993 | PISTON PIN COLLAR |
| 21 | 6686190 | CRANK SHAFT COMP. - DISCONTINUED |
| 22 | 6695602 | NEEDLE BEARING, 2X8.8 |
| 31 | 6686457 | WOODRUFF KEY 3X13X5 |
| B3102 CRANK CASE Pag.2 | ||
| 19 | 6695139 | SMALL NUT 10 |
| 26 | 6686553 | CRANK CASE ASS'Y |
| 27 | 6686713 | CRANK CASE GASKET |
| 28 | 6695637 | OIL SEAL UD15257 |
| 29 | 6695557 | BALL BEARING #6202, 35MM/OD |
| 30 | 6686463 | CRANK SHAFT WASHER 15.2X22 |
| 32 | 6686472 | CRANK SHAFT SHIM 0.20 |
| 32 | 6686473 | CRANK SHAFT SHIM 0.30 |
| 36 | 6695084 | HEX HOLE BUTTON SCREW 6X45 |
| 38 | 6684825 | HEX. SOCKET HD. BOLT (W/BUTTON) M |
| 45 | 6684826 | S.WASHER 6 |
| 46 | 6684872 | LOCK NUT M6 |
| 47 | 6694043 | OUTER RECEIVER |
| 51 | 6687371 | MAGNETO ROTOR COMP. |
| 52 | 6695185 | SMALL WASHER 10 |
| 54 | 6695139 | SMALL NUT 10 |
| 55 | 6687662 | IGNITION COIL |
| 56 | 6695339 | SCREW 5X18/S |
| 58 | 6684864 | SMALL WASHER 5X10 |
| 69 | 6688053 | GROMMET |
| 70 | 6687967 | LEAD WIRE ASS'Y |
| B3103 ENGINE 1 Pag.3 | ||
| 27 | 6692225 | FUEL TANK CUSHION RUBBER |
| 31 | 6689883 | INLET MANUFOLD GASKET |
| 32 | 6689950 | CARB. INSULATOR SET |
| 33 | 6689826 | CARBURETOR GASKET |
| 45 | 6690468 | CARBURETOR SET HDA306 |
| 045A | 6697706 | CARBURETOR SET HDA180A |
| 49 | 6695423 | SCREW 5X24WS |
| 51 | 6691004 | CHOKE LEVER |
| 52 | 6685267 | FUEL PIPE 2.5X4X90 |
| 052A | 6692347 | FUEL PIPE 2.5X4X80 |
| 53 | 6695139 | SMALL NUT 10 |
| 54 | 6695235 | INNER TOOTHED WASHER 10 |
| 55 | 6690080 | PRIMING PUMP COMP. |
| 055A | 6685139 | PRIMING PUMP COMP. |
| 63 | 6688166 | FUEL PIPE ASS'Y 3X5X230 |
| 64 | 6684619 | CLIP,6.3 DIA. |
| 65 | 6692273 | PUMP FILTER BODY ASS'Y |
| 66 | 6691526 | FUEL TANK, WHITE |
| 68 | 6697846 | RETURN GROMMET |
| 70 | 6691763 | TANK CAP D ASS'Y, BLACK |
| 76 | 6691927 | TANK HOLDING BAND |
| 77 | 6692193 | CUSHION RUBBER |
| 78 | 6695386 | SCREW 5X16/PS |
| 80 | 6691337 | SWIVEL CAP |
| 96 | 6684625 | TANK CAP CHAIN |
| B3104 ENGINE 2 Pag.4 | ||
| 1 | 6692777 | MUFFLER PROTECTOR |
| 2 | 6695383 | SCREW 5X12/PS |
| 3 | 6684667 | HEX.HOLE BOLT M5X12/S |
| 4 | 6684918 | WASHER M5 (BLACK) |
| 5 | 6695088 | HEX. HOLE BUTTON SCREW 6X65 |
| 6 | 6684639 | BOLT WASHER 6 |
| 7 | 6692463 | MUFFLER SET |
| 9 | 6692883 | MUFFLER SPECIAL GASKET |
| 10 | 6692648 | TAIL PIPE SET, SPARE |
| 11 | 6695325 | SCREW 4X8/S |
| 14 | 6692741 | MUFFLER GASKET |
| 16 | 6687242 | HEAT SHIELD |
| 23 | 6695389 | SCREW 5X18/PS |
| 25 | 6692205 | TANK BRACKET |
| 26 | 6692227 | FUEL TANK CUSHION RUBBER |
| 80 | 6699561 | CLUTCH SET ASS'Y |
| 81 | 6689645 | CLUTCH WASHER B |
| 82 | 6688615 | CLUTCH ARM |
| 83 | 6689429 | CLUTCH SPRING |
| 84 | 6695203 | WAVE WASHER 10 |
| 85 | 6689628 | CLUTCH STEP BOLT |
| B3105 RECOIL STARTER Pag.5 | ||
| 0 | 6697645 | RECOIL STARTER BODY ASS'Y |
| 1 | 6693025 | RECOIL STARTER BODY COMP. |
| 1 | 6697646 | RECOIL STARTER BODY COMP |
| 2 | 6693007 | STARTER ROPE REEL |
| 2 | 6697647 | STARTER ROPE REEL |
| 3 | 6693114 | RECOIL SPRING |
| 3 | 6697648 | RECOIL SPRING |
| 9 | 6693165 | STARTER ROPE |
| 9 | 6697649 | STARTER ROPE |
| 12 | 6693607 | STARTER HANDLE CAP |
| 14 | 6693232 | STARTER HANDLE |
| 014A | 6697650 | STARTER HANDLE |
| 17 | 6693634 | SET SCREW |
| 19 | 6693302 | STARTER PAWL |
| 19 | 6697643 | STARTER PAWL |
| 20 | 6684683 | STOP RING E5 |
| 20 | 6684683 | STOP RING E5 |
| 23 | 6695395 | SCREW 5X25PS |
| 24 | 6693345 | STARTER PAWL SPRING |
| 24 | 6697642 | STARTER PAWL SPRING |
| 25 | 6693395 | STARTER PULLEY |
| 25 | 6697644 | STARTER PULLEY ASS'Y |
| B3106 AIR CLEANER Pag.6 | ||
| 36 | 6699506 | CLEANER BODY SET |
| 036A | 6697705 | CLEANER BODY |
| 37 | 6692244 | COLLAR 5.8 |
| 38 | 6690848 | BLOW OVER CHECK BOARD COMP. |
| 39 | 6690357 | CLEANER ELEMENT |
| 41 | 6690149 | CLEANER COVER ASS'Y |
| 42 | 6690383 | COVER FIXING BOLT |
| 43 | 6695354 | SCREW CHEAD 5X60/S |
| B3107 CARBURETOR Pag.7 | ||
| 1 | 6685210 | SCREW |
| 2 | 6691420 | PUMP BODY |
| 3 | 6691455 | PUMP GASKET |
| 4 | 6691446 | PUMP DIAPHRAGM |
| 5 | 6684700 | INLET SCREEN |
| 17 | 6690766 | IDLE ADJUST SPRING |
| 18 | 6690736 | IDLE ADJUST SCREW |
| 22 | 6685215 | NEEDLE VALVE |
| 23 | 6690874 | VALVE SPRING |
| 24 | 6690819 | CONTROL LEVER |
| 25 | 6685219 | HINGE PIN |
| 26 | 6685218 | HINGE PIN SET SCREW |
| 27 | 6690840 | DIAPHRAGM GASKET |
| 27 | 6690838 | DIAPHRAGM GASKET |
| 28 | 6690829 | METERING DIAPHRAGM COMP. |
| 28 | 6690828 | METERING DIAPHRAGM COMP. |
| 29 | 6690434 | AIR PURGE COMP. |
| 30 | 6690860 | DIAPHRAGM COVER |
| 30 | 6690858 | DIAPHRAGM COVER |
| 31 | 6691310 | SET SCREW |
| 31 | 6685223 | SET SCREW |
| B3108 FAN CASE Pag.8 | ||
| 1 | 6688585 | CLUTCH DRUM |
| 3 | 6695558 | BALL BEARING #6202ZZ, 35MM/OD |
| 4 | 6695296 | STOP RING C35, INNER |
| 5 | 6695285 | STOP RING C15, OUTER |
| 15 | 6695093 | HEX.HOLE BOLT 6X25 |
| 66 | 6686975 | FAN CASE OR |
| 67 | 6695361 | SCREW 6X20/S |
| B3109 OPERATION PIPE Pag.9 | ||
| 1 | 6689476 | DRIVE SHAFT, 1552L |
| 2 | 6689403 | DRIVE SHAFT PIPE |
| 3 | 6689515 | BUSHING ASS'Y |
| 11 | 6691207 | KNOB BOLT |
| 13 | 6691143 | HANDLE BRACKET A |
| 14 | 6691159 | HANDLE BRACKET B |
| 15 | 6691237 | SUPPORT HOLDER |
| 16 | 6691232 | HANDLE SUPPORT COMP. |
| 17 | 6689102 | SPECIAL NUT M6X1.0 |
| 18 | 6689165 | ANTIVIBE RUBBER |
| 20 | 6695175 | LOCK NUT 6 UPSP |
| 21 | 6695094 | HEX. HOLE BOLT 6X30 |
| 22 | 6688016 | CORD CLAMP |
| 63 | 6687627 | HANDLE GRIP |
| 74 | 6688025 | CORD CLAMP |
| 86 | 6695797 | SHOULDER HARNESS D5 |
| 92 | 6691079 | HANDLE |
| B3110 THOTTLE LEVER Pag.10 | ||
| 84 | 6687549 | PROTECTION TUBU 990L |
| 95 | 6693730 | THROTTLE LEVER 20 |
| 98 | 6684721 | TRIGGER LOCK OUT |
| 100 | 6684722 | RETURN SPRING |
| 101 | 6684723 | THROTTLE LEVER |
| 106 | 6684725 | SCREW M4X20 (BLACK) |
| 107 | 6684726 | SCREW 5X30 (BLACK) |
| 108 | 6684727 | CONTAL NUT 5 |
| 110 | 6687441 | STOP SWITCH COMP. |
| 120 | 6694009 | THROTTLE WIRE |
| 125 | 6693956 | THROTTLE WIRE COMP. |
| B3111 GEAR CASE Pag.11 | ||
| 1 | 6688801 | GEAR CASE ASS'Y, 30 DIA |
| 2 | 6684709 | HEX.HOLE BOLT M5X25/S |
| 4 | 6684741 | STOP RING C28,INNER |
| 5 | 6684664 | STOP RING C12 OUTER |
| 6 | 6695532 | BALL BEARING #6001Z, 28MM/OD |
| 7 | 6684608 | BALL BEARING 6001 C3 |
| 9 | 6688703 | GEARCASE, SILVER |
| 10 | 6684834 | SPRING WASHER 5 |
| 11 | 6684829 | HEX. SOCKET HD. BOLT M5X12 |
| 12 | 6695437 | PLUS HEAD BOLT 8X10 |
| 13 | 6695524 | BALL BEARING #6000, 26MM/OD |
| 15 | 6688942 | GEAR SHAFT 6X11X14 |
| 16 | 6695563 | BALL BEARING #6203D, 40MM/OD |
| 17 | 6695298 | STOP RING C40, INNER |
| 18 | 6689022 | CUTTER HOLDER |
| 19 | 6689052 | CUTTER HOLDER CAP,6X11X14 |
| 20 | 6688982 | PROTECTION COVER A COMP. |
| 21 | 6695418 | SCREW 5X16/WS |
| 22 | 6689072 | CUTTER FIXING NUT,L/H |
| 23 | 6689157 | GEAR CASE WASHER |
| 26 | 6684714 | HEX.HOLE BUTTON SCREW 6X25S |
| 28 | 6690312 | COVER BRACKET 30 |
| 29 | 6690230 | BLADE GUARD 30 CE |
| 029A | 6690264 | BLADE GUARD 30 CE |
| 30 | 6684748 | GUARD HOLDER |
| 31 | 6690372 | COVER GUARD |
| 031A | 6690376 | BLADE GUARD |
| 32 | 6693386 | KNIFE |
| 032A | 6684750 | KNIFE |
| 34 | 6695334 | SCREW 5X12/S |
| 034A | 6684751 | TAPPING SCREW 4X14 |
| 35 | 6688866 | GEARPINION SET, SPARE |
| 36 | 6684965 | NUT M5 |
| 38 | 6684753 | TAPPING SCREW 5X20 |
| 38 | 6684753 | TAPPING SCREW 5X20 |
| B3112 TOOLS Pag.12 | ||
| 2 | 6684764 | BOX WRENCH (HEX. SOCKET 17/19) |
| 3 | 6693529 | HEX. WRENCH 5 |
| 4 | 6684813 | HEX. BAR WRENCH 4MM |
| 5 | 6695792 | BLADE B3/12/3.0 |
| 12 | 6688994 | PROTECTION COVER B |
| 30 | 6699542 | SAFETY GLASSES |
| 35 | 6692016 | CUTTER COVER |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
