Hitachi Parts for Engine Hedge Trimmer CH66EB (ST)
€1.11
Tax included
Hitachi Parts for Engine Hedge Trimmer CH66EB (ST)
Hitachi Original spare parts at attractive and competitive prices on the web, we are a licensed service center with a repair service able to quickly solve the maintenance or repair any issues for Engine Hedge Trimmer CH66EB (ST).Fix Your Engine Hedge Trimmer CH66EB (ST). All Spares can be supplied at discounted prices. Our Spares are Genuine.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Parts for Engine Hedge Trimmer CH66EB (ST)
Fix Your Engine Hedge Trimmer CH66EB (ST). All Spares can be supplied at discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Hedgecutter and the respective parts of the code.
| ENGINE HEDGE Trimmer Hitachi CH66EB (ST) | ||
| 1.01 CYLINDER / PISTON / COIL / CRANK SHAFT Pag.1 | ||
| # | Pat Num | Description |
| 1 | 6687476 | SPARK PLUG CAP |
| 3 | 6685480 | CYLINDER CW/ GASKET |
| 4 | 6684586 | SCREW M5X18 / S |
| 7 | 6685744 | CYLINDER GASKET |
| 8 | 6686118 | PISTON RING |
| 9 | 6685892 | PISTON W/ RINGS (2) AND FERMI (2) |
| 10 | 6696944 | PISTON PIN |
| 11 | 6686028 | CIRCLIP |
| 12 | 6686205 | CRANKSHAFT W / BEARING |
| 13 | 6695589 | NEEDLE BEARING |
| 27 | 6695589 | NEEDLE BEARING |
| 28 | 6684599 | SCREW EX68-4599 |
| 29 | 6688461 | IGNITION COIL CABLE |
| 36 | 6684597 | TUBE |
| 37 | 6687866 | CABLE |
| 38 | 6695939 | IGNITION COIL |
| 1.02 FLYWHEEL / CRANK SHAFT HOUSING Pag.2 | ||
| 21 | 6686574 | CRANKSHAFT CARTER |
| 22 | 6686720 | CARTER CRANKSHAFT GASKET |
| 23 | 6684607 | OIL SEAL TB 12227 |
| 24 | 6684608 | BEARING 6001 C3 NSK |
| 25 | 6684604 | SPACER 0,20 |
| 25 | 6684605 | SPACER 0.30 |
| 26 | 6691822 | RUBBER |
| 30 | 6684786 | SCREW M5X30S |
| 31 | 6687389 | FLYWHEEL |
| 32 | 6684611 | WASHER M8 |
| 33 | 6684971 | WASHER 8 |
| 34 | 6684612 | NUT M8 |
| 35 | 6686771 | STUD |
| 1.03 CARBURATOR / TANK / AIR CLEANER Pag.3 | ||
| 25 | 6689891 | GASKET |
| 26 | 6689966 | COLLECTOR C / GASKET |
| 27 | 6695515 | SCREW 5X25WS |
| 30 | 6689839 | GASKET |
| 33 | 6695670 | O-RING |
| 35 | 6690119 | FILTER BODY |
| 36 | 6690804 | BUSHING |
| 37 | 6691274 | VALVE |
| 38 | 6684658 | WAVY WASHER M8 |
| 39 | 6690843 | VALVE |
| 40 | 6684662 | WASHER |
| 41 | 6684660 | SCREW M5X60 |
| 43 | 6690364 | AIR FILTER |
| 44 | 6690415 | AIR FILTER COVER |
| 45 | 6689737 | SCREW |
| 46 | 6690487 | CARBURETOR WYL120 W/ GASKET |
| 50 | 6685247 | TUBE W / GROMMET |
| 51 | 6684619 | CLIP |
| 52 | 6698874 | DOUBLE MIXTURE FILTER |
| 53 | 6691582 | MIXTURE TANK |
| 55 | 6692244 | COLLAR 5.8 |
| 58 | 6695505 | HEX HOLE SCREW 5X18PS |
| 61 | 6691337 | TANK CAP |
| 63 | 6691716 | ORANGE TANK CAP |
| 70 | 6685139 | PRIMER |
| 77 | 6692347 | TUBE MIX |
| 78 | 6692346 | TUBE |
| 79 | 6697846 | RUBBER |
| 86 | 6692059 | CHAIN CAP |
| 1.04 RECOIL STARTER / MUFFLER / CYLINDER HOUSING Pag.4 | ||
| 3 | 6692795 | MUFFLER PROTECTION |
| 4 | 6692744 | MUFFLER GASKET |
| 5 | 6687252 | THERMAL PROTECTION |
| 6 | 6692477 | COMPLETE MUFFLER |
| 7 | 6684661 | WASHER M5 |
| 8 | 6685114 | SCREW M5X50 |
| 17 | 6688050 | RUBBER |
| 20 | 6695502 | BOLT ESA |
| 47 | 6688494 | COMPLETE CLUTCH |
| 61 | 6684636 | SCREW D4.5X16 |
| 62 | 6695441 | SCREW 4X12PS |
| 67 | 6687014 | FAN CASE COMP. DISCONTINUED |
| 68 | 6693072 | REEL |
| 69 | 6684678 | CAM PLATE |
| 70 | 6684677 | STARTER SPRING WITOUT-START |
| 71 | 6684675 | STARTER SPRING |
| 72 | 6684679 | SET SCREW |
| 73 | 6693172 | ROPE 3X890 |
| 74 | 6693237 | STARTER KNOB |
| 75 | 6684681 | COMPLETE STARTER COUPLING |
| 76 | 6687209 | DEFLECTOR |
| 77 | 6684685 | STARTER PAWL |
| 78 | 6684684 | PAWL SPRING |
| 79 | 6684683 | PIN |
| 1.05 CARBURATOR STUFF Pag.5 | ||
| 1 | 6684698 | SCREW |
| 5 | 6684697 | PIN |
| 7 | 6684696 | RING |
| 10 | 6684695 | O-RING |
| 11 | 6691888 | JET TO ES. 669-1888 |
| 13 | 6691457 | PUMP GASKET |
| 14 | 6684693 | PUMP MEMBRANE |
| 17 | 6684700 | NET FILTER |
| 18 | 6691430 | CARBURATOR CIRCUIT ESA 669-1430 |
| 19 | 6685220 | DISC GASKET |
| 20 | 6690827 | MEMBRANE DISC |
| 21 | 6685222 | LITTLE COVER |
| 22 | 6691312 | SCREW |
| 1.06 FRONT HANDLE GRIP Pag.6 | ||
| 1 | 6688377 | HANDLE GRIP SUPPORT |
| 2 | 6688096 | FRONT HANDLE GRIP |
| 3 | 6688485 | RUBBER RING |
| 4 | 6688412 | DAMPER |
| 5 | 6689680 | WASHER |
| 6 | 6684786 | SCREW M5X30S |
| 7 | 6696359 | PIN |
| 8 | 6686111 | SUPPORT |
| 9 | 6695054 | BOLT 5X40 |
| 10 | 6684834 | WASHER |
| 11 | 6684918 | WASHER M5 |
| 1.07 REAR HANDLE GRIP Pag.7 | ||
| 1 | 6686314 | LEFT HANDLE |
| 2 | 6686279 | RIGHT HANDLE |
| 3 | 6688230 | THROTTLE LEVER |
| 4 | 6688240 | SAFETY LEVER |
| 5 | 6688244 | THROTTLE SPRING LEVER |
| 6 | 6687770 | STOP BUTTON |
| 7 | 6688246 | LEVER |
| 8 | 6688279 | SPRING |
| 9 | 6685070 | WASHER |
| 10 | 6685161 | SCREW D4X10 |
| 11 | 6684636 | SCREW D4.5X16 |
| 12 | 6693943 | THROTTLE CABLE |
| 13 | 6688366 | BUTTON |
| 14 | 6684913 | SCREW 3X10 |
| 15 | 6687524 | PROTECTION |
| 16 | 6694588 | STOP SWITCH |
| 1.08 BLADE / GEARS CASE/ BLADE DRIVE Pag.8 | ||
| 1 | 6688684 | GEAR BOX COMP. |
| 2 | 6695285 | SEEGER |
| 3 | 6002C3 | BEARING 6002C3 |
| 4 | 6695538 | BEARING |
| 5 | 6688570 | CLUTCH DRUM |
| 7 | 6686612 | PLATE |
| 8 | 6686811 | ROD |
| 9 | 6688625 | GEAR |
| 10 | 6688909 | GEAR COVER GASKET |
| 11 | 6692101 | COVER |
| 12 | 6687147 | CUTTER GUIDE (734MM) |
| 13 | 6687285 | PROTECTION |
| 14 | 6695075 | SCREW M6X25 |
| 15 | 6687086 | BLADE (696.5 MM) |
| 16 | 6686654 | FELT |
| 17 | 6687187 | WASHER D7 |
| 18 | 6687158 | SCREW M6 |
| 19 | 6695170 | NUT M6 |
| 21 | 6684595 | SCREW M4X12 / S |
| 22 | 6688643 | GREASE |
| 23 | 6695495 | SCREW |
| 30 | 6690762 | PLATE |
| 32 | 6695175 | NUT M6 |
| 33 | 6684639 | WASHER M6 |
| 60 | 6688844 | GEAR CASE COVER |
| 69 | 6687302 | BLADE PROTECTION |
| 72 | 6695475 | NUT M6 |
| 82 | 6695484 | SCREW 4X10S |
| 83 | 6687275 | PROTECTION |
| 88 | 6695547 | BEARING 608 ZZ C3 |
| SPECIAL TOOLS Pag.9 | ||
| 2 | HGA6695736 | FLYWHEEL PULLER |
| 3 | HGA6695737 | FLYWHEEL PULLER BOLT |
| 5 | HGA6695740 | PISTON PIN PULLER |
| 14 | HGA6695754 | CLUTCH PULLER |
