Hitachi Spare Parts for Engine Grass Trimmer CG25EUS

Name: Hitachi Spare Parts for Engine Grass Trimmer CG25EUS
Brand: HiKOKI Power Tools Italia S.p.a.
SKU: Hitachi CG25EUS
Price: 1.76 EUR
Availability: InStock

€1.76

Tax included

Hitachi Spare Parts for Engine Grass Trimmer CG25EUS

Hitachi-HIKOKI Tanaka authorized service center and original spare parts Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Engine Grass Trimmer CG 25EUS.

ITEM CODE: 6684590

6696462
6696461
6696460
6696458
6696455
6696452
6696451
6696450
6696440
6696439
6696437
6696436
6696432
6696431
6696430
6696429
6696427
6696426
6696425
6696421
6696420
6696419
6696418
6696417
6696416
6696413
6685410
6685407
6685391
6685337
6685311
6685310
6685308
6685139
6684751
6684750
6684714
6684709
6684667
6684658
6684655
6684648
6684642
6699402
6685199
6684590
6684591
6684628
6684636
6699188
6698798
6698793
6698720
6698717
6698644
6698643
6698514
6697846
6696980
6696977
6696974
6696965
6696964
6696963
6696957
6696956
6696954
6696950
6696948
6696940
6696593
6696558
6696494
6696492
6696490
6696488
6696487
6696486
6696479
6696471
6696470
6696469
6696464
6696951
6696454

Quantity

Usually Ships in: 7/10 Business Days Approx.

Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Description
Product Details
Attachments

Hitachi Spare Parts for Engine Grass Trimmer CG25EUS

Hitachi-HIKOKI Tanaka authorized service center

and original spare parts Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Engine Grass Trimmer CG 25EUS.

In the following table, look for the model of the Trimmer and ripettivo spare part.

ENGINE GRASS TRIMMER CG 25EUS
#	Part Num.	Description
1	307635	MACHINE SCREW (W/SP. WASHER) M4X10
2	6696440	CYLINDER HEAD COVER
3	949566	LOCK NUT M5 (10 PCS.)
4	6696438	PIVOT ROCKER ARM
5	6696437	PUSH ROD
6	6696432	TAPPET
7	6696442	BREATHER PIPE
8	6696439	ROCKER ARM
9	6696415	SHAFT BOLT
10	6696414	PUSH ROD GUIDE
11	6685409	HEX. SOCKET HD. BOLT M5
12	6696462	MUFFLER
13	6696460	MUFFLER GASKET(A)
14	6696461	WIND GUIDE PLATE (B)
16	6696421	RETAINER VALVE
17	6696420	VALVE SPRING
18	6696418	STEM SEAL BASE
19	6696419	STEM SEAL
20	6696465	SPARK PLUG CAP
21	6696996	METAL FITTING OF PLUG CAP
22A	6699310	SPARK PLUG ASS'Y CMR5H
23	6696450	INSULATOR GASKET
24	6696451	WIND GUIDE PLATE (A)
25	6696452	INSULATOR
26	880561	MACHINE SCREW (W/WASHERS) M5X30
27	6696954	CARBURETOR GASKET
30	6684629	THROTTLE WIRE FIXING PLATE
31	6696956	INSULATOR GASKET (B)
32	6696957	CARBURETOR
45	6684628	SWIVEL CAP
46	6696958	HEX. SOCKET BOLT M5X20
47	6696413	CYLINDER (A)
48	6696436	CYLINDER GASKET
49	6696417	INTAKE VALVE
50	6696416	EXHAUST VALVE
51	6696444	PUMP GASKET
52	6696443	BASE PUMP
53	6696445	INNER ROTOR
54	6696446	OUTER ROTOR
55	6696447	COVER PUMP
56	696997	MACHINE SCREW (W/SP. WASHER) M4X16(BLACK
57	6696429	1ST RING
58	6696430	2ND RING
59	6696431	OIL RING
60	6696427	PISTON
61	6684590	CIR CLIP
62	6696425	CRANK CASE GASKET
63	6684607	OIL SEAL TB 12227
64	6684608	BALL BEARING 6001 C3
65	6696426	CRANK SHAFT GEAR SET
66	6684591	PISTON PIN
67	6696434	SHIM
68	6696433	CAM SHAFT SET
69	6696449	OIL CAP
70	6696959	O-RING (I.D 13.8)
71	6685391	NEEDLE ROLLER D3
72	321905	STEEL BALL D4 (10 PCS.)
73	6696960	CRANK CASE ASS'Y (B)
74	6685310	OIL FILTER BODY
75	6690919	OIL FILTER
76	6685407	BOLT WASHER D5
77	6685311	CLIP
78	6696435	FUEL PIPE
79	6684599	HEX.HOLE BOLT M4X18/WS
80	6696470	RECOIL STARTER BODY ASS'Y
85	6693168	ROPE
88	6696472	SEAL LOCK SCREW M4
93	6696471	STARTER PULLEY ASS'Y
94	6696455	CLEANER BODY
95	6684657	CHOKE VALVE
96	6684659	COLLAR 8
97	6684658	WAVE WASHER 8
98	6685407	BOLT WASHER D5
99	6696961	MACHINE SCREW (W/SP. WASHER) M5
100A	6698720	FUEL PIPE
101	6685139	PRIMING PUMP COMP.
102	6696459	CLEANER ELEMENT
103	6696458	CLEANER COVER
104	6684655	COVER FIXING BOLT
105	6685408	WASHER 5
106	6685408	WASHER 5
107	949566	LOCK NUT M5 (10 PCS.)
108	6600329	MUFFLER HEAT COVER
109	6600327	MARK PLATE (T)
110	6699000	PRIMER LABEL
121	6684667	HEX.HOLE BOLT M5X12/S
122	305583	HEX. SOCKET HD. BOLT (W/SP.WASHER) M5X20
123	6696963	ANTI VIBE RUBBER (A)
124A	6698643	PIPE HOLDER (A)
125A	6698644	PIPE HOLDER (B)
126	6696964	ANTI VIBE RUBBER (B)
128	6684636	TAPPING SCREW D4.5X16
129A	6600331	ENGINE COVER (W/ALUMINUM TAPE)
131	6696469	STEP BOLT
132	6684648	BENT WASHER 8
133	6696965	CLUTCH PLATE (A)
134	6696948	CLUTCH
135	6684642	CLUTCH WASHER B
136	6685337	FLYWHEEL NUT
137	6685410	BOLT WASHER D8
138	6696464	MAGNET ROTOR
139	6684599	HEX.HOLE BOLT M4X18/WS
140	6696463	IGNITION COIL SET
141	6696467	STOP CORD
142	6696966	CORD INSULATION TUBE
143	6696466	EARTH CORD
144	939542	RETAINING RING FOR D12 SHAFT (10 PCS.)
146B	6600330	FAN CASE (A) W/ALUMINUM TAPE
147B	6698793	CLUTCH SHAFT
*148	305812	TAPPING SCREW (W/FLANGE) D4X16 (BLACK)
*149	6696487	HANDLE (B)
150	6696490	LOCK LEVER
151	6696488	LEVER
152	6696489	SPRING (A)
*153	6696486	HANDLE (A)
154	6696940	STOP SWITCH
*155	6696491	STOP SWITCH CORD
*156	6696967	PROTECTION TUBE
*157	6696492	THROTTLE WIRE (EU)
*158	6696474	TANK
159	6685199	PUMP FILTER BODY
160	6696477	STAND
161	6696478	COLLAR
162	6684709	HEX. HOLE BOLT M5X25/S
163A	6698717	FUEL PIPE
164	6696476	FUEL PIPE (PINK)
165A	6697846	RETURN GROMMET
166	6685308	FUEL GROMMET (A)
167	6600333	REAR COVER
*167	6696479	TANK CAP ASS'Y (A)
168	305583	HEX. SOCKET HD. BOLT (W/SP.WASHER) M5X20
168	6600332	TAPPING SCREW D4
169	6685408	WASHER 5
170	6685311	CLIP
171	6685408	WASHER 5
172	6600333	REAR COVER
173	6600332	TAPPING SCREW D4
181	323837	TAPPING SCREW (W/FLANGE) D4X30
182	6696590	HANDLE (B)
183	323041	MACHINE SCREW M5X30 (BLACK)
*184	6698637	HANDLE RIGHT
185	6696577	HANDLE HOLDER (B)
186	6696578	HANDLE HOLDER (C)
187	6684714	HEX. HOLE BUTTON SCREW 6X25S
188	6684709	HEX. HOLE BOLT M5X25/S
189	6696576	HANDLE HOLDER (A)
190	6696588	HANDLE (A)
191	302012	NUT M5 (BLACK)
*192	6698638	HANDLE (LEFT)
194	6696973	BARRIER
195	6696974	BOLT (BLACK) M6
*196	949566	LOCK NUT M5 (10 PCS.)
*197	6696975	LOOP HANDLE
*198	6696976	GEAR CASE ASS'Y 3BB (B) SET
198A	6699402	GEAR CASE ASS'Y 3BB(A)
199	6684737	BOLT (W/PLUS) M6X8
206	6696977	CUTTER HOLDER (A)
208A	6699188	NUT COVER
209A	335759	U-NUT (LEFT HAND) M10
216	6696494	COVER BRACKET
217	6684714	HEX. HOLE BUTTON SCREW 6X25S
224	6684851	LEVEL MARK
225	6696558	MAIN PIPE COMP.
226A	6698514	DRIVE SHAFT
227	6696493	HANGER
228	6698794	COVER
230	6698795	SET SCREW
231	6698796	REEL
232	6698797	RETURN SPRING
233	6698798	BUTTON
234	6698799	CORD GUIDE
235	6698800	CASE
236	6696454	NYLON HEAD ASS'Y
237	6696950	COVER GUARD
238	6684751	TAPPING SCREW 4X14
239	6684750	KNIFE
240	6696951	GUARD HOLDER
241	6696980	COVER
247	305812	TAPPING SCREW (W/FLANGE) D4X16 (BLACK)
248	6696592	STOP SWITCH CORD
249	6696593	THROTTLE WIRE COMP.
250	6696594	PROTECTION TUBE
