FIAC Spare Parts for Air Compressor LEONARDO HP 1
€357.28
Tax included
FIAC Spare Parts for Air Compressor LEONARDO HP 1
Distribution and Sale at attractive prices of FIAC Original Spare Parts. Low prices and a professional Assistance guarantee, repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Air Compressor LEONARDO HP 1.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
FIAC Spare Parts for Air Compressor LEONARDO HP 1
Distribution and Sale at attractive prices of FIAC Original Spare Parts. Low prices and a professional Assistance guarantee, repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Air Compressor LEONARDO HP 1.
In the following table, look for the type of the Air Compressor and the respective parts of the code.
| Air Compressor LEONARDO HP 1 | ||
| # | Part Num. | Description |
| 1 | 7030190000 | Washer Ø6,4X18X1,5 UNI-6593 |
| 2 | 7011290000 | Screw M6X35 UNI-5739 |
| 3 | 7084080000 | Fitting "L" 1/4 FIL |
| 4 | 7570550000 | Head |
| 5 | 7070600000 | O-Ring |
| 6 | 4200030000 | VALVE PLATE KIT RPM 1400 |
| 7 | 7078490000 | Gasket |
| 8 | 4190270000 | Kit Rod / Piston |
| 9 | 7021010000 | Nut M6 UNI-7473 |
| 10 | 7060550000 | Bearing 6004 2RS1 / QE6 |
| 11 | 7200140000 | Cooling Fan |
| 12 | 7150800000 | CASING Compressor ECU RED |
| 13 | 7011040000 | Screw M6X20 UNI-5739 |
| 14 | 5040700008 | Crankshaft |
| 15 | 7670040000 | Casing |
| 16 | 7020240000 | Nut M8 DIN-6923 |
| 17 | 7060280000 | Bearing 6005-2Z |
| 18 | 5090330008 | Armature |
| 19 | 4011710000 | Stator 230V / 50Hz |
| 20 | 7310100000 | Capacitor MF.20 V450 |
| 21 | 7014300000 | Screw M4X12 UNI-8112 |
| 22 | 7013060000 | Screw M4X8 UNI-8112 |
| 23 | 7150580000 | Plastic Fairing |
| 24 | 7640100000 | Rear Motor Holder |
| 25 | 7030780000 | Washer |
| 26 | 7458340000 | Filter Plate |
| 27 | 7210450000 | Filter Cover |
| 28 | 7012010000 | Screw Ø3,9X19 UNI-6954 |
| 29 | 7060010000 | Bearing 6203 ZZ 17:40:12 QE6 |
| 30 | 7018010000 | Screw M6x139 UNI-5737 |
| 31 | 7250740000 | Pressure Switch |
| 32 | 7100380000 | Pressure Reducer |
| 33 | 7081090000 | Fitting 1/4 "MM |
| 34 | 7130570000 | Universal Tap M1 / 4 " |
| 35 | 7090070000 | M Cap 1/4 " |
| 36 | 7087910000 | Fitting 1/4 MM |
| 37 | 7110240000 | Gauge Ø40-1 / 8 " |
| 38 | 7070700000 | O-Ring 4042 |
| 39 | 7230010000 | Rilsan Tube Ø6X4 |
| 40 | 7192430000 | Drain Valve M1 / 4 "-8.5 BAR |
| 41 | 7196960000 | Distributor |
| 42 | 7130090000 | Bleeding Tap M1 / 4 " |
| 43 | 7110240000 | Gauge Ø40-1 / 8 " |
| 44 | 7190200000 | Check Valve M1 / 4-Tube 10 |
| 45 | 7031210000 | Washer |
| 46 | 7070690000 | O-Ring 3056 |
| 47 | 7014000000 | Screw 1/4 "G ECUII |
| 48 | 5159920008 | Tank |
| 49 | 7360380000 | Rubber Foot Ø25 - 40 Sh |
| 50 | 7030020000 | Ø6 Washer UNI-6592 |
| 51 | 7012090000 | Screw M5x12 UNI-8112 |
| 52 | 7239380000 | Tube Feeding |
| 53 | 7329070000 | Power Cable |
| 54 | 7210590000 | Filter Element |
| 55 | 7012290000 | Screw M5X20 TAP-TITE |
| 100 | 4280100000 | GR.CARTER-TREE-ROTOR F-114 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Fiac LEONARDO HP 1
