Distribution and Sale at attractive prices of FIAC Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Pump Unit GM 142 Aluminium 09-06-18.
(modificale nel modulo Rassicurazioni cliente)
(modificale nel modulo Rassicurazioni cliente)
(modificale nel modulo Rassicurazioni cliente)
Distribution and Sale at attractive prices of FIAC Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Pump Unit GM 142 Aluminium 09-06-18.
In the following table, look for the model of the Pumping Unit and the respective parts of the code .![]()
| GM 142 ALUMINIUM 09-06-18 | ||
| SINGLE PHASE V.230/50Hz cod.9101721000 | ||
| MONOFASE V.230/50Hz cod.9101721000 | ||
| # | Part Num. | Description |
| 1 | 7011220000 | Screw |
| 1A | 9700010186 | washer |
| 2 | 7084040000 | Joint |
| 3 | 7458340000 | Plate |
| 4 | 7210010000 | Filtering element |
| 5 | 7210430000 | Intatake filter |
| 6 | 7012100000 | Screw |
| 7 | 9100010190 | START valve 1.7Bar |
| 8 | 9101410070 | Head |
| 9 | 9101410080 | Gasket |
| 10 | 9100010240 | Valve plate |
| 11 | 9100010080 | Gasket |
| 12 | 9100010370 | Valve |
| 13 | 9101410090 | Gasket |
| 14 | 9101410060 | Cylinder |
| 15 | 7020070000 | Nut - Dado M8 UNI 5587 |
| 16 | 7078150000 | Gasket 1mm |
| 18 | 9100580050 | Piston |
| 19 | 9100580090 | Piston pin |
| 20 | 7041010000 | Seeger D12 |
| 21 | 5050150008 | Con rod |
| 22 | 9101720040 | Rear Cover |
| 23 | 7060200000 | Bearing |
| 25 | 9101410050 | Counter weight |
| 26 | 9100030090 | Plastic schroud Black |
| 28 | 9101410020 | Carter cover |
| 29 | 7012160000 | Screw |
| 30 | 9700010187 | Screw |
| 31 | 9700000016 | O-Ring (110,7X3,53) |
| 32 | 9100270150 | Oil seal |
| 33 | 9101720030 | Cranckcase |
| 35 | 9101720010 | Stator |
| 36 | 7060010000 | Bearing |
| 37 | 7310590000 | Capacitor |
| 38 | 9700010188 | Nut M8 |
| 38A | 9700010184 | washer D8 |
| 40 | 9100010060 | Tension rod M6x138x25 |
| 41 | 9100010200 | Fan |
| 42 | 7013060000 | Screw |
| 42A | 9700010183 | washer D4 |
| 43 | 9100010050 | Stud bolt M8x36 |
| 100 | 7459480000 | Set of valve plate |
| 101 | 4190330000 | Conrod-Piston Kit |
| 102 | 4082380000 | Set of gaskets |
| 103 | 4080010000 | Piston ring Kit |
| 104 | 9101720060 | Cranckshaft with rotor |
| 105 | 9700010061 | Oil dipstick+O-ring Kit Green |
