Femi Spare Parts for Transportable Band Saws NG160 - 8486021
€2.43
Tax included
Femi Spare Parts for Transportable Band Saw NG160 - 8486021
We have the original Femi Spare Parts for Transportable Band Saw NG160, the diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Transportable Band Saw NG160 - 8486021. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine with a Full Guarantee
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Femi Spare Parts for Transportable Band Saws NG160 - 8486021
We have the original Femi Spare Parts for Transportable Band Saw NG160, the diagram, parts list and tool repair that help you need to get your tools running like new again.
In the following table, look for the model of the Band Saw and the respective parts of the code.
| Transportable Band Saw NG160-8486021 | ||
| # | Part Num. | Description |
| 2 | 5080132 | SPRING JOINT |
| 3 | 0063040 | BUSH FE SINT. D.14X22 H25 |
| 4 | 5124050 | WASHER JOINT |
| 5 | 0147003 | LEVER BLACK - ART.523-65-M 8X90 |
| 6 | 5042782 | SLIDE CLAMP BLACK |
| 7 | 5137922 | SUPPORT REVOLVING SEG. 1735 RAL 9006 (gr.grossa) |
| 11 | 5159513 | JOINT INDEX |
| 12 | 0063037 | BUSH FE SINT. D.8X12 H 20 |
| 13 | 0120718 | WASHER sheared D.8X24 SP.3 ZN |
| 15 | 7130552 | GROUP STOP BAR COMPLETE X 785 |
| 16 | 5133684 | BASE VICE SAW NG160 |
| 18 | 5124029 | LOG ECCENTRIC |
| 19 | 5404012 | SLIDE SUPPORT REVOLVING GRADUATED |
| 20 | 0402905 | RIVET AUT. ELIC. D.2,9X5 |
| 21 | 0144003 | HANDLE FOR TRANSPORT (224-151) |
| 23 | 5137796 | BASE PLATE |
| 24 | 5152504 | JAW FIXED VICE |
| 25 | 5130834 | SUPPORT SCREW VICE |
| 26 | 5100329 | SCREW VICE |
| 27 | 5130393 | VICE GUIDE |
| 29 | 5137778 | BRACKET SUPPORT REVOLVING |
| 30 | 5137793 | FOOT |
| 31 | 5124056 | WASHER FOR QUICK LOCK |
| 32 | 5171056 | BUSH CLAMPS NG160 |
| 33 | 0152630 | PLUG SPIROL 6X30 |
| 34 | 5142080 | LEVER FOR VICE NG160 |
| 35 | 0140073 | HANDLE PRESSURE ART.135-83 d1 = 12 |
| 39 | 5130394 | GUIDE UPPER SLIDE |
| 40 | 5124048 | WASHER THICKNESS SCREW VICE |
| 41 | 0063039 | BUSH FE SINT. C / COLL.D16X22X28X3,5 H14 |
| 42 | 0140059 | HANDLE PRESSURE HOLE 12 (510-37) |
| 43 | 5130744 | EXTENSION SCREW VICE |
| 44 | 5142023 | LEVER VISE |
| 45 | 0152631 | ELASTIC PIN D6X30 |
| 47 | 5182829 | HOUSING COVER CLAMP BLACK |
| 49 | 5152505 | JAW CLOSING VICE |
| 50 | 7213008 | FIRST GEAR ASSEMBLY |
| 51 | 0606205 | BEARING 6205 2RS 25x52x15 |
| 54 | 0586200 | BEARING 6200 10x30x 9 OPEN |
| 56 | 0150139 | TAB 6X6X20 UNI 6604 |
| 57 | 5154103 | GLAND PLATE |
| 59 | 5214022 | DRIVING PULLEY |
| 63 | 5001558 | SHAFT |
| 64 | 5137808 | SLIDE |
| 65 | 0155149 | WASHER THICKNESS PS 20X28 SPESS.1 |
| 66 | 0606204 | BEARING 6204 2RS 20x47x14 |
| 67 | 0155116 | WASHER THICKNESS PS 20X28 SPESS.0,5 |
| 69 | 5181736 | CARTER PROTECTION BLACK |
| 71 | 0140087 | WING KNOB TNB D25 M5 |
| 73 | 5124047 | WASHER WHEEL TIGHTENING |
| 74 | 7214210 | WHEEL |
| 75 | 7130593 | DEVICE. TENDIL. Clutch. COMPL. (NG160) |
| 77 | 0590624 | BEARING 624 ZZ 4x13x 5 |
| 78 | 5181738 | PLATE CLEANER KNIFE |
| 83 | 5081005 | SPRING TENSION BELT |
| 85 | 5130734 | GUIDE PULLEY SUPPORT NEUTRAL |
| 86 | 0080259 | CUP SPRING D.23X12.2X1.5 |
| 88 | 5181737 | PLATE BLACK |
| 89 | 5871048 | CORD 2X1X1200 C / FASTON C / PUSH RODS |
| 90 | 0802324 | INTERRUTTORE MONOFASE A BUTTON 8A LOCKOFF |
| 92 | 5050133 | HALF HANDLE LEFT |
| 93 | 5050132 | HALF HANDLE RIGHT |
| 95 | 0179901 | ROLLER D.10X10 |
| 96 | 5042780 | ARM FOR BAND SAWS 1735 RAL9006 (gr.grossa) |
| 97 | 7130588 | SLIDING GUIDE ASSEMBLY FOR BAND SAWS 1750 |
| 98 | 0147000 | LEVER BLACK-ART.522-43 M-6 |
| 99 | 0120706 | FLAT WASHER D.6,5X18 SP.1,5 ZN |
| 102 | 0120718 | WASHER D.8X24 SP.3 ZN |
| 103 | 0147006 | LEVER BLACK - ART.522-65 M-8 |
| 104 | 5130774 | BLADE GUIDE, REAR |
| 105 | 0174016 | NEEDLE D.4X15,8 |
| 106 | 0129004 | WASHER INOX D.4,3X8X0,5 DIN 433 A2 |
| 107 | 0590634 | BEARING 634 ZZ 4X16X5 |
| 109 | 5181729 | REAR blade guide (5181868) |
| 110 | 0600607 | BALL BEARING 607 2RS 7x19x 6 |
| 111 | 5100075 | BEARING REGISTRATION BOLT |
| 112 | 7132503 | COMPLETE REAR BLADE GUIDE |
| 113 | 5120638 | SPACER FOR BEARING D.6X12 H.1,5 |
| 114 | 5100074 | BEARING SCREW LOCKING |
| 115 | 5181654 | BLADE PROTECTION BLACK |
| 116 | 5100064 | BEARING SCREW LOCKING |
| 117 | 5100065 | BEARING REGISTRATION BOLT |
| 118 | 5130771 | SLIDING GUIDE |
| 120 | 7213004 | GEAR ASSY |
| 121 | 0424060 | TAPPING SCREW PANELVIT TPS T / ZN CR.4X60 |
| 122 | 5182519 | MOTORT COVER CAP |
| 124 | 7820153 | ex 7820105 REGATORE DIGITAL ELECTRONIC 1750 8K-22K C / TACH.TRIAC16A |
| 125 | 5850111 | FAN COMPLETE WITH MAGNETIC CORE |
| 126 | 5870853 | CABLE H05 3X0.75X1800 C / PUNT.SP / EUR.2 / TER |
| 127 | 7801646 | MOTOR 93 H50 230 Hz50 C / K FEMI 100899 (ROV) |
| 129 | 5154501 | GLAND |
| 132 | 5850006 | 901 518 BRUSH MOTOR H50 |
| 133 | 0802316 | SWITCH BIPOLAR 250V.-16 LIGHT (8). C / SCREWS |
| 135 | 5182504 | COVER PORTAINTERRUTTORE |
| 136 | 0168507 | CAP PLASTIC CLEAR. MATT D. 9 MM. |
| 137 | 0801101 | MICROSWITCH V16-1A6 (R) |
| 138 | 5081008 | SPRING RETURN pushbutton |
| 139 | 0168513 | CAP PLASTIC KAPSTO TYPE 950/0054 |
| 141 | 5130833 | ROD DRIVE MICROSWITCH. 1750 |
| 142 | 5130806 | GUIDE ROD MICRO |
| 145 | 0816004 | FILTER EMC 6.5A FAST.2.8X0.5 |
| 146 | 5182823 | SWITCH BOX |
| 148 | 5182505 | COVER GEAR BOX BLACK |
| 149 | 7013145 | ARMATURE |
| 150 | 5024118 | STATOR - FIELD |
| 151 | 5182839 | CAP MOTOR PROTECTION |
| 152 | 0586200 | BEARING 6200 10x30x 9 OPEN |
| 157 | 7213005 | GEAR ASSY |
| 158 | 0731212 | NEEDLE BEARING HK 1212 |
| 159 | 0124026 | WASHER 12X18 PS THICK THICK 1 |
| 162 | 5850110 | CARBON BRUSHE SET |
