FEMI VB28-194 Vertical Band Saw Spare Parts
€6.36
Tax included
FEMI VB28-194 Vertical Band Saw Spare Parts
We have the original Spares FEMI Spare Parts for FEMI VB28-194 Vertical Band Saw H 224 mm - 8505020 the diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your FEMI VB28-194 Vertical Band Saw H 224 mm - 8505020. All Spares are original and can be supplied at Low and discounted prices.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
FEMI VB28-194 Vertical Band Saw Spare Parts
Fix Your FEMI VB28-194 Vertical Band Saw H 224 mm - 8505020. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.In the following table, look for the model of Drill Pressand the respective parts of the code.
| FEMI VB 28-194 Vertical Band Saw H 224 mm - 8505020 Spare Parts | ||
| # | Part N um. | Description |
| 3 | 8505020-3 | TENSIONING KNOB |
| 4 | 8505020-4 | TENSIONING SCREW |
| 5 | 8505020-5 | BUSHING |
| 7 | 8505020-7 | COVER CAP |
| 10 | 8505020-10 | TENSIONING SCREW SUPPORT |
| 11 | 8505020-11 | TENSIONING SPRING |
| 12 | 8505020-12 | NUT |
| 13 | 8505020-13 | CONNECTION LEVER |
| 17 | 8505020-17 | INDEX PIVOT |
| 20 | 8505020-20 | TENSIONING INDEX |
| 23 | 8505020-23 | SHAFT |
| 24 | 8505020-24 | SLIDING GUIDE |
| 25 | 8505020-25 | TENSIONING GUIDE |
| 29 | 8505020-29 | TENSIONING PLATE |
| 30 | 8505020-30 | FREE PULLEY SHAFT |
| 30 | 8505020-31 | BEARING |
| 33 | 8505020-33 | FREE PULLEY |
| 35 | 8505020-35 | PROTECTION RING |
| 37 | 8505020-37 | UPPER COVER |
| 38 | 8505020-38 | TENSIONING SCREEN |
| 39 | 8505020-39 | SCREEN SEAL |
| 41 | 8505020-41 | MICROSWITCH PLATE |
| 43 | 8505020-43 | LOWER COVER |
| 54 | 8505020-54 | MICROSWITCH BOX COVER |
| 62 | 8505020-62 | SWITCH BOX |
| 65 | 8505020-65 | START/STOP SWITCH |
| 70 | 8505020-70 | SPACER |
| 72 | 8505020-72 | CLEANING BRUSHES |
| 75 | 8505020-75 | PULLEY SHAFT |
| 76 | 8505020-76 | DRIVING PULLEY |
| 77 | 8505020-77 | DRAWER HANDLE |
| 78 | 8505020-78 | CHIPS DRAWER |
| 79 | 8505020-79 | SPRING |
| 88 | 8505020-88 | CAM |
| 89 | 8505020-89 | BUSHING |
| 91 | 8505020-91 | SHAFT |
| 92 | 8505020-92 | LEVER |
| 93 | 8505020-93 | LEVER HANDLE |
| 94 | 8505020-94 | LEVER KNOB |
| 95 | 8505020-95 | KNOB |
| 96 | 8505020-96 | KNOB CAP |
| 100 | 8505020-100 | SHAFT |
| 101 | 8505020-101 | GEAR |
| 102 | 8505020-102 | LOWER KNOB |
| 103 | 8505020-103 | SPRING |
| 104 | 8505020-104 | UPPER KNOB |
| 125 | 8505020-125 | COVER KNOB |
| 126 | 8505020-126 | GUIDE PLATE |
| 132 | 8505020-132 | SHAFT |
| 135 | 8505020-135 | LOWER BLADE PROTECTION |
| 138 | 8505020-138 | SHAFT |
| 150 | 8505020-150 | CONVEYOR COVER |
| 151 | 8505020-151 | DUST CONVEYOR |
| 154 | 8505020-154 | BUSHING |
| 155 | 8505020-155 | PULLEY SHAFT |
| 156 | 8505020-156 | PULLEY |
| 157 | 8505020-157 | BEARING |
| 159 | 8505020-159 | BELT |
| 160 | 8505020-160 | DRIVING PULLEY |
| 163 | 8505020-163 | COMPLETE MOTOR |
| 166 | 8505020-166 | BELT KNOB |
| 168 | 8505020-168 | GEAR |
| 169 | 8505020-169 | KNOB |
| 170 | 8505020-170 | GUIDE LOCKING KNOB |
| 171 | 8505020-171 | WORKTABLE |
| 172 | 8505020-172 | TABLE INSERT |
| 174 | 8505020-174 | TABLE SUPPORT |
| 175 | 8505020-175 | SUPPORT |
| 181 | 8505020-181 | INDEX |
| 187 | 8505020-187 | LIMITER |
| 189 | 8505020-189 | HAND LEVER |
| 203 | 8505020-203 | CABLE |
| 223 | 8505020-223 | COVER CAP |
| 224 | 8505020-224 | TABLE GUIDE |
| 225 | 8505020-225 | COVER CAP |
| 235 | 8505020-235 | WOOD PUSHER SUPPORT |
| 237 | 8505020-237 | KEY SUPPORT |
| 500 | 8505020-500 | COMPLETE GONIOMETER |
| 501 | 8505020-501 | COMPLETE FENCE |
| 502 | 8505020-502 | LOWER BLADE GUIDE GROUP |
| 503 | 8505020-503 | UPPER BLADE GUIDE GROUP |
| 504 | 8505020-504 | COMPLETE COVER |
| 505 | 8505020-505 | BASE GROUP |
