FIAC Spare Parts for Pump Unit S15
€1.48
Tax included
FIAC Spare Parts for Pump Unit S15
We are FIAC authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair problem for Pump Unit S15.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
FIAC Spare Parts for Pump Unit S15
We are FIAC authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair problem for Pump Unit S15.
In the following table, look for the type of the air compressor and the respective parts of the code.
| Pump Unit S 15 | ||
| # | Part Num. | Description |
| 1 | 7011220000 | Screw M6x40 UNI-5737 |
| 2 | 7210010000 | Filter Element |
| 3 | 5030150008 | Head |
| 5 | 7459530000 | Kit Valve Plate |
| 8 | 7575360000 | Cylinder |
| 10 | 4080240000 | Piston Ring Kit |
| 11 | 7220050000 | Piston |
| 12 | 7050030000 | Pin Ø 13 |
| 13 | 7041030000 | Seeger Ø13 |
| 14 | 7098120000 | Stopper |
| 15 | 7070010000 | O-Ring 108 |
| 16 | 7090090000 | Stopper M1 / 4 "Brass |
| 17 | 7072010000 | Seal |
| 18 | 7060060000 | Bearing 6205 |
| 19 | 5041280008 | Crank Shaft |
| 20 | 7040040000 | And Seeger 20 |
| 21 | 5040720008 | Fan Shaft |
| 22 | 7030030000 | Washer Ø8 UNI-6592 |
| 23 | 7010420000 | Screw M8x20 UNI-5931 |
| 24 | 5080060008 | Cover |
| 25 | 7200150000 | Cooling Fan |
| 26 | 7248060000 | Grid |
| 27 | 7012060000 | Screw M4X12 UNI-8112 |
| 28 | 7071260000 | Oil Seal SM 1728/7 |
| 29 | 7012290000 | Screw M5X20 TAP-TITE |
| 30 | 7070250000 | O-Ring 4500 |
| 31 | 7071090000 | Oil Seal 2552/10 |
| 32 | 5070260008 | Carter |
| 33 | 7011970000 | Screw 5/16 "25 UNF |
| 34 | 7040510000 | Ring |
| 35 | 7051280000 | Woodruff Key 4,76X4,76X22 X GC135 S-13 |
| 36 | 7016100000 | Screw M8x10 UNI-5923 |
| 37 | 7015020000 | Prisoner M.8X35X14X16 |
| 38 | 5050160008 | Piston ConRod |
| 39 | 7020070000 | Nut M8 UNI-5587 |
| 40 | 4081050000 | Kit Valves |
| 41 | 7084190000 | Fitting "L" 3 / 8-1 / 2 MM |
| 42 | 7382680000 | Engine |
| 43 | 7016190000 | Screw M5X8 UNI-5923 |
| 44 | 7488011000 | Plate |
| 45 | 7040200000 | Centering Ring |
| 46 | 7012080000 | Screw Ø4,2X12,7 UNI-6954 |
| 47 | 7030020000 | Ø6 Washer UNI-6592 |
| 48 | 7210800000 | Suction Filter |
| 49 | 7090080000 | Stopper M3 / 8 " |
| 50 | 7458031000 | Filter Plate |
| 100 | 4082970000 | Valve Plate Kit |
| 101 | 4191040000 | KIT ROD-PISTON-PISTON TINGS 55 / VX 304 |
| 102 | 4280800000 | GR.CARTER + TREE S-14 "HONDA" |
| 103 | 4082340000 | Gasket Set |
