Femi Spare Parts for Mitre Saw for Wood TR 245-8426126
Femi genuine spare parts or replacement parts for to fix Mitre Saw for Wood TR 245-8426126.
Made for the wide market of craftsmen and lovers of do it yourself, the TR 245 is light, handy, stable, this miter saw is ideal for cutting various types of wood with precision.
In the following table, look for the model of the Wood Mitre Saw and the respective parts of the code.
| Wood Mitre Saw TR 245-8426126 | ||
| # | Part Num. | Description |
| 1 | 5181782 | UPPER BLADE GUARD ASS'Y |
| 2 | 5130462 | UPPER WORKING TABLE |
| 3 | 7130629 | UPPER FENCE GROUP |
| 4 | 5871084 | CABLE |
| 5 | 5182912 | CONSENSATOR SUPPORT |
| 6 | 5182911 | FAN COVER |
| 8 | 0840035 | CAPACITOR |
| 12 | 5081000 | BRAKE SPRING |
| 13 | 5042824 | MOTOR BODY |
| 14 | 5152075 | BRAKE PIN |
| 15 | 5182914 | MOTOR BODY COVER |
| 16 | 0536201 | BALL BEARING |
| 17 | 5024303 | STATOR |
| 18 | 5050140 | HANDLE |
| 19 | 0802622 | SWITCH |
| 20 | 7820126 | ELECTRONIC CARD = 7075046 - 7820124 |
| 21 | 5050139 | HANDLE |
| 24 | 5153504 | CABLE LOCKING DEVICE |
| 25 | 5221021 | RUBBER GASKET |
| 27 | 5181003 | RUBBER PROTECTION |
| 29 | 5182562 | BOX COVER |
| 30 | 5181784 | PROTECTION GROUP |
| 31 | 5100336 | BOLT M8 L. |
| 32 | 5190310 | BLADE FLANGE |
| 33 | 0151040 | SNAP RING |
| 34 | 7013636 | ROTOR |
| 35 | 5182883 | ELECTRIC BOX |
| 39 | 5120672 | SPACER |
| 40 | 0107012 | WING NUT |
| 41 | 5130883 | TABLE GUIDE |
| 42 | 5181781 | LOWER PROTECTION |
| 45 | 5120673 | SPACER |
| 46 | 0221106 | O-RING SEAL |
| 47 | 5171072 | LOCKING PIN |
| 49 | 0536203 | BALL BEARING |
| 50 | 0106116 | RING NUT |
| 51 | 5124085 | WASHER |
| 52 | 5170003 | LOCKING PIN |
| 53 | 5080163 | SPRING |
| 54 | 5042823 | MITRE SAW ARM |
| 55 | 5190311 | BLADE FLANGE |
| 60 | 5080160 | SPRING |
| 63 | 5183084 | RIVING KNIFE |
| 64 | 5130882 | TABLE GUIDE |
| 65 | 7130621 | LEVER AND PROTECTION GROUP |
| 67 | 5182882 | ARM COVER |
| 69 | 5080162 | SPRING |
| 70 | 0107013 | WING NUT |
| 71 | 5100337 | SCREW |
| 72 | 7130648 | LEVER GROUP |
| 75 | 5124084 | WASHER |
| 76 | 7130630 | JOINT-SHAFT GROUP |
| 77 | 5181780 | LOWER PROTECTION |
| 78 | 5159013 | SCREW CAP |
| 79 | 5080161 | SPRING |
| 80 | 5130918 | SUPPORT BASE |
| 82 | 5100339 | SCREW |
| 87 | 5181783 | BLADE PROTECTION |
| 88 | 5081033 | SPRING |
| 89 | 5138011 | SPRING SUPPORT |
| 90 | 0147019 | HAND LEVER |
| 91 | 5120674 | SPACER |
| 92 | 5100338 | SCREW |
| 93 | 7130626 | ROD STOP GROUP |
| 94 | 0142002 | WOOD PUSHING DEVICE |
| 96 | 5171074 | SUPPORT PIN |
| 98 | 5137979 | SWIVEL SUPPORT |
| 99 | 5130881 | JOINT SUPPORT |
| 102 | 5140056 | KNOB |
| 104 | 5137980 | RUBBER FOOT |
| 105 | 5133720 | BASE |
| 106 | 5159519 | INDEX |
| 108 | 5170537 | LOCKING PIN |
| 109 | 5402228 | GRADUATE PLATE |
| 112 | 0151512 | ELASTIC RING |
| 113 | 5112031 | MOTOR FAN |
| 114 | 5182913 | CAPACITOR COVER |
| 122 | 5871083 | CABLE |
