DEWALT D28011 Type 3 Angle Grinder Spare Parts

DEWALT, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for D28011 Type 3 Angle Grinder Spare Parts.

In the following table, look for the model of the hammer and the respective parts of the code.
D28011 Type 3 Angle Grinder Spare Parts

DeWalt D28011 Type 3 Small Angle Grinder Spare Parts
# Part Num. Description
1 623584-16 ARMATURE 230V
2 650994-00 FIELDCASE
3 N074217 GEARCASE SA
4 330065-31 PLASTIC SCREW
5 648743-00 ARM
6 623592-00 FELT SEAL
7 1003860-00 BRUSH PAIR 230V
9 623589-00 Carbon Brush Spring For D281 Series
10 623591-00 BRUSH CAP
11 593685-00 SCREW
12 625243-05 GRIP ASSY
13 641889-01 SWITCH SA
16 636963-00 CORD CLAMP
17 330019-03 SCREW
18 N542553 CORD PROTECTOR
18 N918736 CORD PROTECTOR
19 622613-02 CLAMP WASHER
20 633257-00SV RECIEVE WASHER
21 N041731 GUARD SA
24 562226-59 CORDSET (EURO)
26 623593-00 TERMINAL
27 628396-00 SPRING
29 N088390 LABEL
30 635892-00 BRAND LABEL
35 637543-00 CHOKE SA
36 N033051 SCREW
70 604484-00 NUT
71 623564-00 PINION
72 605040-11 BEARING,BALL
73 623617-00 FELT SEAL
74 N422242 RETAINER
75 623613-00 WASHER
76 605040-02 BEARING
77 641823-00 SLEEVE
78 624764-04 FIELD 230V 220-240V
79 650997-00 BAFFLE FAN
80 330065-25 SCREW
81 623618-00 GASKET
82 611492-00 SLEEVE
83 625414-00 GEARCASE COVER
84 385676-01 SCREW
85 631609-03 SCREW
87 401680-00 Pin Spanner Wrench
88 N401305 Side Handle
89 626999-00 LINK D28111 D28139 D28110 D28011 DWEN201
90 644326-00 BAR LOCKING
91 623608-00 BUTTON START
92 633045-00 O RING
93 633043-00 O RING
800 583534-00 GREASE 50 GMS - NYE RHEOLUB 380G1
836 233804-36 DRIVER
861 638758-00 KIT BOX
