DEWALT D28492 Type 2 Parts
€1.65
Tax included
DEWALT D28492 Type 2 Angle Grinder Spare Parts
DEWALT, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for D28492 Angle Grinder Spare Parts.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
DEWALT D28492 Type 2 Angle Grinder Spare Parts
DEWALT, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for D28492 Angle Grinder Spare Parts.In the following table, look for the model of the hammer and the respective parts of the code.
| DeWalt D28492 Angle Grinder - Type 2 spares and parts | ||
| # | Part Num. | Description |
| 1 | 330045-14 | SCREW M5X16 T25 |
| 2 | 330019-26 | SCREW M5.28 X42 |
| 3 | 330019-19 | SCREW, PLASTITE |
| 4 | 330019-11 | SCREW M4.55x13 T20 |
| 5 | 330019-50 | SCREW PLSTC THD FORM M4.55X13 T20 |
| 6 | 330019-32 | SCREW,PLASTITE |
| 10 | N513676 | FIELD 230V |
| 10 | 617004-04 | FIELD 115V |
| 11 | N467980 | ARMATURE SA 230V |
| 11 | 638001-01 | ARMATURE SA 112V |
| 12 | 393239-01 | FIELD CASE |
| 13 | 397031-00 | TOROIDAL RING |
| 14 | N074214 | GEARCASE SA |
| 15 | N074213 | GEARCASE COVER SA |
| 16 | 629729-00 | PINION 6K |
| 17 | 330015-03 | NUT M8x1.25 |
| 18 | 639681-00 | WASHER |
| 19 | 632702-00 | COLLAR |
| 20 | 609987-00 | BRUSH SPRING |
| 20 | 645650-00 | BRUSH SPRING |
| 21 | 394387-01 | DOOR, BRUSH |
| 22 | 617001-00 | BRUSH HOLDER SA 230V |
| 22 | 629976-00 | BRUSH HOLDER SA 115V |
| 23 | 392574-03 | BRUSH SET CUT OFF 230 V |
| 23 | N025285 | BRUSH 120V |
| 24 | 636499-00 | HANDLE AND COVER |
| 25 | N035342 | SWITCH SA |
| 26 | 604118-00 | CORD PROTECTOR |
| 26 | 330005-11 | CORD PROTECTOR |
| 27 | 604119-00 | CORD CLAMP |
| 28 | 632218-00 | CAPACITOR |
| 29 | 562226-65 | CORDSET (EURO) |
| 29 | 562226-67 | CORDSET |
| 30 | 631350-00 | RADIAL FAN BAFFLE |
| 31 | 393238-00 | SHIELD DUST |
| 32 | N389509 | BEARING, BALL, CW MFG |
| 33 | N110359 | BEARING 608 |
| 36 | N033051 | SCREW STOP |
| 37 | 636503-00 | BUTTON LOCK-OFF |
| 38 | 636502-00 | SPRING |
| 39 | 641929-00 | COVER |
| 40 | N041513 | RATING PLATE 230V |
| 40 | N041519 | RATING PLATE 115V |
| 41 | 403150-01 | WASHER, CLAMP, INNER |
| 42 | 401678-05 | WASHER OUTER CLAMP PAINTED |
| 43 | 609970-00 | CUP, RUBBER |
| 44 | 630553-00 | SPINDLE LOCK BUTTON |
| 45 | 638328-00 | SPINDLE LOCK SPRING |
| 46 | 635908-00 | SPINDLE LOCK RETAINING PLATE |
| 47 | 634589-00 | SPINDLE LOCK PIN |
| 48 | 750831 | O RING (SPINDLE LOCK) |
| 52 | 640591-00 | WASHER PLAIN |
| 53 | 330045-67 | SCREW |
| 60 | 635261-00 | WRENCH PIN |
| 61 | N036839 | GUARD SA |
| 62 | N082712 | SCREW M8 X 35 |
| 63 | 651858-01 | SIDE HANDLE |
| 70 | 612273-00 | TERMINAL |
| 71 | 610057-00 | TERMINAL |
| 73 | 053650-00 | TERMINAL |
| 99 | N038672 | GUARD ASSEMBLY Type A Cutting Guard 230mm |
| 800 | 583534-00 | GREASE 50 GRAMS - NYE RHEOLUB 380G1 |
| 861 | 644490-00 | KITBOX |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
