Bosch Spare Parts for Angle Grinder GWS 660
Bosch genuine spare parts or replacement parts for to repair Angle Grinder GWS 660 - 0601375065.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Angle Grinder GWS 660
Bosch genuine spare parts or replacement parts for to repair Angle Grinder GWS 660 - 0601375065.In the following table, look for the model of the Angle Grinder and the respective parts of the code.
| Angle Grinder GWS 660/0 601 375 065 | ||
| Pos. | Codice | Descrizione |
| 1 | 1619P09772 | Motor Housing |
| 2 | 1604220328 | Field 220-240V |
| 3 | 1604010626 | Armature 220-240V |
| 3/50 | 1606610141 | Fan |
| 4 | 1607200179 | Switch |
| 6 | 2600703012 | Grommet Ø6,5-Ø6,9x95 MM |
| 7 | 1601302017 | Fastening Clamp |
| 9 | 2609130601 | Manufacturer's nameplate GWS 660 |
| 12 | 1619P07647 | Suppression Filter |
| 13 | 2600905032 | groove ball bearing 7x19x6 |
| 14 | 1619P11240 | groove ball bearing |
| 16 | 1604336035 | Brush Holder |
| 17 | 1604652013 | Spiral Spring |
| 18 | 1604611031 | Compression Spring |
| 22 | 1602319009 | Adjusting Slide |
| 23 | 1602026068 | Switch Handle BLACK |
| 25 | 1605500194 | Housing Cover BLUE |
| 26 | 1600502024 | Intermediate Ring |
| 27 | 1600206025 | Rubber Ring |
| 29 | 1600591023 | Air-Deflector Ring |
| 30 | 1600591024 | Air-Deflector Ring |
| 33 | 1600210041 | O-Ring 42,0x1,1 MM |
| 35 | 1600136016 | Shim 0,1 MM THICK |
| 35 | 1600136017 | Shim 0,2 MM THICK |
| 37 | 1600100033 | Cover Disc |
| 38 | 2609110150 | Crown Gear |
| 39 | 2609110149 | Bevel Gear |
| 45 | 2915011007 | Hex Nut DIN 934-M6-8-A |
| 47 | 2609110052 | Special Screw |
| 48 | 1619P00220 | Torx Oval-Head Screw 3x10 |
| 49 | 1603435068 | Thread-forming tap. Screw DIN 7500, M4x10, SR10.2 |
| 50 | 2910611020 | Tapping Screw DIN 7981-ST3,9x19-C-H |
| 55 | 2910611022 | Tapping Screw DIN 7981-ST3,9x25-C-H |
| 80 | 3600150021 | Sealing disk |
| 650/10 | 1602025031 | Auxiliary Handle M10, Ø37x115 MM ANTI-VIBRATION |
| 650/10 | 2602025067 | Auxiliary Handle M10, Ø32,5x105 MM |
| 650/20 | 1603345043 | Round Nut M14 |
| 650/30 | 1619P08927 | Pin-Type Face-Wrench |
| 650/50 | 2605703014 | Clamping-Flange Ø22,3xØ42 MM |
| 650/50/20 | 1600210039 | O-Ring 20,35x1,78 MM |
| 651 | 1605510252 | Protective Cover Ø 115 MM |
| 805 | 1607000385 | Power supply cord EU 2,6m 2 x 1,0 mm |
| 808 | 1619P00637 | Nameplate |
| 810 | 1607014145 | Carbon-Brush Set |
| 821 | 1619P01814 | Gear Housing GREEN |
| 828 | 1605805090 | Bearing Flange BLACK |
| 832 | 1603523110 | Grinding Spindle M14, SW17 |
| 840 | 1607000298 | Push-Button BLACK |
| 841 | 1600910018 | Needle bearing Ø8xØ12x8 MM |
