DeWalt Spare Parts for Pressure Washer DXPW001CE
€9.04
Tax included
DeWalt Spare Parts for Pressure Washer DXPW001CE
DeWalt genuine spare parts for to repair Pressure Washer DXPW001CE - 26771.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
DeWalt Spare Parts for Pressure Washer DXPW011E
DeWalt genuine spare parts for to repair Pressure Washer DXPW001CE - 26771.
In the following table, look for the model of the Pressure Washer and the respective parts of the code.
| DeWalt Pressure Washer DXPW001CE - 26771 | ||
| Casing Pag.1 |
||
| # | Part Num. | Description |
| 1 | 3961200 | Handle |
| 2 | 2100300 | Screw |
| 3 | 880280 | Screw |
| 4 | 3961210 | Guard |
| 5 | 3800250 | Screw |
| 6 | 3961260 | Knob |
| 7 | 3961290 | Guard |
| 8 | 3961160 | Casing |
| 9 | 3960830 | Guard |
| 10 | 3961230 | Guard |
| 11 | 4240590 | Screw |
| 12 | 1260780 | Screw |
| 13 | 3961220 | Guard |
| 14 | 3961240 | Support |
| 15 | 3961180 | Support |
| 16 | 3961250 | Clamp |
| 17 | 3961170 | Base |
| 18 | 4240540 | Rubber foot |
| 19 | 3960260 | Knob |
| 20 | 3961190 | Guard |
| 21 | 41851 | Pressure gauge |
| 22 | 1270960 | Detergent hose |
| 23 | 1341030 | Filter |
| 24 | 3082130 | Water coupling kit |
| Pump Pag.2 |
||
| 1 | 26854 | Pump assembly |
| 2 | 46065 | Head assembly |
| 3 | 4140650 | Head |
| 4 | 4140570 | Fitting |
| 5 | 2849051 | Complete valve |
| 6 | 2841520 | O-ring |
| 7 | 2840130 | Plug |
| 8 | 2101770 | O-ring |
| 9 | 2761511 | Shutter |
| 10 | 2760200 | Spring |
| 11 | 2761550 | Injector |
| 12 | 1470210 | O-ring |
| 13 | 2760270 | O-ring |
| 14 | 394280 | O-ring |
| 15 | 2761150 | Fitting |
| 16 | 1345180 | Screw |
| 17 | 4140140 | Washer |
| 18 | 3700250 | O-ring |
| 19 | 1560520 | Spring |
| 20 | 1250280 | Ball |
| 21 | 480480 | O-ring |
| 22 | 1344620 | Fitting |
| 23 | 480560 | O-ring |
| 24 | 2320180 | Hose tail |
| 25 | 3700250 | O-ring |
| 26 | 2841800 | Plug |
| 27 | 2760260 | Plug |
| 28 | 46935 | Valve kit adjustment |
| 29 | 1470210 | O-ring |
| 30 | 2841080 | Seat |
| 31 | 3800230 | Piston |
| 32 | 820510 | O-ring |
| 33 | 740290 | O-ring |
| 34 | 3800970 | Piston guide |
| 35 | 2500550 | Split pin |
| 36 | 2760210 | Ring |
| 37 | 660190 | O-ring |
| 38 | 2260100 | O-ring |
| 39 | 4140170 | Piston |
| 40 | 1980220 | Plate |
| 41 | 4140620 | Spring |
| 42 | 3800960 | Screw |
| 43 | 3961360 | Screw |
| 44 | 3800200 | Nut |
| 45 | 1120681 | O-ring |
| 46 | 4140420 | Pin |
| 47 | 2260460 | Spring |
| 48 | 2021650 | Washer |
| 49 | 1260820 | O-ring |
| 50 | 3740050 | Ring |
| 51 | 600180 | O-ring |
| 52 | 4140640 | Plug |
| 53 | 3720750 | O-ring |
| 54 | 3721210 | Seat |
| 55 | 1682800 | O-ring |
| 56 | 3720730 | Plug |
| 57 | 2841910 | Water seal |
| 58 | 2840550 | Bushing |
| 59 | 770590 | O-ring |
| 60 | 2841390 | Bushing |
| 61 | 1683500 | Oil seal |
| 62 | 4140010 | Pump body |
| 63 | 3700250 | O-ring |
| 64 | 2841800 | Plug |
| 65 | 4140210 | Plug |
| 66 | 4140230 | Piston |
| 67 | 4140070 | Pin |
| 68 | 4140080 | Connecting-rod |
| 69 | 4140090 | O-ring |
| 70 | 4140030 | Cover |
| 71 | 4140270 | Screw |
| 72 | 4140110 | Bearing |
| 73 | 4140360 | Ring |
| 74 | 4140150 | Cover |
| 75 | 4140310 | Shaft |
| 76 | 1380520 | Key |
| 77 | 4140190 | Ring |
| 78 | 4140100 | Bearing |
| 79 | 4140360 | Ring |
| 80 | 4140200 | Oil seal |
| 81 | 46936 | TSS Retrofit kit |
| 82 | 2900350 | Plug |
| 83 | 3201960 | Flange |
| 84 | 880280 | Screw |
| A | 43478 | Valve kit |
| B | 47263 | Piston kit |
| C | 43480 | Oil seal kit |
| E | 43481 | Water seal kit |
| F | 43482 | Gasket kit |
| Motor Pag.3 |
||
| 1 | 45143 | Motor |
| 2 | 1260300 | Fan |
| 3 | 1340350 | Seal |
| 4 | 1345180 | Screw |
| 5 | 1345140 | Shield |
| 6 | 1340340 | Bearing |
| 7 | 1269100 | Clamp |
| 8 | 1340780 | Gasket |
| 9 | 2000210 | Screw |
| 10 | 2901920 | Switch |
| 11 | 3780170 | Box |
| 12 | 1261560 | Screw |
| 13 | 2021480 | Gland |
| 14 | 1263520 | Capacitor |
| 15 | 1982550 | Clamp |
| 16 | 1462900 | Gland |
| 17 | 2029803 | TSS box assembly |
| 18 | 2022201 | Fork |
| 19 | 3780630 | Cable |
| Standard Accessories Pag.4 |
||
| 1 | 41842 | Gun |
| 2 | 391000 | O-ring |
| 3 | 43954 | Lance |
| 4 | 2000570 | O-ring |
| 5 | 3960920 | High pressure hose |
