DeWalt Spare Parts for Pressure Washer DXPW011E
DeWalt genuine spare parts for to repair Pressure Washer DXPW011E - 26303.
In the following table, look for the model of the Pressure Washer and the respective parts of the code.
| Casing DXPW011E - 26303 Pag.1 |
||
| # | Part Num. | Description |
| 1 | 2060200 | SCREW |
| 2 | 2100300 | SCREW |
| 3 | 2360760 | KNOB |
| 4 | 3960500 | SUPPORT |
| 5 | 3960330 | GUARD |
| 6 | 200230 | SCREW |
| 7 | 320620 | WASHER |
| 8 | 2240110 | NUT |
| 9 | 2180150 | DETERGENT HOSE |
| 10 | 1270960 | DETERGENT HOSE |
| 11 | 1341030 | FILTER |
| 12 | 1269114 | PRE ASSEMBLY HOSE SA |
| 13 | 3120110 | NUT |
| 14 | 1340260 | FILTER |
| 15 | 3960300 | GUARD |
| 16 | 3960280 | HANDLE |
| 17 | 3960150 | GUARD |
| 18 | 3960160 | GUARD |
| 19 | 3960490 | CARRIER |
| 20 | 3960290 | GUARD |
| 21 | 3969004 | KNOB |
| 22 | 3960830 | GUARD |
| 23 | 4554 | MOTOR SA |
| 24 | 50016 | CAP |
| 25 | 3960530 | WHEEL |
| 26 | 3960510 | FRAME |
| 27 | 1060120 | NUT |
| 28 | 3960350 | GUARD |
| 29 | 3960340 | GUARD |
| 30 | 3960360 | DAMPER |
| 31 | 380250 | SCREW |
| 32 | 3960540 | SPACER |
| 33 | 380210 | SCREW |
| 34 | 3960520 | FRAME |
| 35 | 961900 | SCREW |
| Pump DXPW011E - 26303 Pag.2 |
||
| 1 | 960160 | O RING |
| 2 | 960850 | PLUG |
| 3 | 889052 | VALVE |
| 4 | 1382740 | SEAL |
| 5 | 1380690 | PLUG |
| 6 | 820510 | O RING |
| 11 | 960110 | RING |
| 12 | 1382740 | SEAL |
| 13 | 1380090 | GUIDE |
| 14 | 961240 | O RING |
| 15 | 880330 | SEAL |
| 16 | 1383130 | RING |
| 17 | 850370 | SCREW |
| 18 | 1380050 | SUPPORT |
| 19 | 640030 | O RING |
| 20 | 2280340 | BEARING |
| 21 | 1382770 | BODY PUMP SA |
| 22 | 880130 | PLUG |
| 23 | 962010 | NUT |
| 24 | 962000 | WASHER |
| 25 | 1380940 | PISTON |
| 26 | 1380950 | PLATE |
| 27 | 600180 | O RING |
| 28 | 1380920 | PISTON |
| 29 | 1380060 | PIN |
| 30 | 1383020 | CON ROD |
| 31 | 1080401 | RING |
| 32 | 1381850 | WASHER |
| 34 | 1780510 | O RING |
| 35 | 1789010 | COVER |
| 36 | 1343510 | SCREW |
| 37 | 2280130 | SHAFT |
| 38 | 820440 | SCREW |
| 39 | 621170 | RING |
| 40 | 1380120 | SHIM 0.19 mm |
| 40 | 1380130 | SHIM 0.05 mm |
| 40 | 1380530 | SHIM 0.25 mm |
| 40 | 1382810 | SHIM 0.10 mm |
| 41 | 2281510 | FLANGE |
| 42 | 740290 | O RING |
| 43 | 1980740 | PLUG |
| 46 | 1981180 | PLUG |
| 47 | 180101 | O RING |
| 49 | 2281590 | HEAD SA |
| 50 | 820150 | SCREW |
| 71 | 180030 | SCREW |
| 77 | 1383150 | BEARING |
| 78 | 2289235 | HEAD SA |
| 86 | 1260250 | LEVEL |
| 87 | 1260430 | RING |
| 88 | 1780690 | PLATE |
| 89 | 1140450 | O RING |
| 91 | 1381580 | PRESSURE GAUGE |
| 92 | 1380220 | O RING |
| 94 | 50129 | VALVE |
| 95 | 20699 | PUMP SA |
| A | 1828 | VALVE KIT |
| B | 2757 | PISTON KIT |
| C | 1856 | SEALS KIT |
| E | 1857 | WATER SEALS KIT |
| G | 1829 | RING SA |
| Pump DXPW011E - 26303 Pag.3 |
||
| 1 | 25184 | VALVE CPL |
| 2 | 2840970 | SCREW |
| 3 | 1060120 | NUT |
| 4 | 3740100 | PLUG |
| 5 | 2500540 | INSERT |
| 6 | 2500550 | PIN |
| 7 | 1980220 | PLATE |
| 8 | 2760410 | SPRING |
| 9 | 2760400 | PISTON |
| 10 | 2260100 | O RING |
| 11 | 660190 | O RING |
| 12 | 2760210 | RING |
| 13 | 2760570 | GUIDE |
| 14 | 1200690 | O RING |
| 15 | 394280 | O RING |
| 16 | 2260070 | SHUTTER |
| 17 | 2760980 | SEAT |
| 18 | 770140 | O RING |
| 19 | 2760640 | RING |
| 20 | 390080 | O RING |
| 21 | 1540272 | SCREW |
| 22 | 1982520 | COUPLING |
| 23 | 480480 | O RING |
| 24 | 1250280 | BALL |
| 25 | 1560520 | SPRING |
| 26 | 2260190 | O RING |
| 27 | 3740010 | VALVE BODY |
| 28 | 600180 | O RING |
| 29 | 1540630 | O RING |
| 30 | 3740020 | BODY |
| 31 | 880270 | O RING |
| 32 | 2260420 | SCREW |
| 33 | 2101770 | O RING |
| 34 | 2760131 | SHUTTER |
| 35 | 2760200 | SPRING |
| 36 | 2760120 | INSERT |
| 37 | 1470210 | O RING |
| 38 | 2760270 | O RING |
| 39 | 2760230 | COUPLING |
| 40 | 480440 | O RING |
| 41 | 3600760 | COUPLING |
| 42 | 1122260 | COUPLING |
| F | 42780 | GASKET SET |
| Accessories DXPW011E - 26303 Pag.4 |
||
| 1 | 41843 | HANDLE SA |
| 2 | 40826 | EXTENSION |
| 3 | 2000570 | O RING |
| 4 | 3961050 | HOSE |
| 5 | 391000 | O RING |
| 6 | 3082 | NOZZLE |
