Castor Spare Parts for Chain Saw CJ 300

€4.02
Tax included

Castor Spare Parts for Chain Saw CJ 300

CASTOR authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Chain Saw CJ 300.

Castor CJ 300
ITEM CODE: 6995022
Quantity
Usually Ships in: 10/15 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Castor Spare Parts for Chain Saw CJ 300

CASTOR

 authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Chain Saw CJ 300.

In the following table, look for the model of the Chain Saw and the respective parts of the code.
Castor CJ 300

Chain Saw CJ 300 - Engine Pag.1
# Part Num. Description
1 123120008/0 NUT
2 183880005/0 FLYWHEEL ASSY
7 119035162/0 SEAL RING
8 114215219/0 BALL BEARING
9 123072005/0 FLYWHEED KEY
10 123020030/0 CRANKSHAFT
11 123652505/0 WASHER
12 123235008/0 NEEDLE BEARING
13 123590012/0 PISTON
14 123760006/0 PISTON PIN
15 123202006/0 CIRCLIP
16 123204014/0 PISTON RING
17 183070007/0 CYLINDER ASSY
18 123082006/0 STABILIZER
19 123878076/0 SCREW
20 119035163/0 SEAL RING
21 123878081/0 SCREW
22 123280067/0 MUFFLER GASKET
23 183740018/0 MUFFLER
24 6995251 PLATE
25 123878078/0 SCREW
26 6995210 EARTH CABLE
27 6995227 STOP WIRE
28 123878079/0 SCREW
29 183044001/0 ELECTRONIC COIL
30 6995022 SPARK PLUG SPRING
31 6995066 SPARK PLUG COVER
32 123160063/0 SPACER
34 123073516/0 SPARK PLUG
35 123878077/0 INTAKE MANIFOLD ASSY
36 6995212 SCREW
37 123054034/0 GASKET
38 123275025/0 CARBURETTOR
39 123315093/0 GROMMET
40 183040000/0 CHOKE LEVER ROD
41 123543002/0 AIR FILTER SUPPORT + COVER
42 123878086/0 SCREW
43 123220014/0 AIR FILTER
51 123878008/0 SCREW
52 123600075/0 FRONT COVER
53 118802270/0 CRANKASE ASS.Y
54 6995187 SCREW
55 183875003/0 BREATHER VALVE ASSY
56 123275024/0 GROMMET
57 183790010/0 CAP ASS'Y
58 123018001/0 AIR PURGE
59 123867019/0 PIPE
60 123650004/0 GROMMET
61 183520007/0 FUEL PICKUP ASSY
62 123867020/0 PIPE
63 123878082/0 SCREW
64 123109580/0 UPPER COVER
65 123600072/0 GUARD
66 123202007/0 CHAIN GUARD
67 123878093/0 SCREW
65 123600072/0 GUARD
66 123202007/0 CHAIN GUARD
67 123878093/0 SCREW
71 123600073/0 GASKET
72 123652506/0 WASHER
73 123867020/0 PIPE
74 183594508/0 OIL PUMP ASSY
75 123878083/0 WORM SCREW
76 123867024/0 PIPE
77 123878084/0 SCREW
78 123109577/0 OIL PUMP COVER
79 123878080/0 SCREW
80 123235009/0 NEEDLE BEARING
81 123050007/0 DRUM ASS'Y, CLUTCH 3/8"
81 123050008/0 DRUM ASS'Y, CLUTCH 1/4"
82 123657011/0 SPROCKET WASHER
83 183215008/0 CLUTCH ASS.Y
84 123311009/0 PLATE
85 118800255/0 OIL INGOING TUBE
86 118801162/0 SUCTION JET
87 123275027/0 SHOCK ABSORBER
88 123878093/0 SCREW
89 123790022/0 CAP
90 123208412/0 CLAMP
91 123878080/0 SCREW
92 123206852/0 FAIR LED
93 123867018/0 PIPE
94 123650005/0 PIPE CONNECTION
95 123220013/0 FUEL PICKUP ASSY
96 123430593/0 SPRING
97 123600074/0 GUARD
Chain Saw CJ 300 - Housing Pag.2
1 183058037/0 STARTER ASSY, YELLOW
1 118801168/0 STARTER ASSY, WHITE
1 118801169/0 STARTER ASSY,RED
2 123234005/0 STARTER CORD
3 123300013/0 STARTER HANDLE
4 123430594/0 STARTER SPRING
5 123604011/0 STARTER PULLEY
7 123878087/0 SCREW
8 123107504/0 AIR CONVEYOR
9 123878088/0 SCREW
10 123275026/0 GROMMET
11 183300023/0 HANDLE ASSY
12 123430599/0 SPRING
13 123315095/0 THROTTLE LEVER
14 123510098/0 ELASTIC PIN
15 123790021/0 CAP
16 123275027/0 SHOCK ABSORBER
17 123878093/0 SCREW
18 123790022/0 CAP
19 118800202/0 SWITCH
20 123867021/0 PIPE
21 123650005/0 PIPE CONNECTION
22 123867022/0 PIPE
23 183090013/0 REAR COVER
23A 123593507/0 KNOB
23B 123657012/0 BUSH
24 123835002/0 THROTTLE ROD
25 123315096/0 SAFETY LEVER
26 123109579/0 HANDLE, UPPER PART
27 123878008/0 SCREW
28 123878008/0 SCREW
31 123790022/0 CAP
32 123878093/0 SCREW
33 123275027/0 SHOCK ABSORBER
34 183105000/0 HANDLE
35 123657014/0 PLATE
41 123878088/0 SCREW
42 123311010/0 BAR PLATE
43 123796008/0 NUT
44 123878092/0 SCREW
45 123510097/0 PIN
46 123448005/0 BRAKE BAND
47 123665004/0 NEEDLE
48 123430598/0 SPRING
49 123315094/0 LEVER
50 123430595/0 SPRING
51 123120009/0 NUT
52 123657013/0 WASHER
53 123044219/0 BUSHING
54 123455009/0 HAND GUARD
55 123430597/0 SPRING
56 183315052/0 BRAKE RELEASE LEVER ASS'Y
57 123665003/0 NEEDLE
58 123044220/0 BUSHING
59 123430596/0 SPRING
63 123109578/0 BRAKE COVER
64 123059036/1 CLUTCH HOUSING YELLOW
64 118801170/0 CLUTCH HOUSING WHITE
64 118802734/0 CLUTCH HOUSING RED
66 123120010/0 NUT
71 123900360/0 Bar 10"-3/8"-0,050"
72 1519-9110-02 Chain 10"-3/8"-0,050"-40E
