Castor Spare Parts for Chain Saw CP 411 (2010) 222516001/05
€54.66
Tax included
Castor Spare Parts for Chain Saw CP 411 (2010) 222516001/05
Alpina Genuine spare parts or replacement parts for to repair Chain Saw CP 411 (2010) 222516001/05.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Castor Spare Parts for Chain Saw CP 411 (2010) 222516001/05
Alpina Genuine spare parts or replacement parts for to repair Chain Saw CP 411 (2010) 222516001/05.
In the following table, look for the model of the Chain Saw and the respective parts of the code.
| ALPINA CP 411 (2010) 222516001/05 pag.1 | ||
| # | Part Num. | Description |
| 1 | 4252600 | Starter Carter Assembly Yellow |
| 1 | 4252603 | Starter Carter Assembly Red |
| 2 | 3784030 | Starter rope |
| 3 | 3750067 | Starter handle |
| 4 | 2123030 | Screw |
| 5 | 4611480 | Starter Spring |
| 6 | 3623590 | Bushing |
| 7 | 3723640 | Starter Spring Disc |
| 8 | 3750130 | Starter Pulley |
| 9 | 3750080 | Starter coupling |
| 10 | 3750140 | Starter Hook Guide |
| 11 | 3657480 | Locking |
| ALPINA CP 411 (2010) 222516001/05 pag.2 | ||
| 1 | 2432050 | Nut |
| 2 | 2312080 | Washer |
| 3 | 3L4541210/1 | Flywheel Magnet From 01-September-2005 |
| 3 | 4541210 | Flywheel Magnet To 31-August-2005 |
| 4 | 3151010 | Flywheel key |
| 5 | 3121071 | Seal Ring 5a |
| 5 | 3121072 | Seal Ring 5b |
| 6 | 3112030 | Ball bearing |
| 7 | 3614480 | Washer |
| 8 | 3L4251960/1 | Crankshaft assembly |
| 9 | 3750311 | Oil Pump Cover - DISCONTINUED |
| 10 | 3L4252200/1 | Clutch assembly |
| 11 | 3114190 | Needle Bearing |
| 12 | 4122070 | Clutch Drum |
| 13 | 3612620 | Pinion Washer - DISCONTINUED |
| 14 | 112000955/0 | Benzing ring |
| 15 | 3356050 | Circlip |
| 18 | 3158260 | Piston pin |
| 19 | 3116100 | Needle Bearing |
| 20 | 2135030 | Screw |
| 21 | 2330020 | Washer |
| 22 | 3123220 | Piston Ring Ø 39 |
| 23 | 3L8541360/1 | Piston assembly |
| 24 | 3L8541370/1 | Cylinder - Piston assembly |
| 25 | 3210024 | Spark Plug |
| 26 | 4252550 | Spark Plug Cap |
| 27 | 3657050 | Spark Plug Spring |
| 29 | 3210970 | Stop switch |
| 32 | 3211380 | Earth Cable |
| 33 | 3L3211350/1 | Electronic Coil |
| 34 | 3654480 | Spring |
| 35 | 2321150 | Washer |
| 36 | 2123140 | Screw |
| 37 | 2123020 | Screw |
| ALPINA CP 411 (2010) 222516001/05 pag.3 | ||
| 1 | 2135040 | Screw |
| 2 | 4122040 | Muffler assembly |
| 3 | 3724270 | Muffler gasket |
| 5 | 3786130 | Tube |
| 7 | 3743640 | Air Choke |
| 8 | 8744781 | Intake Manifold Assembly |
| 9 | 2135210 | Screw |
| 10 | 3745650 | Air Lever Grommet |
| 11 | 123054003/2 | Carburetor |
| 12 | 3724160 | Manifold Thermal Spacer Gasket |
| 13 | 4252480 | Throttle Cable with Sheath |
| 14 | 3750180 | Intake manifold |
| 15 | 3724300 | Cylinder Manifold Gasket |
| 16 | 3744740 | Primer |
| 18 | 8724091 | Diaphragm Kit - Carburetor Gaskets |
| 19 | 8724300 | Gaskets Set |
| 20 | 3721560 | Cylinder gasket |
| 21 | 3211690 | Earth Cable |
| ALPINA CP 411 (2010) 222516001/05 pag.4 | ||
| 2 | 4252630 | Oil cap assembly |
| 3 | 4252630 | Oil cap assembly |
| 4 | 4252220 | Oil Pump Assembly |
| 5 | 3744790 | grommet - DISCONTINUED |
| 6 | 2123020 | Screw |
| 7 | 3614810 | Plate for rubber stopper pump |
| 8 | 323900107/0 | 16 inch bar |
| 9 | 2653470 | Screw |
| 10 | 123878001/0 | Screw |
| 11 | 3641970 | Chain Tensioner Pin |
| 12 | 3741360 | Oil Cap / Delivery |
| 13 | 3614930 | Bar Base Reinforcement Insert |
| 14 | 3L4353090/1 | Oil Vent Tube Assembly |
| 15 | 323311002/0 | Bar Base Metal Plate |
| 16 | 4113711 | 16inch chain |
| 17 | 4252590 | Yellow Clutch Housing Assembly |
| 17 | 4252593 | Clutch Housing Set Red |
| 18 | 3786050 | Internal Pipe Intake Fuel |
| 19 | 4253290 | Fuel Filter |
| 20 | 2670270 | Nut |
| 21 | 323650100/0 | Screw |
| 22 | 4253680 | Tank Vent Valve Assembly |
| 23 | 2123060 | Screw |
| 24 | 323026000/0 | Spiked Bumper |
| 25 | 2123100 | Screw |
| 26 | 4181307 | 16 inch cover |
| ALPINA CP 411 (2010) 222516001/05 pag.5 | ||
| 1 | 3614740 | Brake Tape |
| 2 | 2312100 | Washer |
| 3 | 2123060 | Screw |
| 4 | 4252310 | Brake Link Lever |
| 5 | 3180500 | Pin |
| 6 | 3614780 | Spring |
| 8 | 2123100 | Screw |
| 9 | 3654420 | Brake Spring |
| 10 | 3614490 | Brake Plate |
| 11 | 3180510 | Pin |
| 12 | 3614330 | Bush - DISCONTINUED |
| 14 | 2123030 | Screw |
| 15 | 4252610 | cylinder cover Yellow |
| 15 | 4252613 | cylinder cover Red |
| 16 | 4563770 | Handguard with insert |
| 17 | 8781610 | Air filter |
| 19 | 3750450 | Primer Button Cap |
| 20 | 3654430 | Spring |
| 21 | 3750440 | Button |
| ALPINA CP 411 (2010) 222516001/05 pag.6 | ||
| 1 | 4563750 | Handle - Handrail |
| 2 | 4563760 | Handle cover |
| 3 | 3743587 | Throttle Lever For Cable |
| 4 | 1L3654440/1 | Safety Throttle Lever Spring 360-41 |
| 5 | 3743597 | Safety Lever |
| 6 | 3654400 | Spring |
| 7 | 3614800 | Washer |
| 8 | 2123100 | Screw |
| 9 | 2123031 | Screw |
| 10 | 2135040 | Screw |
| 11 | 2432040 | Nut |
| 12 | 2312090 | Washer |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Castor websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Castor brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
CP 411 - 222516001
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 7/10 BUSINESS DAYS APPROX
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N ALPINA:
- STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS
