Carat Spare Parts for A-1825 DIAMOND DRILL MACHINE
search
  • Carat Spare Parts for A-1825 DIAMOND DRILL MACHINE
  • Carat Spare Parts for A-1825 DIAMOND DRILL MACHINE

Carat Spare Parts for A-1825 DIAMOND DRILL MACHINE

€86.81
Tax included

Carat Spare Parts for A-1825 DIAMOND DRILL MACHINE

Carat service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for A-1825 DIAMOND DRILL.
ITEM CODE: XBA-692300
Quantity

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Carat Spare Parts for A-1825 DIAMOND DRILL MACHINE

Carat service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for A-1825 DIAMOND DRILL.

In the following table , look for the model of the Angle Grinder and their respective spare parts.
A-1825 DIAMOND DRILL MACHINE
# Part Num. Description
1 XBA-692300 SUCTION HOSE
2 XBA-597090 SPRING CLAMP
3 XBA-667040 DRIVE SHAFT
4 XBA-224750 BALL 4 DIN5401
5 XBA-494520 CYLINDER PIN 4X18 DIN6325
6 XBA-377050 O-RING 18X3.5
7 XBA-366400 FUSE RING J 47X1.75 DIN472
8 XBA-826900 GROOVED BALL BEARING 16005 2RS
9 XBA-622160 SEALING RING 30X47X7 DIN3760
10 XBA-528780 STOP RING AXLE
11 XBA-528860 STOP RING HOUSING
12 XBA-502600 SCREW EJOT DELTA PT 5X100 TORXPLUS
13 XBA-827500
14 XBA-725200 RETAINING RING 30X42X7 DIN3760 VIA
15 XBA-330190 GROOVED BALL BEARING 6203
16 XBA-507160 LOCK RING J 40 DIN472
17 XBA-596750 COG WHEEL 40Z
18 XBA-597580 GEAR SHAFT
19 XBA-597740 STICKER BLACK
20 XBA-607490 O-RING 13X2
21 XBA-597820 STICKER GREEN
24 XBA-224000 GROOVED BALL BEARING 629
25 XBA-764550 INTERMEDIATE SHAFT COUPLING
27 XBA-127240 GASKET
28 XBA-221030 CYLINDER PIN 4X16 DIN7
29 XBA-611920 MOTOR COVER
31 XBA-427130 GROOVED BALL BEARING 6201 2RS
32 XBA-216000 FAN
33 XBA-648100 ARMATURE 230V
34 XBA-511600 INSULATING RING
35 XBA-226810 GROOVED BALL BEARING 6000 2RS
36 XBA-804200 AIR CONDUCTION RING SHORT
37 XBA-153130 HAND GRIP PA-GF 210MMLG
38 XBA-775600 SCREW EJOT DELTA PT 4X90 TORXPLUS
39 XBA-458560 FIELD 230V
40 XBA-454430 MOTOR HOUSING
42 XBA-458720 CARBON BRUSH
43 XBA-528940 CARB.BRUSH HOLDER A3
44 XBA-456250 CARB. BRUSH HOLDER COVER
45 XBA-210300 SCREW EJOT DELTA PT 4X12 TORXPLUS
47 XBA-252210 BEND PROTECTION
48 XBA-586440
49 XBA-179130 CABLE BRIDGE
50 XBA-209900 SCREW EJOT DELTA PT 4X16 TORXPLUS
51 XBA-449410 SCREW EJOT DELTA PT 5X40 TORXPLUS
52 XBA-427210 SCREW EJOT DELTA PT 4X19 TORXPLUS
53 XBA-350550 ELECTRONIC CONTROLLER
54 XBA-248440 SWITCH
55 XBA-326070 HAND GRIP COUPLING
56 XBA-496840 HAND GRIP EXTENSION
57 XBA-734000 CARBON BR. HOLDER COVER WITH LIBEL
60 XBA-597660 INFORMATION PLATE
61 XBA-615560 INFORMATION PLATE (SOFT IMPACT)
62 XBA-595430
63 XBA-310880 COMPANY PLATE
64 XBA-628440
71 XBA-630730 O-RING 44X2.5
94 XBA-485040 CONNECTION CLAMP 1-P
95 XBA-489180 PROTECTION PIPE
96 XBA-623310 WASHER PLATE M4 DIN433 GALV.
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Carat websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Carat brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
