Carat Spare Parts for A-1810 DUSTEC® DIAMOND DRILL

Carat service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for A-1810 DUSTEC® DIAMOND DRILL.

In the following table , look for the model of the Angle Grinder and their respective spare parts.
Carat A-1810
A-1810 DUSTEC® DIAMOND DRILL
# Part Num. Description
1 DPB0310000 ADATTATORE CUFFIA DUSTEC X 5/8X16UNF
2 HT00600000
3 XAM-E30950 SEALING WASHER 17X32X7
4 XAM-E30A05 SEALING WASHER 12X22X4
5 XAM-E4035A O-RING 35X1,5
6 XAM-E4084A O-RING 85X2,0
7 XAM-EA007D CUSCINETTO 629
8 XAM-EA028F CUSCINETTO 6202
9 XAM-EA034B CUSCINETTO 6003
10 XAM-EA036A CUSCINETTO 6203
11 XAM-EB008A NEEDLE BUSH 0810
12 XAM-EB015A NEEDLE BUSH HOUSING 1210
13 XAM-EN0105 NEEDLE BUSH 513
14 XAM-ES012A BEARING BUSH 12X14X10
15 XAM-F6Q112 PIN 4X12
16 XAM-F6R214 KEY 5X5X14
17 XAM-FB2030 HEXAGONAL BOLT M12X30
18 XAM-FC0870 HEXAGONAL BOLT M8X70
19 XAM-FF1432 PANNED CYLINDRICAL SCREW 4,8X32
20 XAM-FF1450 PANNED CYLINDRICAL SCREW 4,8X50
21 XAM-FF1485 PANNED CYLINDRICAL SCREW 4,8X85
22 XAM-FIK051 SET SCREW M5X10
23 XAM-FM10S1 NUT M10
24 XAM-FR0130 SHIM RING 13MM
25 XAM-FR5250 DISC SPRING 25X12,2
26 XAM-FS10P2 SHIM RING 10X16MM
27 XAM-N14001 MAIN AXE 5/8''-16UNF
28 XAM-N14003 GEAR
29 XAM-N14004 DRIVE
30 XAM-N14005 PINION
31 XAM-N14006 SLIP RING
32 XAM-N14007 LOCK RING
33 XAM-N14010 AIR RING
34 XAM-N14011 BEARING CARTER
35 XAM-N14012 GEAR FOR ROTOR
36 XAM-N14015 BACKSIDE GRIP PART RIGHT
37 XAM-N14016 BACKSIDE GRIP PART LEFT
38 XAM-N14017 GRIP COMPLETE
39 XAM-N14018 CLUTCH COMPLETE
40 XAM-N14020 CARBON BRUSH HOLDER
41 XAM-N14021 CARBON BRUSH SET A-14../18..
42 XAM-N14022 CARBON BRUSH COVER
43 XAM-N14023 CABLE GUIDE
44 XAM-N14024 CABLE CLAMP
45 XAM-N14025 LOCK RING
46 XAM-N14026 SHAFT SIDE GRIP
47 XAM-N14027 GRIP SIDE GRIP
48 XAM-N140281 LAMINATE STICKER FOR TYPE PLATE
49 XAM-N14030 SWITCH 8A
50 XAM-N14032 LED
51 XAM-N14033 CONDENSER INCLUDING FASTONS
52 XAM-N14034 BULLS EYE CYLINDRICAL
53 XAM-N14035 BULLS EYE ROUND
54 XAM-N14039 SCREW 3,5X16 TAPPING
55 XAM-N14040 SCREW 4,0X20 TAPPING
56 XAM-N14045 CABLE
57 XAM-N14050 GEAR BOX A-1651/A-1810DT
58 XAM-N14051
59 XAM-N14096 SEALING FOR A14../A18../A20..
60 XNB-N18009
61 XAM-N18010 PRINTED CIRCUIT BOARD COMPLETE 1800
62 XAM-N18013 STATOR 1800W
63 XAM-N18014 ROTOR 1800W
64 XAM-N18034 ROTOR COMPLETE 1800W
65 XAM-N18087
63 XAM-N18014 ROTOR 1800W
64 XAM-N18034 ROTOR COMPLETE 1800W
65 XAM-N18086
66 XAM-FR5500 DISC SPRING 25X12,2
67 XAM-NMHX002
68 XAM-NMVX002
69 XAM-G10040 SPANNER SW24
70 XAM-N14046 OIL GEAR BOX 1400W
71 ZVMKA1810N ALU PHOTO CASE FOR A-1810
72 ZANT050000 DUSTEC RUBBER SEAL
