Bosch Spare Parts for Table Saw GTS 10
We are BOSCH original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues fore Table Saw GTS 10 - 0601B30003.
In the following table, look for the model of the Bench Saw and the respective parts of the code.
| Bench Saw GTS 10/0 601 B30 003 | ||
| # | Part Num. | Description |
| 1 | 2610996864 | Motor Housing |
| 2 | 1609203K86 | Field 230V |
| 3 | 1619P03278 | Armature 230V |
| 4 | 1609203K88 | Switch |
| 5 | 1609203K89 | Power supply cord |
| 6 | 1609203K90 | Cord guard |
| 7 | 2610358842 | Clamp |
| 8 | 1609203K91 | Front Panel |
| 9 | 2610997806 | Sticker |
| 13 | 2610004595 | Ball Bearing |
| 14 | 2610911927 | Ball Bearing |
| 16 | 2610911858 | Brush Holder |
| 19 | 2610358844 | Screw |
| 20 | 1609902557 | Manufacturer's nameplate |
| 21 | 1609902558 | Nameplate |
| 22 | 2610996865 | Cover |
| 23 | 2610998571 | Screw |
| 24 | 2610911859 | Brush-Cover Ø 20mm |
| 25 | 2610327868 | Nut |
| 26 | 2610911569 | Insert |
| 27 | 2610911929 | Screw |
| 28 | 2610996948 | Rubber Ring |
| 29 | 2610911566 | Bearing cover |
| 30 | 2610355295 | Screw |
| 31 | 2610996863 | Gear Housing |
| 32 | 1609902670 | Screw |
| 33 | 2610911924 | Spring Washer |
| 34 | 2610996949 | Ball Bearing |
| 35 | 2610997281 | Spring retaining ring |
| 36 | 2610997208 | Toothed Gear |
| 37 | 2610996869 | Gear Cover |
| 38 | 2610997282 | Spring retaining ring |
| 39 | 2610997210 | Ball Bearing |
| 40 | 2610997211 | Output Shaft |
| 41 | 2610993102 | Woodruff Key |
| 42 | 2610996932 | Bearing Sleeve |
| 43 | 2610355293 | Screw |
| 44 | 1609902679 | Screw |
| 45 | 2610996875 | Torsion Spring |
| 46 | 2610996874 | Locking Lever |
| 47 | 2610996876 | Shoulder Screw |
| 48 | 1609203K93 | Clamping Flange |
| 49 | 2610996871 | Clamping Flange |
| 50 | 2610358858 | Nut |
| 51 | 2610996879 | Wing Screw |
| 52 | 2610996878 | Cover Plate |
| 53 | 1609902699 | Screw |
| 54 | 2610996877 | Cover Plate |
| 55 | 2610996861 | Holding Plate |
| 56 | 2610996862 | Guiding bolt |
| 57 | 2610997276 | Spring retaining ring |
| 58 | 2610996895 | Threaded Rod |
| 59 | 2610998573 | Spring retaining ring |
| 60 | 2610997221 | Bushing |
| 61 | 2610996896 | Toothed Gear |
| 62 | 1609902672 | Spring Washer |
| 63 | 2610998588 | Screw |
| 64 | 2610358149 | Nut |
| 65 | 2610910796 | Bolt |
| 66 | 2610997277 | Spring retaining ring |
| 67 | 2610997212 | Mounting Bracket |
| 68 | 2610997222 | Bushing |
| 69 | 2610297323 | Screw |
| 70 | 2610355325 | Spring Washer |
| 71 | 2610996897 | Shaft |
| 72 | 2610996933 | Threaded Bushing |
| 73 | 2610996938 | Bushing |
| 74 | 2610303023 | Screw |
| 75 | 2610997271 | Spring |
| 76 | 2610998550 | Plain Washer |
| 77 | 2610997299 | Plain Washer |
| 78 | 2610997298 | Nut |
| 79 | 2610996898 | Clamping Lever |
| 80 | 1609203K94 | Handwheel |
| 81 | 1609902669 | Set screw |
| 82 | 2610996925 | Knob |
| 83 | 2610997270 | Shoulder Screw |
| 84 | 1609902696 | Screw |
| 85 | 2610996927 | Pointer |
| 86 | 2610355570 | Washer |
| 87 | 2610356706 | Nut |
| 88 | 2610997286 | Screw |
| 89 | 2610996929 | End stop |
| 90 | 1609203L32 | Housing |
| 91 | 2610997294 | Screw |
| 92 | 1609203K95 | Switch Housing |
| 93 | 2610358846 | Rubber Bushing |
| 94 | 2610996930 | Pickup Clip |
| 95 | 2610996931 | Pickup Clip |
| 96 | 2610910047 | Screw |
| 97 | 2610990504 | Cable Clip |
| 98 | 2610997273 | Screw |
| 99 | 2610997246 | Nut |
| 100 | 2610996880 | Key |
| 102 | 2610996922 | Holder |
| 103 | 2610998574 | Screw |
| 104 | 1609203K96 | Cable Clip |
| 105 | 1609203L33 | Connecting Cable |
| 106 | 2610997297 | Screw |
| 107 | 2610910013 | Washer |
| 108 | 2610998575 | Screw |
| 109 | 2610996894 | Bearing Pedestal |
| 110 | 2610908271 | Tapping Screw |
| 111 | 2610998587 | Screw |
| 112 | 2610996921 | Holding Bracket |
| 113 | 2610996913 | Pin |
| 114 | 2610996917 | Plate |
| 115 | 2610996914 | Gusset |
| 116 | 2610997275 | Pin |
| 117 | 2610997274 | Pin |
| 118 | 2610996918 | Set screw |
| 119 | 2610996920 | Connecting Nut |
| 120 | 1609203L34 | Rod |
| 121 | 2610994262 | Clamp |
| 122 | 2610996915 | Clamping Piece |
| 123 | 2610355272 | Nut |
| 124 | 2610996916 | Tommy Screw |
| 125 | 2610997217 | End stop |
| 126 | 1609203L35 | Table top |
| 127 | 2610996855 | Mounting Rail |
| 128 | 2610996912 | Fixing Plate |
| 129 | 2610996856 | Mounting Rail |
| 131 | 2610303029 | Screw |
| 132 | 2610320339 | Screw |
| 133 | 2610996941 | Pointer |
| 134 | 2610996853 | Profile Rail |
| 135 | 2610996923 | Cover |
| 138 | 2610908270 | Washer |
| 139 | 2610997244 | Cover |
| 140 | 2610996926 | End stop |
| 141 | 2610997218 | Cover |
| 142 | 2610996854 | Profile Rail |
| 143 | 2610997216 | Cover |
| 144 | 1609203L36 | Table top |
| 145 | 2610996928 | Retaining Plate |
| 146 | 1619P01539 | Trunnion |
| 147 | 2610304772 | Nut |
| 148 | 2610998577 | Protective Cover |
| 149 | 1609203K97 | Rule |
| 150 | 2610997807 | Sticker |
| 151 | 1609203L37 | Insert |
| 152 | 2610997283 | Stud |
| 153 | 2610011716 | Holding Spring |
| 158 | 2610998579 | Clamp Handle |
| 159 | 2610909178 | Plain Washer |
| 160 | 1609203L38 | End stop |
| 161 | 1609902697 | Screw |
| 162 | 2610908272 | Nut |
| 165 | 1609203L39 | Guide Bar |
| 166 | 2610997214 | Pointer |
| 167 | 2610997215 | End stop |
| 168 | 2610296243 | Screw |
| 172 | 2610997291 | Pin |
| 182 | 2610996891 | Slide Rail |
| 183 | 2610998570 | Bracket |
| 184 | 2610358892 | Cover |
| 185 | 1609203K99 | Rod |
| 186 | 1609902703 | Retaining Pin |
| 187 | 2610996888 | Spring |
| 188 | 1609203L40 | Profile Rail |
| 189 | 2610358802 | Washer |
| 190 | 2610996884 | Housing |
| 191 | 2610996886 | Locking Lever |
| 192 | 2610997292 | Pin |
| 193 | 2610996885 | Clamping Plate |
| 194 | 2610997240 | Clamping Piece |
| 195 | 2610997293 | Screw |
| 196 | 2610997245 | Adjusting Screw |
| 197 | 2610911920 | Rubber Bushing |
| 198 | 2610998551 | Hexagon Socket Screw Key |
| 199 | 2610998580 | Screw |
| 200 | 2610328617 | Screw |
| 201 | 2610992380 | Spring retaining ring |
| 202 | 1609203L00 | Sticker |
| 203 | 2610358932 | Connector |
| 204 | 2610303020 | Plain Washer |
| 205 | 2610303026 | Screw |
| 206 | 2610967422 | Screw |
| 208 | 2610998593 | Spring |
| 209 | 2610912588 | Plain Washer |
| 211 | 1609203L01 | Sticker |
| 212 | 2610341465 | Washer |
| 213 | 2610913192 | Compression Spring |
| 214 | 1609203L03 | End stop |
| 215 | 1609203L04 | Clamping Plate |
| 216 | 1609203L05 | Screw |
| 217 | 1609203L06 | Knob |
| 218 | 1609203L07 | Profile Rail |
| 219 | 1609203L08 | Bolt |
| 220 | 1609203L09 | Guard Plate |
| 221 | 1609203L10 | Plain Washer |
| 222 | 1609203L11 | Nut |
| 223 | 1609203L12 | Holding Plate |
| 224 | 1609203L13 | Screw |
| 225 | 1609203L14 | Nut |
| 226 | 1609203L15 | Screw |
| 227 | 1609203L16 | Guard Plate |
| 228 | 1609902044 | Screw |
| 229 | 1609203L18 | Pusher |
| 230 | 1609203L19 | Nut |
| 231 | 1609203L20 | Sticker |
| 232 | 1609902027 | Riving Knife |
| 233 | 1609902025 | Flap Guard |
| 234 | 1609902026 | Flap Guard |
| 235 | 1609902045 | Cover Plate |
| 236 | 1609902040 | Screw |
| 237 | 1609902030 | Guard Holder |
| 238 | 1609902029 | Spacer |
| 239 | 1609902028 | Screw |
| 241 | 1609203L30 | Container |
| 242 | 1609203L31 | Sticker |
| 243 | 1609902033 | Screw |
| 244 | 1609902023 | Pin |
| 245 | 1609902024 | Nut |
| 246 | 1609902047 | Round Nut |
| 247 | 2610993221 | Plain Washer |
| 248 | 1609902048 | Coil |
| 249 | 1609902050 | Cable Strap |
| 250 | 1609902051 | Cupped Washer |
| 251 | 1609902052 | Spring Washer |
| 252 | 1609902053 | Plain Washer |
| 253 | 1609902032 | Cupped Washer |
| 254 | 1609902031 | Extension Spring |
| 255 | 1609902041 | Spacer |
| 256 | 1609902046 | Screw |
| 257 | 1609902043 | Washer |
| 258 | 1609902042 | Washer |
| 260 | 1609902054 | Set screw |
| 261 | 1609902055 | Screw |
| 262 | 1609902056 | Screw |
| 263 | 1609902057 | Screw |
| 264 | 2610355278 | Screw |
| 265 | 1609902022 | Round Nut |
| 266 | 2610911896 | Nut |
| 267 | 1609902058 | Nut |
| 268 | 1609902039 | Linkage part |
| 269 | 1609902059 | Screw |
| 270 | 1609902060 | Label |
| 271 | 2610997296 | Screw |
| 272 | 2610358936 | Washer |
| 273 | 1609902063 | Lens |
| 274 | 1609902616 | Washer |
| 670 | 2610919255 | Fitting |
| 801 | 1609203L41 | Protective Cover |
| 802 | 1609203L42 | Edge Guide |
| 803 | 1609203L43 | Mitre Fence |
| 810 | 1609203L02 | Carbon-Brush Set |
| 820 | 1609902076 | Clamp Handle |
| 821 | 1609902077 | Rod |
| 822 | 1609902078 | Locking clamps |
