Bosch Spare Parts for Percussion Drill GSB 24-2
€39.87
Tax included
Bosch Spare Parts for Percussion Drill GSB 24-2
BOSCH Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Percussion Drill GSB 24-2 - 3601A9C801.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Percussion Drill GSB 24-2
BOSCH Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Percussion Drill GSB 24-2 - 3601A9C801.
In the following table, look for the model of the Percussion Drill and the respective parts of the code.
| Percussion Drill GSB 24-2 - 3601A9C801 | ||
| # | Part Num. | Description |
| 1 | 2605105141 | Motor Housing DARK BLUE |
| 2 | 2604220727 | Field 230-240V |
| 4 | 160720032L | Switch |
| 6 | 2600707078 | Grommet |
| 9 | 160111C2KG | Manufacturer's nameplate GSB 24-2 |
| 14 | 2600905095 | Ball Bearing 9x24x7 |
| 19 | 2603490017 | Torx Oval-Head Screw 3x10 |
| 20 | 2601115903 | Reference Plate |
| 24 | 2606135148 | Drilling Spindle |
| 26 | 2604616013 | Compression Spring |
| 27 | 1900905163 | groove ball bearing 17x35x10 |
| 28 | 2600100695 | Shim 0,5 MM |
| 29 | 2916650008 | Spring retaining ring DIN 471 17x1 MM |
| 30 | 2602300032 | Flat Key |
| 31 | 2600101671 | Retaining Washer |
| 33 | 2606317086 | Cylindrical Gear |
| 34 | 2606317098 | Cylindrical Gear |
| 35 | 2600101047 | Shim 0,3 MM |
| 36 | 2600190105 | Catch Disk |
| 38 | 2600000021 | Shim washer 1,0 MM |
| 38 | 2600000030 | Shim washer 1,35 MM |
| 38 | 2600000031 | Shim washer 1,7 MM |
| 40 | 1903230009 | Ball DIN 5401-5 G28 |
| 40 | 1903230010 | Ball DIN 5401-5,5MM-III-ST |
| 40 | 2603230007 | Ball 5,25 MM |
| 41 | 2602026168 | Rotary Knob BLACK |
| 42 | 2603120064 | Control Shaft |
| 44 | 2601015091 | Seal |
| 46 | 2603435086 | Tapping Screw |
| 47 | 2605132070 | Housing Cover DARK BLUE |
| 53 | 2600550008 | Disc Spring |
| 63 | 2603435085 | Headless Screw |
| 68 | 2604616014 | Compression Spring |
| 69 | 2602026117 | Rotary Knob BLACK |
| 71 | 2600590006 | Ratchet Cap |
| 72 | 2603490027 | Torx Oval-Head Screw 4x40 |
| 73 | 2603490022 | Screw 4x16 |
| 74 | 2601324062 | Switch Contact |
| 75 | 2601099260 | Contact |
| 76 | 1614336086 | Brush Plate |
| 78 | 2916660014 | Spring retaining ring DIN 472 35x1,5 MM |
| 84 | 2916660008 | Spring retaining ring DIN 472-24x1,2 MM |
| 85 | 2608572143 | Keyless Chuck HSB 4 |
| 86 | 1614448014 | Connecting Cable L=80 MM |
| 87 | 1600A014ZP | Connecting Cable L=170 |
| 89 | 2605510206 | Lens BLACK |
| 210 | 160111C0YY | Sticker KickBack Control |
| 653 | 2602025184 | Auxiliary Handle BLACK |
| 655 | 1613001009 | Depth-Gauge SW 6x210 MM |
| 803 | 2604011401 | Armature 230-240V |
| 805 | 1607000386 | Power supply cord EU 230V 4,15m 2 x 1,0mm H05 RN-F |
| 808 | 160111A5RK | Nameplate |
| 810 | 1617000525 | Carbon-Brush Set |
| 825 | 2605806882 | Gear Housing |
| 843 | 2605700946 | Bearing Bracket |
| 845 | 2600148016 | Air-Deflector Ring |
| 859 | 2606309941 | Transmission |
| 866 | 2602033018 | Adjusting Slide |
| 867 | 2606308925 | Toothed rack |
| 888 | 2601328900 | Holding Plate BLACK |
| 890 | 2607001305 | Fastening parts kit |
| 895 | 3605430003 | Grease Tube Albida |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s BOSCH websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to BOSCH brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Bosch GSB 24-2 - 3601A9C801
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N BOSCH:
- BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
