Bosch Spare Parts for Impact Drill GSB 22-2 RE

€31.07
Tax included

Bosch Spare Parts for Impact Drill GSB 22-2 RE

We have the original Spares BOSCH for Impact Drill GSB 22-2 RE - 0601146403 the diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Impact Drill GSB 22-2 RE. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Guarantee



ITEM CODE: 1607000386
Quantity
Usually Ships in: 10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Bosch Spare Parts for Impact Drill GSB 22-2 RE

Bosch genuine spare parts for to fix Impact Drill GSB 22-2 RE - 0601146403.

In the following table, look for the model of the Percussion Drill and the respective parts of the code.
Impact Drill GSB 22-2 RE - 0601146403

Impact Drill GSB 22-2 RE/0 601 146 403
# Part Num. Description
2 1614220136 Field 230-240V
3 2604011242 Armature With Fan 230-240V
4 2607200544 Switch
6 2600707066 Grommet Ø6,2-Ø6,9x90 MM
9 2601116658 Manufacturer's nameplate
13 2600905032 Deep-Groove Ball Bearing 7x19x6
14 1610905017 Deep-Groove Ball Bearing 9x24x7
19 2603490017 Torx Oval-Head Screw 3x10
20 2601117956 Reference Plate
24 2606135099 Drilling Spindle
26 2604616013 Compression Spring
27 1900905163 Deep-Groove Ball Bearing 17x35x10
28 2600100695 Shim 0,5 MM
29 2916650008 Spring retaining ring DIN 471 17x1 MM
30 2602300032 Flat Key
31 2600101671 Retaining Washer
32 2600101056 Shim
33 2606317084 Cylindrical Gear
34 2606317098 Cylindrical Gear
35 2600101047 Shim 0,3 MM
36 2600190090 Catch Disk
37 2600190078 Catch Disk
38 2600000012 Shim washer 0,2 MM
38 2600000014 Shim washer 0,5 MM
38 2600000021 Shim washer 1,0 MM
39 2603410048 Thread-forming tap. Screw M4x8
40 2603230007 Ball 5,25 MM
40 1903230009 Ball DIN 5401-5 G28
40 1903230010 Ball DIN 5401-5,5MM-III-ST
41 2602098014 Changeover Lever
42 2600114016 Pressure Plate
44 2601073014 Gasket
45 2600148007 Air Guide Plate
46 2603490024 Torx Oval-Head Screw 4x25
47 2605132053 Housing Cover DARK BLUE
48 2601324046 Contact Spring
53 2600550008 Disc Spring
61 2600100607 Shim 0,3 MM
62 2600914010 Needle bearing Ø6 MM
63 2603435070 Headless Screw
64 2603435077 Headless Screw
70 2601328068 Holding-Down-Appliance
71 2600590006 Ratchet Cap
72 2603490025 Torx Oval-Head Screw 4x30
73 2603490022 Torx Oval-Head Screw 4x16
74 2601324045 Contact Bar
75 2604477005 Blade terminal
76 2604337096 Brush Plate
78 2916660014 Spring retaining ring DIN 472 35x1,5 MM
80 2602099016 Change-Over Switch
81 2602319024 Carrier Bracket
82 2602319025 End stop
84 2601098067 Retaining Washer
85 2608571060 Key Chuck
88 2601328070 Holding Plate
653 2602025118 Auxiliary Handle Ø43 MM
655 1613001009 Depth-Gauge SW 6x210 MM
801 2605104784 Motor Housing DARK BLUE
805 1607000386 Power supply cord EU 230V 4,15m 2 x 1,0mm H05 RN-F
808 2601117594 Marking Plate
825 2605806894 Gear Housing
843 2605700942 Intermediate Flange
859 2606309933 Transmission
865 2605510901 Bulb Shield
867 2606308923 Toothed rack
876 2604321927 Carbon-Brush Set
879 2607230900 Speed governor 230-240V
885 2607950007 Chuck Wrench SG2
891 2603410046 Cross Recessed-Head Screw M3x5
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s BOSCH websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to BOSCH brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Bosch GSB 22-2 RE - 0601146403
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS APPROX.
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:
BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
New

Download

Diagram Bosch GSB 22-2 RE

Diagram Bosch GSB 22-2 RE

Download (104.64KB)
